Introduction
About This Manual
This manual describes the function, installation, configuration, and operation of the
Extron IPL T S Series interface devices which are shown below.
About the IPL T S Series Interface
The Extron IPL T S Series interface devices integrate network connectivity into
audio/video (A/V) systems. Installing an IPL T S Series interface into an
A/V network gives users the ability to remotely monitor and control projectors,
flat-panel displays, switchers, and other serially-controlled devices.
IPL T S1 control interface
•
•
•
•
•
IPL T S2 control interface
•
•
•
•
IPL T S4 control interface
•
•
•
•
IPL T S6 control interface
•
•
•
•
1-2 IPL T S Series • Introduction
PN 60-801-81
One bidrectional RS-232 serial port
7.25 MB of available flash memory
Low-profile form factor
1.0 inch H x 4.3 inches W x 3.0 inches D
(2.5 cm x 10.9 cm x 7.6 cm)
PN 60-544-81
Two bidrectional RS-232, RS-422,
or RS-485 serial ports
7.25 MB of available flash memory
1.7 inches H x 4.3 inches W x 3.0 inches D
(4.3 cm x 10.9 cm x 7.6 cm)
PN 60-544-83
Four bidirectional RS-232, RS-422,
or RS-485 serial ports
7.25 MB of available flash memory
1.7 inches H x 4.3 inches W x 3.0 inches D
(4.3 cm x 10.9 cm x 7.6 cm)
PN 60-544-84
Six bidirectional RS-232, RS-422,
or RS-485 serial ports
7.25 MB of available flash memory
1.7 inches H x 4.3 inches W x 3.0 inches D
(4.3 cm x 10.9 cm x 7.6 cm)
