System Status page
The System Status page is a read-only page that provides the following status
information:
• System Description — Model, Description, Part Number, Firmware, Date,
and Time
• IP Settings — Unit Name, DHCP setting, IP Address, Gateway IP Address,
Subnet Mask, and MAC Address
• Serial Port Settings — For each port: Port number, Port Type, Baud Rate, Data
Bits, Parity, Stop Bits, and Flow Control
Figure 3-11 — System Status screen
Configuration page
The Configuration page has five sub-pages, which are described below.
System Settings
The System Settings page grants access to view and change:
• IP Settings
• Date/Time Settings
IPL T S Series • Connection and Configuration 3-11
