  • Page 1 Order toll-free in the U.S. 24 hours, 7 A.M. Monday to midnight Friday: 877-877-BBOX CUSTOMER FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724- SUPPORT 746-0746 INFORMATION Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com...
  • Page 2 FEDERAL COMMUNICATIONS COMMISSION AND CANADIAN DEPARTMENT OF COMMUNICATIONS RADIO FREQUENCY INTERFERENCE STATEMENT This equipment generates, uses and can radiate radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication.

  • Page 3: Preface

    Preface This manual describes how to install and use LB300A, Ethernet Extender. The Ethernet Extender introduced here provides one channel for Ethernet over VDSL. LB300A, Ethernet Extender fully complies with IEEE 802.3 10BaseT and IEEE 802.3u 100BaseTX standards. In this manual, you will find:...

  • Page 4: Table Of Contents

    Table of Contents Preface ..........................3 Table of Contents ......................4 Introduction........................5 .......................5 RODUCT VERVIEW .......................5 RODUCT EATURES ........................5 ACKING LB300A, One-Channel Ethernet Extender ................6 ..........................6 ORTS VDSL M ....................6 ETTINGS & LED .....................6 RONT ANEL ................8 ELECTING A ITE FOR THE QUIPMENT ....................8...

  • Page 5: Introduction

    Packing List When you unpack this product package, you will find the items listed below. Please inspect the contents, and report any apparent damage or missing items immediately to our authorized reseller. • LB300A, Ethernet Extender • User’s Manual •...

  • Page 6: Lb300A, One-Channel Ethernet Extender

    Loc and the other to Rmt when two devices are connected. Front Panel & LEDs The device operates in The device operates in local mode remote mode LED Indicators The LED indicators give you instant feedback on status of LB300A, Ethernet Extender:...
  • Page 7 LEDs State Indication Steady Power on Pwr stands for POWER Power off Ethernet Lnk/Act Steady A valid Ethernet connection established Lnk stands for LINK Flashing Transmitting or receiving Ethernet data Act stands for ACTIVITY Neither valid Ethernet connection established nor transmitting/receiving Ethernet data Steady Ethernet Connection in full duplex mode...

  • Page 8: Selecting A Site For The Equipment

    This LB300A, Ethernet Extender is a plug-and-play device. Connect the supplied AC to DC power adaptor to the receptacle on the rear panel of LB300A, Ethernet Extender, and then attach the plug into a standard AC outlet with a voltage range from 100 to 240VAC.

  • Page 9: Use Panel Mount Kit

    Carefully slide in the carrier until it is fully and firmly fit the chassis. Fasten the screws onto the carrier. <NOTE> Never insert any LB300A, Ethernet Extender into the chassis directly without using the supplied carriers. The carriers allow secure and consistent placement of LB300A, Ethernet Extenders into the chassis backplane without causing any damage.

  • Page 10: Lb300A Specifications

    LB300A Specifications Applicable IEEE 802.3 10BaseT Standards IEEE 802.3u 100BaseTX Ethernet over VDSL Fixed Ports 1 x 10/100Mbps Ethernet port with RJ-45 connector 1 x Ethernet over VDSL port with RJ-11 connector Speed 10BaseT 10/20Mbps for half/full-duplex 100BaseTX 100/200Mbps for...
