Cat. No. H113-E1-1
E5ZN
Temperature Controller
OPERATION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Omron E5ZN

Summary of Contents for Omron E5ZN

  • Page 1 Cat. No. H113-E1-1 E5ZN Temperature Controller OPERATION MANUAL...
  • Page 2 E5ZN Temperature Controller Operation Manual Produced January 2001...
  • Page 4 OMRON. No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is con- stantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice.
  • Page 5 For example, the smallest unit of 50.02 (m) is 0.01 (m) and 0.01 is thus one EU. Parameter Notation The following table shows the alphabet notation used for parameter abbreviations and settings dis- played on the E5ZN-SDL Setting Display Unit.

  • Page 6: Table Of Contents

    Manual Mode ........... . . 4-10 Reading Temperatures for Multiple E5ZN Units ......
  • Page 7 SECTION 6 Using the E5ZN-SDL......Introduction ............
  • Page 8 TABLE OF CONTENTS Appendices Specifications ........... . . Error Displays .

  • Page 10: About This Manual

    Section 2 describes mounting, wiring, and other preparatory work that must be done before the E5ZN can be used. Section 3 describes the basic settings required by the E5ZN. Section 4 describes scaling, SP ramp, and other functions to enable maximum use of the E5ZN func- tions. Section 5 describes performing communications for the E5ZN.

  • Page 12: Precautions

    PRECAUTIONS This section provides general precautions for using the E5ZN Temperature Controller. The information contained in this section is important for the safe and reliable application of the Temperature Controller. You must read this section and understand the information contained before attempting to set up or operate an Temperature Controller.

  • Page 13: Intended Audience

    It is extremely important that a Temperature Controller be used for the speci- fied purpose and under the specified conditions, especially in applications that can directly or indirectly affect human life. You must consult with your OMRON representative before applying a Temperature Controller to the above men- tioned applications.
  • Page 14 Application Precautions !Caution Tighten the terminal screws properly. Tighten them to a torque of 0.40 to 0.56 N · m. !WARNING To maintain safety in the event of a Temperature Controller malfunction, always take appropriate safety measures, such as installing an alarm on a separate line to prevent excessive temperature rise.
  • Page 15 Application Precautions • Places directly subject to heat radiated from heating equipment • Places subject to intense temperature changes • Cleaning: Do not use paint thinner or the equivalent. Use standard grade alcohol to clean the Temperature Controller. • Install DIN track vertically. •...

  • Page 16: Outline

    SECTION 1 Outline Name and Function of Parts ........1-1-1 External Appearance.

  • Page 17: Name And Function Of Parts

    Name and Function of Parts 1-1-1 External Appearance • The E5ZN Temperature Controller can be mounted inside another device. • RS-485 communications is a standard feature with the E5ZN, allowing monitoring of process values and reading/writing parameters from the host.

  • Page 18: Display

    1-1-4 Setting Switches Use the switches to change the communications conditions for communica- tions with the host computer. Before using the E5ZN, match the settings to the host. Operate the switches under the following conditions only. • The power supply must be turned OFF. The settings will be enabled only when the power is turned ON again.

  • Page 19: I/O Configuration And Main Functions

    I/O Configuration and Main Functions Section 1-2 I/O Configuration and Main Functions 1-2-1 I/O Configuration Control ch1 Controller Control output Heating control output Temperature input/ analog input OR of Alarm 1 and HBA Aux. output 1 CT input Alarm 2 Alarm 3 Cooling control output...

  • Page 20: Main Functions

    Communications according to CompoWay/F (See note.) are supported and are performed through the RS-485 interface. Functions Up to 16 E5ZN Temperature Controllers can be operated from the host. Note CompoWay/F is a general-purpose serial communications-based unified communica- tions protocol developed by OMRON. CompoWay/F uses commands compatible with...
  • Page 21 I/O Configuration and Main Functions Section 1-2...

  • Page 22: Preparations

    SECTION 2 Preparations Installation........... . 2-1-1 External Dimensions.

  • Page 23: Installation

    Units. Use this Terminal Unit for all but the first Unit. 2-1-2 Assembling Units Joining Terminal Units Up to 15 Expansion E5ZN- SCT18S-500 Terminal Units can be connected to Together a basic E5ZN-SCT24S-500 Terminal Unit. Two Terminal Units can be connected by joining the side connector on each Terminal Unit.
  • Page 24 Installation Section 2-1 Attach a connector cover to the rightmost Terminal Unit. Connector cover Mounting to DIN Track Mounting the Unit Pull the hook down on the bottom, latch the top hook onto the track, push the Unit until the hook locks onto the track, and then push the hook back up to lock the Unit in place.
  • Page 25 Use a flat-blade screwdriver to pull down the hook and lift the Unit from the bottom. Flat-blade screwdriver Mounting End Plates Always mount end plates to both ends of the E5ZN Temperature Controllers. For only one For dense mounting of multiple Temperature Controller...
  • Page 26 Installation Section 2-1 Mounting Bracket Mount the E5ZN Temperature Controller to DIN track. Use screws to attach the DIN track to the control panel in at least three places. • PFP-50N (50 cm)/PFP-100N (100 cm) DIN Track Horizontal: NG Vertical: OK Position the DIN track vertical to the ground.
  • Page 27 Installation Section 2-1 Covers When wiring, open the E53-COV12 Terminal Cover attached to the E5ZN- SCT24S-500 Terminal Unit or the E53-COV13 Terminal Cover attached to the E5ZN-SCT18S-500 Terminal Unit. When wiring has been completed, close the cover until it clicks shut.

  • Page 28: Using The I/O Section

    2-2-2 Precautions when Wiring • Separate signal leads and power lines in order to protect the E5ZN and its lines from external noise. • We recommend using solderless terminals when wiring the E5ZN. • Tighten the terminal screws using a torque between 0.40 and 0.56 N·m.
  • Page 29 30 Vr.m.s and a 42.4-V peak or maximum 60 VDC. Recommended power supply: S8PS-05024 CD (OMRON) Inputs Connect channel 1 to terminals 10 to 12 and channel 2 to terminals 4 to 6 as...
  • Page 30 Control output 1 Control output 2 Control output 1 Control output 2 Pulse voltage output type Transistor output type E5ZN-2Q@H03@-FLK E5ZN-2T@H03@-FLK • The following table shows the specifications for each output. Output Specifications 12 VDC output voltage ± 15% (PNP) Pulse voltage Max.
  • Page 31 Using the I/O Section Section 2-2 Event Input • When event input is used, connect to terminals 3 and 9. Contact input Non-contact input • Use event inputs under the following conditions: Contact input ON: 1 kW max., OFF: 100kW min. No-contact input ON: residual voltage of 1.5 V max., OFF: leakage current of 0.1 mA max.
  • Page 32 (No 0, 1, 2) (No 3, 4, 5) (No 13, 14, 15) • When using an E5ZN-SDL Setting Display Unit, connect across terminals 21 and 22. Refer to Section 6 Using the E5ZN-SDL for information on how to use the Setting Display Unit.

  • Page 33: Installation Precautions

    Installation Precautions Section 2-3 Installation Precautions 2-3-1 Ensuring Prolonged Use Use the Temperature Controller in the following operating environment: Temperature: -10 to +55 ° C (with no icing or condensation) Humidity: 25% to 85% When the Temperature Controller is incorporated in a control panel, make sure that the Controller's ambient temperature (not the panel's ambient tem- perature) does not exceed 55 °...

  • Page 34: Enclosure Ratings

    Installation Precautions Section 2-3 2-3-4 Enclosure Ratings The enclosure ratings are shown in the following table. The E5ZN is not water- proof. Temperature Controller IP00 Module Terminal Units IP00...
  • Page 35 Installation Precautions Section 2-3...

  • Page 36: Temperature Control Settings

    Temperature Control Settings This section describes the basic functions of the E5ZN. Setting the Input Type ......... . .

  • Page 37: Setting The Input Type

    Input Type To set the input type to a K thermocouple from -20.0 to 500.0 ° C, use host communications or the E5ZN-SDL Setting Display Unit to set 1 as the set value for the input type. List of Input Types...

  • Page 38: Selecting Centigrade/Farenheit

    The same temperature unit is used for both channel 1 and channel 2. To use ° C, use host communications and set 0 as the temperature unit or use the E5ZN-SDL Setting Display Unit and set c. Unit Setting °C...

  • Page 39: Selecting Pid Control Or On/Off Control

    Either 2-PID control (PID control with two degrees of freedom) or ON/OFF control can be selected. The control method is selected by using host commu- nications or the E5ZN-SDL Setting Display Unit to change the “PID/OnOff” parameter. Set the control method for channels 1 and 2 separately. Default is for PID control.

  • Page 40: Setting Output Specifications

    • Use host communications or the E5ZN-SDL Setting Display Unit to set the “heating control period” and “cooling control period” parameters. Default is 2 s.

  • Page 41: Output Allocations

    Setting Output Specifications Section 3-4 3-4-3 Output Allocations • The E5ZN has four outputs. The following tables shows the default func- tions allocated to each output terminal. Name Terminal Setting OUT1 (control output 7, 8 Heating control output for ch 1...

  • Page 42: Setting The Sp

    Setting the SP 3-5-1 Changing the SP Use host communications or the E5ZN-SDL Setting Display Unit to set the SP. Default is 0 ° C. In this example, the set point will be changed from 0 ° C to 200 ° C.

  • Page 43: Executing On/Off Control

    Executing ON/OFF Control Section 3-6 Executing ON/OFF Control In ON/OFF control, the control output turns OFF when the process value (temperature) reaches the preset set point. When the control output turns OFF, the temperature begins to fall and the control output turns ON again. This operation is repeated between certain points.

  • Page 44: Setup

    To execute ON/OFF control, set the set point, the PID/OnOff parameter, and the hysteresis. Setting ch1 to ON/OFF Use host communications or the E5ZN-SDL Setting Display Unit to make the Control with an SP of following settings. 200 ° ° ° ° C and Hysteresis of •...

  • Page 45: Determining Pid Constants: Autotuning And Manual Setup

    ON/OFF control. • To start autotuning, use host communications operation commands or the E5ZN-SDL Setting Display Unit and set “AT execute/stop” to “execute.” • To stop autotuning, use host communications operation commands or the E5ZN-SDL Setting Display Unit and set “AT execute/stop” to “stop.”...

  • Page 46: Manual Setup

    Determining PID Constants: Autotuning and Manual Setup Section 3-7 3-7-2 Manual Setup To set PID parameters manually, use host communications or the E5ZN-SDL Setting Display Unit and set values for the “proportional band” (P), “integrated time” (I) and “derivative time” (D) parameters. Note When control characteristics are already known, the PID parameters can be set di- rectly to adjust control.

  • Page 47: Alarm Outputs

    Alarm Outputs Section 3-8 Alarm Outputs This section describes the “alarm type,” “alarm value,” “upper limit alarm,” and “lower limit alarm” parameters. 3-8-1 Alarm Type Alarms 1 and 2 Set value Alarm type Alarm output operation When alarm value When alarm value X is positive X is negative Alarm function OFF...
  • Page 48 Alarm Outputs Section 3-8 Operation for set value 1 (upper and lower limit alarms) would be as follows: Case 1 Case 2 Case 3 H < 0, L < 0 H < 0, L > 0 H > 0, L < 0 H <...

  • Page 49: Alarm Values

    Absolute-value lower limit with standby sequence Use host communications or the E5ZN-SDL Setting Display Unit to set the alarm type separately for each alarm for alarms 1 to 3. Defaults are “2: Upper limit.” Set the alarms separately for each channel.

  • Page 50: Using Heater Burnout Alarm (Hba)

    • Be sure to connect the CT to the E5ZN, and pass the heater lead through the CT hole. • Turn ON the heater at the same time as or before turning the E5ZN. If the heater is turned ON after turning the E5ZN, the heater burnout alarm will activate.

  • Page 51: Calculating The Detection Current Value

    Using Heater Burnout Alarm (HBA) Section 3-9 Note To detect heater burnout for a 3-phase heater, use the K2CU-F@@A-@GS (with gate input terminal). For details, see the data sheet. 3-9-3 Calculating the Detection Current Value • Calculate the set value by the following equation: (Normal current + Current at heater burnout) Set value = •...

  • Page 52: 3-10 Starting And Stopping Control

    2. Using the E5ZN-SDL Setting Display Unit. 3. Using an external contact for an event input. Operation after Turning • Set the operation status after the power supply for the E5ZN has been ON the Power Supply turned ON. Choose one of the following two statuses.

  • Page 53: 3-11 Operating Precautions

    Operating Precautions Section 3-11 3-11 Operating Precautions 1,2,3... 1. About four seconds is required for outputs to turn ON after the power is turned ON. Take this into consideration when the Temperature Controller is incorporated into a sequence circuit. 2. The Temperature Controller may be subject to the influence of radio inter- ference if used near a radio, TV, or wireless equipment.

  • Page 54: Settings Used Only When Required

    Manual Manipulated Variable......4-10 Reading Temperatures for Multiple E5ZN Units ..... .

  • Page 55: Shifting Input Values

    Shifting Input Values Section 4-1 Shifting Input Values 4-1-1 Shifting Input The input shift type matched to the sensor currently selected in the “input type” parameter is displayed. • A 2-point shift is used only for infrared temperature sensors. • With a 1-point shift, only the value set for the “Temperature input shift” parameter is applied to the entire temperature input range.

  • Page 56: Calculating Input Shift Values For Non-Contact Sensors

    4-1-2 Calculating Input Shift Values for Non-contact Sensors When a ES1A Infrared Temperature Sensor is connected to the E5ZN, an off- set of several degrees to several tens of degrees can occur due to internal impedance. Furthermore, if the rate of heat radiation of the control target is not 0.9, errors may occur.
  • Page 57 Shifting Input Values Section 4-1 3. After you have set the input shift values, check Controller readout (A) and control target temperature (B). If they are almost the same, the tempera- ture input shift value is correct. Controller readout (A) Upper limit temperature After shift Temperature readout...
  • Page 58 Shifting Input Values Section 4-1 4. Although the input shift was performed at two points, close to room tem- perature (ambient temperature) and near to the set point, select points close to each end of the sensor range to improve accuracy across the full range of sensor measurement.

  • Page 59: Alarm Hysteresis

    Alarm Hysteresis Section 4-2 Alarm Hysteresis • The hysteresis of alarm outputs when alarms are switched ON and OFF can be set as follows: Upper limit Lower limit alarm alarm Alarm hysteresis Alarm hysteresis Alarm value Alarm value • Alarm hysteresis is set independently for each alarm in the “alarm hyster- esis 1”...

  • Page 60: Close For Alarm/Open For Alarm

    4-2-3 Close for Alarm/Open for Alarm • When the E5ZN is set to “close for alarm,” the status of the alarm output function is normally open. When set to “open for alarm,” the status of the alarm output standby is normally closed.

  • Page 61: Setting Scaling Upper And Lower Limits (Analog Input)

    Setting Scaling Upper and Lower Limits (Analog Input) Section 4-3 Setting Scaling Upper and Lower Limits (Analog Input) 4-3-1 Analog Input • An analog voltage input can be scaled matched to the control application. • Scaling is set in the “scaling upper limit,” “scaling lower limit,” and “deci- mal point”...

  • Page 62: Executing Heating And Cooling Control

    Executing Heating and Cooling Control Section 4-4 Executing Heating and Cooling Control 4-4-1 Heating and Cooling Control Heating and cooling control operates when a cooling control output has been allocated to one of the outputs. For example, to set heating and cooling con- trol for ch1, allocate “cooling control output for ch1”...

  • Page 63: Using The Event Input

    When the event input is not used as a multi-SP function, the multi-SP function can be used via host communications or the E5ZN-SDL Setting Display Unit by setting the “multi-SP use” parameter. The following table shows the relationship between the three settings.
  • Page 64 Multi-SP Set point Set point 0 Set point 1 Note The set point can be switched independently for ch 1 and ch2. Using Key Operations The set point can be selected using the E5ZN-SDL Setting Display Unit.

  • Page 65: Setting The Sp Upper And Lower Limit Range

    Setting the SP Upper and Lower Limit Range Section 4-6 Setting the SP Upper and Lower Limit Range 4-6-1 Set Point Limits The upper and lower set point limits can be set within the input temperature setting range. Once the input set point limit is set, the set point is automatically returned to the upper or lower set point limit if it goes outside the set point limit range.

  • Page 66: Sp Ramp Function: Limiting Sp Change Rate

    SP Ramp Function: Limiting SP Change Rate Section 4-7 SP Ramp Function: Limiting SP Change Rate 4-7-1 SP Ramp The SP ramp function controls the rate of change of the set point. If a change larger than the rate of change is specified when the SP ramp function has been enable, changes in the set point will be limited as shown below.

  • Page 67: Key Protection

    There are three protect mechanisms: “Communications writing” prohibits set- ting changes from host communications, while “operation/adjustment protec- tion” and “initial setting/communications protection” limit settings from the E5ZN-SDL Setting Display Unit. Communications If the ‘communications writing” parameter is set to “0: Prohibited (off),”...
  • Page 68 Key Protection Section 4-8 Setting Change This protect level protects the setup from being changed by operating the keys on the front panel. Protection wtpt Set value Description Setup can be changed by key operation. Setup cannot be changed by key operation. (The protect level can be changed.) Default is OFF.

  • Page 69: Manual Mode

    Auto/Manual • If the “auto/manual” operation command is used by host communications to set “01: manual (ch1)” or “11: manual (ch2),” the E5ZN will operate in manual mode. • If ON/OFF control is selected, operation cannot be switched to manual mode.

  • Page 70: Manual Manipulated Variable

    Manual Mode Section 4-9 Relationship with RUN/ • The E5ZN can switch between auto and manual modes during both RUN (control operating) and STOP (control stopped). STOP • Even if the manual manipulated variable is set to STOP during output in manual mode, the operation status will not change and the output of the manual manipulated variable will continue.

  • Page 71: 4-10 Reading Temperatures For Multiple E5Zn Units

    Temperature Controller, making it difficult to obtain con- current data. The PV hold function can be used with the E5ZN to ensure that the data is concurrent to within 500 ms. To read present temperatures from all Temperature Controllers, the present value is read in order from Unit No.

  • Page 72: 4-11 Remote Pv Mode

    PV communications wait time.” This setting affects both channels. If the refresh cycle for data from the external sensor is longer than the “re- mote PV communications wait time,” the E5ZN will determine that the ex- ternal sensor has been disconnected, and an input error will occur.
  • Page 73 Remote PV Mode Section 4-11...
  • Page 74 SECTION 5 Communications Communication Protocols........5-1-1 CompoWay/F Communication Protocol.

  • Page 75: Communication Protocols

    FINS is a protocol for message communications between Controllers in OMRON FA networks. Note The program for communications is created on the host PC and E5ZN's parameters are monitored or set from the host PC. In this manual, descriptions of communications are given from the standpoint of the host PC.

  • Page 76: Data Format Structure

    If you want to broadcast a command, set the node number to “XX.” No response is given from the Temperature Controllers for broadcast commands. Sub-address Not used for E5ZN. Always set the sub-address to “00.” SID (Service ID) Not used for E5ZN. Always set the SID to “0.” FINS-mini...

  • Page 77: Response Frame

    The unit number of the Temperature Controller that returns the response is set in this field. Sub-address Not used for E5ZN. This field is always set to “00.” End code This field contains the result of execution of the corresponding com- mand frame.

  • Page 78: Structure Of Command/Response Text

    Structure of Command/Response Text Section 5-3 Structure of Command/Response Text The command/response text constitutes the main body of a command/ response frame. The structure of the command/response text is described below. Command Text The command text consists of the MRC (Main Request Code) and the SRC (Sub Request Code), followed by the required data.

  • Page 79: Variable Area

    The variable area is to read current process values or read/write parameter settings. The variable area is not used for operation commands or for reading Control- ler attributes. E5ZN Microcomputer Variable area Data reading/writing To specify the position of a variable in the variable area, use the variable type and address.

  • Page 80: Read From Variable Area

    Read start address Specify the read start address. Bit position Not used for E5ZN. Always set this item to “00.” No. of elements Set this item to the quantity of variables that are to be read (up to 6). Not required for multiple reads.

  • Page 81: Write To Variable Area

    Write start address Specify the write start address at this field. Bit position Not used for E5ZN. Always set this item to “00.” No. of elements Set this item to the quantity of variables that are to be written (up to 6). Not required for multiple writes.

  • Page 82: Operation Commands

    Specify the FINS-mini operation command (operation com- mand service). Command code Place a command code in this field. Related information Place information related to the operation command in this field. E5ZN Command Codes Command Command code Related information code “00” Communications writing “00”...
  • Page 83 Operation Commands Section 5-7 Response Response Text Response code (MRES/SRES) “30” “05” 4 bytes Item Description MRC/SRC This field contains the same value (“30”/“05”) as specified in the command text. Response code This field contains the execution result of the command. Response Codes Response Code name...

  • Page 84: Setting Areas

    Setting Areas Section 5-8 Setting Areas E5ZN Temperature Controllers can be set to either setting area 0 or setting area 1. Control operation is executed in setting area 0. In this state, you can perform operations that are permitted only during control or those that cause no prob- lems even if control is in progress.

  • Page 85: Commands And Responses

    Commands and Responses Section 5-9 Commands and Responses Various commands are provided for the application layer to implement ser- vices, such as variable area reading/writing and operation commands, sup- ported by the CompoWay/F communications protocol. This section describes the commands provided for the application layer. 5-9-1 Read Monitor Value Command...

  • Page 86: Read Setting Data

    Commands and Responses Section 5-9 5-9-2 Read Setting Data Variable No. of Command type Address position elements “01” “01” “00” “0001” Variable Address Setting data type Description “C1” “0000” to “0019” Setting data for setting area 0 “0100” to “0119” “C3”...

  • Page 87: Multiple Reads Of Monitor Values/Setting Data

    Commands and Responses Section 5-9 5-9-3 Multiple Reads of Monitor Values/Setting Data Command Variable Variable type Address position type Address position “01” “04” “00” “00” Variable type Address position “00” Variable Address Monitor value/setting data type Description “C0” “0000” to “0006” Monitor value “0100”...

  • Page 88: Write Protect Level Setting Data

    Commands and Responses Section 5-9 5-9-4 Write Protect Level Setting Data Variable Command No. of Data type Address position elements “01” “02” “C1” “00” “0001” Protect level setting data Address Setting data “0000” Operation/adjustment protection “0001” Initial setting/communication protec- tion “0002”...

  • Page 89: Write Setting Data

    Commands and Responses Section 5-9 5-9-5 Write Setting Data Command Variable No. of Data type Address position elements “01” “02” “00” “0001” Setting data (setting area 1) Variable Address Setting data type Description “C1” “0000” to “0019” Setting data for setting area 0 “0100”...

  • Page 90: Multiple Writes Of Setting Data

    Commands and Responses Section 5-9 5-9-6 Multiple Writes of Setting Data Variable Command Data type Address position “01” “13” “00” Setting data Variable type position Data Address “00” Setting data Variable Address Setting data type Description “C1” “0000” to “0019” Setting data for setting area 0 “0100”...

  • Page 91: Communications Writing

    Commands and Responses Section 5-9 5-9-7 Communications Writing Command Command Related code information “30” “05” Related information Description ”00” or “10” Communications writing prohibited ”01” or “11” Communications writing not pro- hibited This command enables/disables communications writing. It rewrites the setting for “communications writing.” If communications writing is disabled, operation commands for parameter rewriting, RUN/STOP, and other operations will be rejected.

  • Page 92: Multi-Sp

    Commands and Responses Section 5-9 5-9-9 Multi-SP Command Command Related code information “30” “05” “02” Related Contents information Selected SP “00” SP 0 “01” SP 1 ”10” SP 0 “11” SP 1 This command switches between set points that have been set in advance for SP 0 and SP1.

  • Page 93: Write Mode

    However, if the data is changed using the E5ZN-SDL Setting Display Unit key operations, it is written to internal non-volatile memory. Refer to 6-3 Setup Level Con- figuration and Front Panel Keys for information on operation/ adjustment level.

  • Page 94: 5-9-12 Ram Data Save

    Commands and Responses Section 5-9 5-9-12 RAM Data Save Command Related Command code information “30” “05” “05” ”00” or “10” This command writes operation/adjustment level setting data to internal non- volatile memory. Refer to 6.3 6-3 Setup Level Configuration and Front Panel Keys for information on operation/adjustment level.

  • Page 95: Move To Setting Area 1

    Commands and Responses Section 5-9 5-9-14 Move to Setting Area 1 Command Command Related code information “30” “05” “07” ”00” or “10” Use this command to move to setting area 1. Use this command in setting area 0. If the Temperature Controller is in setting area 1 when the command is received, the command is ignored.

  • Page 96: Auto/Manual

    Commands and Responses Section 5-9 5-9-16 Auto/Manual Command Command Related code information “30” “05” “09” Related Contents information Operation mode “00” Auto “01” Manual ”10” Auto “11” Manual This command selects automatic/manual operation. It can be used when the “PID/OnOff” parameter is set to PID. This command can be used in either setting area 0 or 1.

  • Page 97: 5-9-18 Parameter Initialize

    Buffer size “05” “03” “0000” “0048” Model name No. of control Control output Auxiliary Heater points output burnout alarm E5ZN-2QNH0 Pulse voltage Transistor out- Supported output put (sinking) E5ZN-2QPH0 Pulse voltage Transistor out- Supported output put (sourcing) E5ZN-2TNH0 Transistor out-...

  • Page 98: 5-9-20 Read Controller Status

    Commands and Responses Section 5-9 5-9-20 Read Controller Status Command “06” “01” This command reads the operation status of the Temperature Controller. The command can be used regardless of what state the Temperature Control- ler is in. Response Operation Related Response code status information...

  • Page 99: 5-9-21 Echoback Test

    Commands and Responses Section 5-9 5-9-21 Echoback Test Command Data to be tested “08” “01” 0 to 23 bytes This command performs an echoback test. The command can be used regardless of the state of the Temperature Con- troller. Data to be checked must not exceed the communications data length. Communication data length Description 7 bits...

  • Page 100: 5-10 Variable Area Map

    Variable Area Map Section 5-10 5-10 Variable Area Map The variable area of the Temperature Controller is mapped in terms of vari- able types and addresses as described below. Variable type C0: Read-only data for setting area 0, including process val- ues and status Variable type C1: Setting data for setting area 0...
  • Page 101 Variable Area Map Section 5-10 15 14 13 12 11 10 9 Bit position Value of bit Status Current exceeded Not detected Detected Current hold Refresh Hold Not detected Detected Indicate range exceeded. Input error Not detected Detected Heating output Cooling output HB output Alarm output 1...
  • Page 102 00000002H (2): Moving to initial setting/communications set- ting levels is disabled. 0002 Setting change protection 00000000H (0): OFF (Setting changes using the E5ZN-SDL enabled.) 00000001H (1): ON (Setting changes using the E5ZN-SDL disabled.) 0003 Set point...
  • Page 103 0102 Setting change protection 00000000H (0): OFF (Setting changes using E5ZN-SDL enabled.) 00000001H (1): ON (Setting changes using E5ZN-SDL dis- abled.) 0103 Set point Lower value of set point limit to upper value of set point limit 0104...
  • Page 104 Variable Area Map Section 5-10 Variable Address Setting data name Description type 0000 Input type Platinum-resistance thermometer input type: 00000000H (0): Pt (-200 to 850°C or -300 to 1,500°F) 00000001H (1): Pt (-199.9 to 500.0°C or -199.9 to 900.0°F) 00000002H (2): Pt (0.0 to 100°C or 0.0 to 210.0°F) 00000003H (3): JPt (-199.9 to 500.0°C or -199.9 to 900.0°F) 00000004H (4): JPt (0.0 to 100.0°C or 0.0 to 210.0°F) Thermocouple input type:...
  • Page 105 Variable Area Map Section 5-10 Variable Address Setting data name Description type 000B Alarm 1 type 00000000H (0): No alarm function 00000001H (1): Upper and lower limit alarm 00000002H (2): Upper limit alarm 00000003H (3): Lower limit alarm 00000004H (4): Upper and lower limit range alarm 00000005H (5): Upper and lower limit alarm with standby...
  • Page 106 Variable Area Map Section 5-10 Variable Address Setting data name Description type 001A SP ramp setting 00000000H (0): OFF 00000001H to 0000270FH (1 to 9,999) 001B Standby sequence 00000000H (0): Condition A restart 00000001H (1): Condition B 001C Alarm 1 open for alarm 00000000H (0): Closed 00000001H (1): Open 001D...
  • Page 107 Variable Area Map Section 5-10 Variable Address Setting data name Description type 0100 Input type Platinum-resistance thermometer input type: 00000000H (0): Pt (-200 to 850°C or -300 to 1,500°F) 00000001H (1): Pt (-199.9 to 500.0°C or -199.9 to 900.0°F) 00000002H (2): Pt (0.0 to 100°C or 0.0 to 210.0°F) 00000003H (3): JPt (-199.9 to 500.0°C or -199.9 to 900.0°F) 00000004H (4): JPt (0.0 to 100.0°C or 0.0 to 210.0°F) Thermocouple input type:...
  • Page 108 Variable Area Map Section 5-10 Variable Address Setting data name Description type 010B Alarm 1 type 00000000H (0): No alarm function 00000001H (1): upper and lower limit alarm 00000002H (2): Upper limit alarm 00000003H (3): Lower limit alarm 00000004H (4): upper and lower limit range alarm 00000005H (5): upper and lower limit alarm with standby...
  • Page 109 Variable Area Map Section 5-10 Variable Address Setting data name Description type 011A SP ramp setting 00000000H (0): OFF 00000001H to 0000270FH (1 to 9,999) 011B Standby sequence 00000000H (0): Condition A restart 00000001H (1): Condition B 011C Alarm 1 open for alarm 00000000H (0): Closed 00000001H (1): Open 011D...
  • Page 110 Variable Area Map Section 5-10 Variable Address Setting data name Description type 0000 Remote PV mode 00000000H (0): OFF (normal mode) 00000001H (1): ON (remote PV mode) 0001 Remote PV communica- 00000000H to 0000270F (0 to 9,999) ms tions wait time 0100 Remote PV mode 00000000H (0): OFF (normal mode)
  • Page 111 Variable Area Map Section 5-10...

  • Page 112: Using The E5Zn-Sdl

    SECTION 6 Using the E5ZN-SDL Introduction ...........

  • Page 113: Introduction

    Introduction Section 6-1 Introduction 6-1-1 Outline The E5ZN-SDL Setting Display Unit is used to set and display parameters for E5ZN Temperature Controllers. Using the E5ZN-SDL simplifies the initial settings and maintenance of the E5ZN. 6-1-2 Preparation The E5ZN-SDL uses serial communications to display the settings for the E5ZN Temperature Controller.

  • Page 114: System Configuration

    • Keep the total cable length to 500m maximum. • Attach a terminator to both ends of the transmission path. Note Communications with the E5ZN-SDL will be cut if the E5ZN-2 connection to the E5ZN- SCT24S-500 is broken The E5ZN Temperature Controller and the E5ZN-SDL are connected by serial communications.

  • Page 115: Names Of Parts On The Front Panel

    CH Key 6-2-2 Display No.1 Display Displays the type of process value or parameter for the E5ZN Temperature Controller. No. 2 Display Displays the process value, read value for the parameter, and the input value when settings are changed for the E5ZN Temperature Controller.

  • Page 116: Using The Keys

    Alternatively, the display moves back one setting item. Level Key + Mode Key This key combination sets the E5ZN to the “protect level.” For details on the protect level, refer to 6-3 Setup Level Configuration and Front Panel Keys .

  • Page 117: Setup Level Configuration And Front Panel Keys

    Setup Level Configuration and Front Panel Keys Parameters are divided into groups called levels. Each of the set values (setup items) in these levels are called a parameter. The parameters on the E5ZN are divided into the following seven levels: Power ON Normal mode...
  • Page 118 Operation Level • This level is initially displayed when you turn ON the power to the E5ZN. You can move to the protect level, initial setting level, and adjustment level from this level.

  • Page 119: Initial Setup Examples

    DIP switches. These hardware settings are now set using the setup menus of the E5ZN-SDL. The Level and Mode Keys are used to switch between setup menus, and the amount of time that you hold the keys down determines which setup menu you move to.
  • Page 120 Power ON Control method:ON/OFF control Alarm type: 2 (upper limit) Alarm value 1: 20°C Operation level Set point: 100°C °c E5ZN Unit No.:3 Process Channel No.: 1 value/set point Match UNIT/CH using the UNIT and CH Keys. Set unit No. °c Set channel No.
  • Page 121 Initial Setup Examples Section 6-4 Typical Example 2 Input type: 4 (T thermocouple -200 to 400°C) E5ZN unit No.:1 Control method:PID control Channel: Calculate PID constants by autotuning. Alarm type: 2 (upper limit) Alarm value 1:30°C Set point: 150°C Power ON...

  • Page 122: Using Copy Mode

    Downloading is not possible in the following circumstances. “Down” will not be displayed when download is not possible. • When a E5ZN has been added or deleted since the upload. • When the same number of units are connected as when the upload was exe- cuted, but when the unit numbers are different.

  • Page 123: List Of Parameters

    List of Parameters Section 6-6 List of Parameters Communications setting level Mode sbit Level Key for less than 1 s Mode prty eUen Mode sdwt Level Key for 1 s min. Level Key Advanced function Initial setting level setting level Level Key Same for ch1 and ch2 Same for ch1 and ch2...
  • Page 124 List of Parameters Section 6-6 Protect level Copy mode oapt Mode Automatic return or COPY Key for Level + Mode Level + Mode icpt COPY Key 1 s or less Keys 1 s min. Keys 3 s min. 1 s min. Mode wtpt Power ON...
  • Page 125 List of Parameters Section 6-6...

  • Page 126: Parameters

    SECTION 7 Parameters Conventions Used in this Chapter ........Protect Level .
  • Page 127 7-6-2 Number of Multi-SP Uses (eU-m) ......7-6-3 Event Input Assignment (eU) ......7-6-4 Multi-SP Uses (mspu) .

  • Page 128: Conventions Used In This Chapter

    Describes related parameters and items. Display Conditions for Related Parameters The parameters are displayed in the display section of the E5ZN-SDL Setting Display Unit only when the condition for use shown at the top of the section describing the parameter are met. Protected parameters are not be displayed regardless, although the parameters themselves will be enabled.

  • Page 129: Protect Level

    Protect Level Section 7-2 Protect Level oapt oapt) oapt 7-2-1 Operation/Adjustment Protection (oapt icpt icpt icpt) Initial Setting/Communications Protection (icpt wtpt) wtpt wtpt Setting Change Protection (wtpt Function These parameters specify the range of parameters to be protected. The shaded areas indicate the defaults. Settings Operation/Adjustment Protection The following table shows the relationship between set values and the range...

  • Page 130: Operation Level

    Operation Level Section 7-3 Operation Level 7-3-1 Condition: The “additional PV display” parameter must be set to ON. Function The process value is displayed on the No.1 display, and nothing is displayed (blank) on the No. 2 display. Communications Variable type Address 0000 0100...

  • Page 131: Multi-Sp (Set Point 0 To 1) (M-Sp)

    Operation Level Section 7-3 m-sp) m-sp m-sp 7-3-3 Multi-SP (Set Point 0 to 1) (m-sp Condition: The “multi-SP uses” parameter must be set to ON. Function Multi-SP allows you to set up to two set points (SP0 to 1) in the adjustment level.

  • Page 132: Run/Stop (R-S)

    Section 7-3 Monitoring Monitoring range Unit 00000000H to 00000226 H (0.0 to 55.0) When the current exceeds 55.0A in the E5ZN-SDL Setting Display Unit, “ffff” is displayed. See Also • Related Parameters “Heater burnout detection” (adjustment level) (page 122) “Heater burnout use” (advanced function setting level) (page 140)

  • Page 133: Alarm Upper Limit Value 1 (Al 1H), Alarm Lower Limit Value 1 (Al 1L)

    Operation Level Section 7-3 Settings Setting range Unit Default FFFFF831H to 00000270FH (-1999 to 9999) The alarm type must be set to other than no alarm or upper and lower limit alarm (alarms 1 and 2 only). See Also • Related Parameters “Input type”...

  • Page 134: Alarm Upper Limit Value 2 (Al2H), Alarm Lower Limit Alarm Value 2 (Al2L)

    Operation Level Section 7-3 al2h) al2h al2h 7-3-9 Alarm Upper Limit Value 2 (al2h al2l) al2l al2l Alarm Lower Limit Alarm Value 2 (al2l Condition: Alarm 2 type must be set to upper and lower limits, upper and lower limit range, or upper and lower limit alarm with standby sequence. These parameters independently set the upper and lower limit alarm values when the mode for setting the upper and lower limits is selected for alarm 2 type.

  • Page 135: Mv Monitor For Cooling (C-O)

    Operation Level Section 7-3 c-o) 7-3-11 MV Monitor for Cooling (c-o The control must be heating and cooling control. This parameter is for monitoring the MV on the cooling side during operation. Function During heating and cooling control, the MV on the cooling side is monitored. Communications Variable type Address...

  • Page 136: Adjustment Level

    7-4-2 Communications Writing (cmwt Function This parameter enables/disables writing of parameters to the E5ZN from the host (e.g., personal computer) by communications. Communications Use the “communications writing” operation command. Refer to page 76 for information. Set this parameter to “on” to enable writing and to “ off ” to disable writing.

  • Page 137: Heater Burnout Detection (Hb)

    0103 Monitoring Monitoring range Unit 00000000H to 00000226 H (0.0 to 55.0) “ffff” is displayed when 55.0A is exceeded in the E5ZN-SDL Setting Display Unit. See Also • Related Parameters “Heater burnout detection” (adjustment level) (page 122) “HBA used” (advanced function setting level) (page 140)

  • Page 138: Set Point 0 (Sp-0), Set Point 1 (Sp-1)

    Adjustment Level Section 7-4 sp-0) sp-0 sp-0 7-4-5 Set Point 0 (sp-0 sp-1) sp-1 sp-1 Set Point 1 (sp-1 Condition: The “number of multi-SP uses” parameter must be set to either 1 or 2, and the “multi-SP uses” parameter must be set to ON. These parameters set the set points when the multi-SP function is used.

  • Page 139: Temperature Input Shift Value (Insl)

    Adjustment Level Section 7-4 See Also • Related Parameter “Input type” (initial setting level) (page 128) insh) insh insh 7-4-7 Upper Limit Temperature Input Shift Value (insh insl insl) insl Lower Limit Temperature Input Shift Value (insl Condition: The “additional temperature input display” parameter must be set to ON and the “input type”...

  • Page 140: Cooling Coefficient (C-Sc)

    Adjustment Level Section 7-4 that is proportional to a predicted process output to cor- rect for future error. Communications Setting Variable type Address Proportional band 0012 0112 Integral time 0013 0113 Derivative time 0014 0114 Settings Setting Setting range Unit Default Proportional band 00000001H to 0000270FH (0.1 to 999.9) Integral time...

  • Page 141: Dead Band (C-Db)

    Adjustment Level Section 7-4 c-db) c-db c-db 7-4-10 Dead Band (c-db Condition: The control system must be heating and cooling control. This parameter sets the output dead band width in a heating and cooling con- trol system. A negative setting sets an overlap band. Function This parameter sets an area in which the control output is 0 centering around the set point in a heating and cooling control system.

  • Page 142: Heating Hysteresis (Hys), Cooling Hysteresis (Chys)

    Adjustment Level Section 7-4 hys) 7-4-12 Heating Hysteresis (hys chys) chys chys Cooling Hysteresis (chys Condition: The control must be ON/OFF control. These parameters set the hysteresis for ensuring stable operation at ON/OFF switching. Function • In a standard control, use the “heating hysteresis” parameter. The “cool- ing hysteresis”...

  • Page 143: Initial Setting Level

    Initial Setting Level Section 7-5 Initial Setting Level in-t in-t in-t) 7-5-1 Input Type (in-t Function • This parameter sets the sensor type using a corresponding code. • When this parameter is changed, the set point limiter is changed to the default.

  • Page 144: Decimal Point (Dp)

    Initial Setting Level Section 7-5 in-h) in-h in-h 7-5-2 Scaling Upper Limit (in-h in-l) in-l in-l Scaling Lower Limit (in-l dp dp Decimal Point (dp Condition: The input type must be set to analog input. Function • These parameters can be used when a voltage input is selected as the input type.

  • Page 145: Set Point Upper Limit (Sl-H), Set Point Lower Limit (Sl-L)

    Initial Setting Level Section 7-5 See Also • Related Parameter “Input type” (initial setting level) (page 128) sl-h) sl-h sl-h 7-5-4 Set Point Upper Limit (sl-h sl-l sl-l) sl-l Set Point Lower Limit (sl-l Function • These parameters set the upper and lower limits for the SP setting. The SP can be set within the range defined by the upper and lower limit set values in the “set point upper limit”...

  • Page 146: Heating Control Period (Cp), Cooling Control Period (C-Cp)

    Initial Setting Level Section 7-5 Settings Settings range Unit Default 00000000H to00000001H 1: 2-PID 0: ON/OFF (onof) 1: 2-PID (pid) See Also • Related Parameters “Manual reset” “Heating hysteresis” “Cooling hysteresis” (adjustment level) (page 126) cp cp 7-5-6 Heating Control Period (cp c-cp) c-cp c-cp...

  • Page 147: Alarm 1 Type (Alt1), Alarm 2 Type (Alt2), Alarm 3 Type (Alt3)

    Initial Setting Level Section 7-5 Settings Settings range Unit Default 00000000H to00000001H 0: Reverse operation 0: Reverse operation (or-r) 1: Direct operation (or-d) See Also 3-4 Setting Output Specifications (page 25) alt1 alt1) alt1 7-5-8 Alarm 1 Type (alt1 alt2 alt2) alt2 Alarm 2 Type (alt2...

  • Page 148: Control Output 2 Assignment (Out2)

    Initial Setting Level Section 7-5 Communications Variable type Address Shared 000E or 010E Settings Settings range Unit Default 00000000H (0): Heating control output for ch1 0: ch1 heating control output 00000001H (1): Cooling control output for heating/cooling control for ch1 00000002H (2): Alarm 1 and HB alarm OR output for ch1 00000003H (3):...

  • Page 149: Auxiliary Output 2 Assignment (Sub2)

    7-5-13 Operation after Power ON (cont Function • This parameter selects either “stop” or “continue” for the E5ZN operation after the power has been turned ON. • The operation after a software reset or when moving from initial setting level to operation level depends on the “stop”...

  • Page 150: Advanced Function Setting Level

    This parameter returns all settings to their defaults. Communications Use the “parameter initialize” operation command. Refer to page 82 for infor- mation. Example of Use ON (on): Initializes all parameters. OFF (off): Turns OFF the E5ZN after returning parameter settings to their defaults. eU-m) eU-m eU-m 7-6-2...

  • Page 151: Multi-Sp Uses (Mspu)

    Condition: The “number of multi-SP uses” parameter must be set to 0. Function • When set to ON, this parameter enables switching between SP0 and SP1 by using communications command or E5ZN-SDL Setting Display Unit key operations. • Setting changes to this parameter must be enabled by executing a soft- ware reset or by turning ON the power again.

  • Page 152: Standby Sequence Reset Method (Rest)

    Advanced Function Setting Level Section 7-6 Communications Variable type Address 001A 011A Settings Setting range Unit Default 00000000H to 00000271H (0 to 9999) EU/min. 0: OFF 0: OFF See Also • Related Parameters “Input type” (initial setting level) (page 128) “Scaling upper limit”...

  • Page 153: Alarm 3 Open For Alarm (Al3N)

    • These parameters set the output states for alarm 1, 2, and 3. • When the E5ZN is set to “close for alarm,” the alarm output is normally open. When set to “open for alarm,” the alarm output is normally closed.

  • Page 154: Alarm 1 Hysteresis (Alh1), Alarm 2 Hysteresis (Alh2), Alarm 3 Hysteresis (Alh3)

    Advanced Function Setting Level Section 7-6 See Also • Related Parameters “Alarm value 1 to 3” (operation level) (page 117) “Upper limit alarm value 1” “Lower limit alarm value 1” (operation level) (page 118) ”Upper limit alarm value 2” “Lower limit alarm value 2” (opera- tion level) (page 118) “Alarm 1 to 3 type”...

  • Page 155: Hba Used (Hbu)

    Advanced Function Setting Level Section 7-6 hbu) 7-6-9 HBA Used (hbu Function • This parameter sets use of the heater burnout alarm. • Setting changes to “HBA used” must be enabled by executing a software reset or by turning ON the power again. Communications Variable type Address...

  • Page 156: Mv Upper Limit (Ol-H), Mv Lower Limit (Ol-L)

    • The “MV upper limit” and “MV lower limit” parameters set the upper and lower limits of the manipulated variable. When the manipulated variable calculated by the E5ZN exceeds the upper or lower limit value, the upper or lower limit will be used as the output level.

  • Page 157: A (Alfa)

    Advanced Function Setting Level Section 7-6 Communications Setting Variable type Address MV upper limit value 0026 0126 MV lower limit value 0027 0127 Settings Setting Setting range Unit Default MV upper For Standard Control: 105.0 limit value (MV lower limit + 1)H to 0000041AH (MV lower limit + 0.1 to 105.0) For Heating and Cooling Control: 105.0...

  • Page 158: Additional Pv Display (Puad)

    • This parameter enables displaying only the PV. It is added to the top of the operation level of the E5ZN-SDL Setting Display Unit. It is used to give the option of displaying the PV and SP, or just the PV only.

  • Page 159: Cold Junction Compensation Method (Cjc)

    Advanced Function Setting Level Section 7-6 Communications Setting Variable type Address Alarm 1 latch 002B 012B Alarm 2 latch 002C 012C Alarm 3 latch 002D 012D Settings Setting Setting range Unit Default Alarm 1 latch 00000000H to 00000001H 0: OFF Alarm 2 latch 0: OFF (off) Alarm 3 latch...

  • Page 160: Communications Setting Level

    Communications Setting Level Section 7-7 Communications Setting Level len) 7-7-1 Communications Data Length (len Function Setting changes to “communications data length” must be enabled by execut- ing a software reset or by turning ON the power again. Communications Variable type Address Shared 0013 or 0113...

  • Page 161: Communications Response Wait Time (Sdwt)

    Communications Setting Level Section 7-7 sdwt) sdwt sdwt 7-7-4 Communications Response Wait Time (sdwt Function Setting changes to “communications response wait time” must be enabled by executing a software reset or by turning ON the power again. Communications Variable type Address Shared 0016 or 0116...

  • Page 162: Troubleshooting

    SECTION 8 Troubleshooting This section describes the troubleshooting procedure and possible errors and remedies when the E5ZN is not operating properly. When performing troubleshooting, follow the order in which information is provided in this section. Troubleshooting Procedure ........

  • Page 163: Troubleshooting Procedure

    Troubleshooting Procedure Section 8-1 Troubleshooting Procedure If the E5ZN has an error, refer to the following items to find the possible cause of the error and take corrective measures. 1,2,3... 1. Indicators Check the operating status of the E5ZN using the indicators.

  • Page 164: Communications Errors

    Communications Errors Communications Not Possible or No Response Probable cause Remedy Communications Baud rate of the E5ZN is different from that of the Set the same rate. conditions host. Communications method of the E5ZN is different Match the communications method of the E5ZN from that of the host.

  • Page 165: Temperature Sensing Errors

    E5ZN. the metal of the thermocouple or that of the com- pensating conductors. A screw of the terminal block of the E5ZN is loos- Tighten the screw. ened and improper contact is resulting. Leads or compensating conductors of a thermo- •...
  • Page 166 1. Connect a 100- W resistor between the A and B temperature sensor input 1,2,3... terminals and short-circuit the B terminals. 2. If the temperature sensed by the E5ZN is 0.0 ° C or 32.0 ° F, the E5ZN is op- erating normally. Thermocouple 1,2,3...

  • Page 167: Temperature Control Errors

    E5ZN. Polarity or wiring of a load is incorrect. Correct the wiring of the load. A screw of the terminal block of the E5ZN is loos- Tighten the screw. ened and improper contact is resulting. Power is not supplied to heaters.
  • Page 168 P constant can be allowed. • Execute autotuning. E5ZN has a short integral time or small I constant. • Increase the I constant keeping within the range where the response delay caused by the I constant can be allowed.

  • Page 169: Output Errors

    When designating multi-SP with event input, the Set the E5ZN so that the ON or OFF status of the ON or OFF status of the input is not kept on hold. input is kept on hold while designating the multi- SP with the event input.

  • Page 170: Hb Alarm Errors

    ON for 190 ms or more. HB alarm is not set in output allocations. Set “Alarm 1 and HAB OR output” in output assignments. Heaters are turned ON after the E5ZN starts con- Turn ON the heaters before starting the E5ZN trol operation. control operation.
  • Page 171 HB Alarm Errors Section 8-6...

  • Page 172: A Specifications

    ON: Max. residual voltage 1.5 V, OFF: Max. leakage current 0.1 mA No. of input/control 2 input points, 2 control points points Setting method Communications or E5ZN-SDL Setting Display Unit Control method 2-PID or ON/OFF control Other functions Heater burnout alarm function, multi-SP with event input or RUN/STOP selection Ambient tempera- -10 to 55°C (with no condensation or icing)

  • Page 173: Specifications

    Specifications Appendix A Characteristics Indication accuracy Thermocouple: (±0.5% of indication value or ±1°C, whichever is greater) ±1 digit max. (See note.) Platinum resistance thermometer: (±0.5% of indication value or ±1°C, whichever is greater) ±1 digit max. Analog input: ±0.5%FS±1 digit max. CT input: ±0.5%FS±1 digit max.
  • Page 174 1000 VAC (for 1 minute) Vibration resistance 50 Hz 98m/s {10G} Weight Approx. 11.5 g Approx. 50 g Accessory None Armature (2) Plug (2) Note The maximum continuous current of the E5ZN is 50 A. External Dimensions (Unit: mm) E54-CT1 10.5 E54-CT3 2.36 dia.
  • Page 175 Specifications Appendix A...

  • Page 176: Error Displays

    Action First, turn the power OFF then back ON again. If the display remains the same, the E5ZN must be replaced. If the display is restored, then a probable cause can be electrical noise affecting the control system. Check for electrical noise.
  • Page 177 • The connection cable is disconnected. • The power supply to the E5ZN-SDL has been turned OFF while in copy mode. • A memory error has occurred in the E5ZN. The control output and alarm outputs will be OFF for the E5ZN generating the error.

  • Page 178: Sensor Input Setting Ranges/Control Ranges

    Appendix C Sensor Input Setting Ranges/Control Ranges Sensor Input Name Input temperature setting range Control range type value -200 to 850 °C or -300 to 1,500 °F -220 to 870 °C or -340 to 1,540 °F Platinum Plati- Pt100 resis- -199.9 to 500.0 °C or -199.9 to 900.0 °F -219.9 to 520.0 °C or -239.9 to 940.0 °F tance resis-...
  • Page 179 Sensor Input Setting Ranges/Control Ranges Appendix C...

  • Page 180: Ascii Table

    Appendix D ASCII Table Upper Lower SPACE ‘ “ & ‘ < >...
  • Page 181 ASCII Table Appendix D...

  • Page 182: Index

    Index Symbols AT execute/cancel, AT execute/stop, °C/°F, auto/manual, °C/°F selection, automatic mode, autotuning, Numerics auxiliary output, auxiliary output 1 allocation, 1-point shif, auxiliary output 2 allocation, 2-PID control, auxiliary outputs, 2-point shift, 2-point temperature input shift, 3-position control, baud rate, BCC, α, additional PV display,...
  • Page 183 Index dead band, initial setting level, decimal point, initial setting/communications protection, derivative time, input digital filter, DIN track, input type, direct operation, integral time, direct/reverse operation, download, levels, list of parameters, echoback test, lower limit alarm, end code, lower limit temperature input shift value, end plates, lower limit values, error displays,...
  • Page 184 Index operation commands, set point lower limit, operation display, set point upper limit, operation level, setting change protection, operation/adjustment protection, setting display unit, output allocations, setting switches, shifting input, SID, side connector, parameter initialize, software reset, PID constants, solderless terminals, PID parameters, SP ramp, PID/OnOff,...
  • Page 185 Index wiring, write mode, write protect level setting data, write setting data, write to multiple variable area, write to variable area,...

  • Page 186: Revision History

    Revision History A manual revision code appears as a suffix to the catalog number on the front cover of the manual. Cat. No. H113-E1-1 Revision The following table outlines the changes made to the manual during each revision. Page numbers refer to the previous version.
  • Page 187 Authorized Distributor: Cat. No. H113-E1-1 Note: Specifications subject to change without notice Printed in Japan 0101-1M (0101) (A)

Table of Contents
