10/100BASE-TX Ethernet over Coax Extender User's Manual
Extend one Ethernet channel over existing coaxial
cable.
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S.
Customer
call 724-746-5500) • FREE technical support 24 hours a day, 7 days
Support
a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address:
Information
Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 •
Web site: www.blackbox.com • E-mail: info@blackbox.com
BLACK BOX
LBNC300A
LBNC300AE
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Black Box LBNC300A
Summary of Contents for Black Box LBNC300A
-
Page 1: Black Box
724-746-5500) • FREE technical support 24 hours a day, 7 days Support a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address: Information Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 • Web site: www.blackbox.com • E-mail: info@blackbox.com... -
Page 2: Federal Communications Commission
10/100BASE-TX Ethernet over Coax Extender FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause inter ference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when the equipment... -
Page 3: Instrucciones De Seguridad
NOM Statement Normas Oficiales Mexicanas (NOM)Electrical Safety Statement INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura. - Page 4 10/100BASE-TX Ethernet over Coax Extender 12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada. 13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
-
Page 5: Trademarks Used In This Manual
Trademarks Used in this Manual Trademarks Used in this Manual Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners. -
Page 6: Table Of Contents
10/100BASE-TX Ethernet over Coax Extender Table of Contents Chapter Page 1. Specifications ......................7 2. Overview ......................8 2.1 Introduction ....................8 2.2 Features ......................8 2.3 What’s Included ................... 8 2.4 Hardware Description .................. 9 2.4.1 Front Panel ..................9 2.4.2 Back Panel .................. -
Page 7: Specifications
Storage: -4 to +158° F (-20 to +70° C) Operating Humidity: 5 to 95%, noncondensing Power: LBNC300A: 100–240 VAC, 50–60 Hz, 12 VDC, 0.5 A, 6 W max.; LBNC300AE: 100–240 VAC, 50–60 Hz, 12 VDC, 1A, 12 W max. Size: 0.94"H x 3.2"W x 4.3"D (2.4 x 8 x 10.9 cm) Weight: 0.3 lb. -
Page 8: Overview
10/100BASE-TX Ethernet over Coax Extender 2. Overview 2.1 Introduction The LBNC300A provides one channel for Ethernet over existing coaxial cabe. Use it as a standalone device or with a chassis. 2.2 Features • Complies with EN61000-6-2 & EN61000-6-3 EMC generic standard immunity for Industrial environment. -
Page 9: Hardware Description
Chapter 2: Overview 2.4 Hardware Description 2.4.1 Front Panel Figure 2-1 shows the Ethernet Extender’s front panel. Table 2-1 describes its components. 3 6 8 Figure 2-1. Front panel. Table 2-1. Front-panel components. Number Component State Description RJ-45 port 10/100 Ethernet connection BNC connector Line connection Pwr LED... -
Page 10: Back Panel
10/100BASE-TX Ethernet over Coax Extender Table 2-1 (continued). Front-panel components. Number Component State Description Rmt LED Steady Device operating in remote mode Loc LED Steady Device operating in local mode Err LED Steady Error occurred Lnk LED Steady A valid connection is established 2.4.2 Back Panel Figure 2-2 shows the extender’s back panel. -
Page 11: Top Panel
Chapter 2: Overview 2.4.3 Top Panel Figure 2-3 shows the top panel. Table 2-3 describes its indicators. Figure 2-3. Top panel. LEDs 1-5 on the top panel indicate the extender’s speeds. See Table 2-3 for details. Units automatically select the fastest speed for your connection. Table 2-3. -
Page 12: Installation
10/100BASE-TX Ethernet over Coax Extender 3. Installation 3.1 Selecting a Site for the Equipment CAUTION: Before you install the switch, we strongly recommend that you: 1. Place the extender within an appropriate ventilation environment. Allow at least 1" (2.5 cm) of space around the unit. 2. -
Page 13: Network Extension Application
Table 3-1. Compatible cables. Media Speed Wiring 10-/100-Mbps 10 Mbps Category 3, 4, 5, 5e UTP/STP copper 100 Mbps Category 5, 5e UTP/STP 3.5 Network Extension Application LBNC300A LBNC300A Switch Switch Internet Figure 3-1. Typical application. 724-746-5500 | blackbox.com Page 13... - Page 14 NOTES 724-746-5500 | blackbox.com Page 14...
- Page 15 NOTES 724-746-5500 | blackbox.com Page 15...
- Page 16 724-746-5500 or blackbox.com. About Black Box Black Box Network Services is your source for an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 30 seconds or less.
