Extron electronics IPA T IPA User Manual

Specifications

Data rate ........................................ 10/100Base-T, half/full duplex with
Power
Input .................................. 100VAC to 240VAC, 50/60 Hz, 15 watts,
Output ............................... IEEE 802.3af compliant
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
Rack mount .................................. Yes, with optional 1U rack shelf, part
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.7" H x 2.2" W x 3.0" D (1U high, one-
Product weight ............................. 0.5 lbs (0.2 kg)
Shipping weight ........................... 1 lbs (1 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International
Listings .......................................... UL, CUL
Compliances ................................. FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
Included Parts
Part Description
IPA T IPA In-Circuit Power Adapter
User's guide
Extron Electronics, USA Extron Electronics, Europe
1230 South Lewis Street Beeldschermweg 6C
Anaheim, CA 92805 3821 AH Amersfoort
USA The Netherlands
714.491.1500 +31.33.453.4040
www.extron.com Fax 714.491.1517 Fax +31.33.453.4050
© 2003 Extron Electronics. All rights reserved.
autodetect
external, autoswitchable; to 48VDC, 0.3 A
power supply
10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
#60-190-01, or the VersaTools rack shelf,
part #60-190-20;
also under-furniture mountable with
optional brackets #70-212-01
or projector mountable with optional
brackets #70-217-01/70-077-04
eighth rack width)
4.3 cm H x 5.6 cm W x 7.6 cm D
(Depth excludes connectors.)
Safe Transit Association)
Part Number
60-545-01
Extron Electronics, Asia Extron Electronics, Japan
135 Joo Seng Road, #04-01 Daisan DMJ Building 6F
PM Industrial Building 3-9-1 Kudan Minami
Singapore 368363 Chiyoda-ku, Tokyo 102-0074 Japan
+65.6383.4400 +81.3.3511.7655
Fax +65.6383.4664 Fax +81.3.3511.7656
User's Guide
IPA T IPA
In-Circuit Power Adapter
68-739-01 Rev. B
Printed in the USA
09 03
