Quick Start — IPL T S Series
Step 1
Turn power off and disconnect the device from
its power source.
Step 2
Mount the IPL T S Series unit:
• on a projector
Projector
Mounting
Mounting
Bolt
Bracket
Digital Projector
Projector Mount
• under a desk
Furniture Mount
IP L
T S
2
R
C O
M
1
2
10
0
LI N
K
A C
T
• or on a rack
IP L
T S2
R
CO
M
1
2
®
10
0
IP L
LI NK
T S2
AC
T
R
CO
M
1
1U Rack Shelf
2
1/4 Rack Width False Front
Face Plate
IP L
T S2
R
CO
M
1
Use 2 mounting holes on
2
opposite corners.
Step 3
Connect a local area network (LAN) cable from a
PC, hub, or router to the IPL T S Series unit.
00-05-A6-00-30-06
LAN
POWER
12V
COM3
COM4
COM5
COM6
.5A MAX
TX RX
TX RX
TX RX
TX RX
IPL T S6 Ethernet Control Interface
Rack Mount
®
10
0
LI NK
AC
T
®
10
0
LI NK
AC
T
(2) 4-40 x 3/16" Screws
COM
1
2
COM
Step 4
Connect RS-232 cables from the IPL T S Series
unit to the audio/video (A/V) devices.
Step 5
Connect power cords and apply power in the
following order:
• output devices (projectors, monitors,
speakers)
• IPL T S Series device
• PC or serial controller
• input devices (DSS, cable boxes, and so on)
Step 6
Configure the IPL T S Series device. See chapter
3 for more information.
Step 7
Test the IPL T S Series device via its default Web
pages. See chapter 4 for more information.
N
L A
Extron
1
M
C O
V
M A
X
IPL T S1
12
.5 A
Ethernet Control
RS-232
Interface
Plasma Display
L A
N
Extron
1
M
C O
V
X
12
M A
IPL T S1
.5 A
Ethernet Control
RS-232
Interface
Plasma Display
Typical IPL T S Series configuration
IPL T S Series • Quick Start
