CDD-880 Multi Receiver Router
Ethernet Management
For each operating demodulator, note the following:
Pkts Rx – Packets received.
UC Pkts Rx – Unicast packets received.
MC Pkts Rx – Multicast packets received.
Current (Mbps) – Most recent symbol rate (in megabits per second).
Maximum (Mbps) – Peak symbol rate (in megabits per second).
(Satellite Rx Statistics)
Satellite RX Overrun Errors – Packets dropped after being combined from all 12 demods
(aggregate data rate too high).
Satellite RX Oversized Errors – Packets dropped because size is greater than 2047 bytes.
Satellite RX Undersized Errors – Packets dropped because size is smaller than WAN frame
(usually due to channel noise).
On a per-demod (i.e., Demod #1 through Demod #12) basis:
Satellite RX Frame CRC Errors – Streamline decoder CRC error – packet discarded.
Satellite RX Packets Dropped – Packets dropped before being combined into aggregate path
(aggregate data rate too high).
