Hardened PoL PoE Ethernet Extenders
Hardened PoL PoE Ethernet Extenders
Extends Power over Ethernet up to 1.2 km over ordinary
voice-grade copper wire.
Features Ethernet extension up to 2.2 km.
Customer
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S.
Support
call 724-746-5500) • FREE technical support 24 hours a day,
Information
7 days a week: Call 724-746-5500 or fax 724-746-0746
• Mailing address: Black Box Corporation, 1000 Park Drive,
Lawrence, PA 15055-1018 • Web site: www.blackbox.com
• E-mail: info@blackbox.com
BLACK BOX
LBPS310A-KIT
LBPS311A
LBPS312A
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Black Box LBPS310A-KIT
Summary of Contents for Black Box LBPS310A-KIT
-
Page 1: Black Box
Support call 724-746-5500) • FREE technical support 24 hours a day, Information 7 days a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 • Web site: www.blackbox.com • E-mail: info@blackbox.com... -
Page 2: Quick Start Guide
10/100Base-TX Hardened PoL/PoE Ethernet Extender Quick Start Guide This quick start guide describes how to install and use the Hardened Ethernet Extender. This is the Hardened Ethernet Extender of choice for harsh environments constrained by space. Installation Transmitter: This is a PoL (Power over Link) transmitter. Data and power can be delivered at the same time through one pair copper wire to turn on and communicate with a Receiver via an RJ-11 phone jack or a 2-pin Terminal Block interface. -
Page 3: Physical Description
10/100Base-TX Hardened PoL/PoE Ethernet Extender ∞ Connect one end of the one pair copper wire to the RJ-11 phone jack or 2-pin Terminal Block interface of the Transmitter and connect the other end to RJ-11 phone jack or 2-pin Terminal Block interface of the Receiver. ∞... - Page 4 10/100Base-TX Hardened PoL/PoE Ethernet Extender Power Input Assignment Power1 48VDC DC Jack T:46-57V / R:46-57V DC Power2 Power Ground Terminal T:46-57V / R:46-57V DC Power3 Block Power Ground Earth Ground DIP Switch Down Transmitter Disable Power over Link Enable Power over Link Std (Standard) Per (Performance) Type...
-
Page 5: 10/100Base-Tx And Ethernet Extender Connectors
10/100Base-TX Hardened PoL/PoE Ethernet Extender Power over Link (PoL) Enabled Distance Data Rate Receiver PoE Output 300M 100Mbps 30.0W 400M 90Mbps 15.4W 600M 60Mbps 14.0W 800M 45Mbps 9.5W 1000M 35Mbps 7.0W 1200M 20Mbps 5.0W Power over Link (PoL) Disabled Power Supply Applied on Receiver Distance Data Rate Receiver PoE Output... -
Page 6: Functional Description
10/100Base-TX Hardened PoL/PoE Ethernet Extender Ethernet Extender Connection The RJ-11 and Terminal Block port pinouts: Pin 3: Tip, Pin 4: Ring. Use a telephone line to connect two RJ-11 or Terminal Block ports between two Hardened Ethernet Extenders. Functional Description ∞... -
Page 7: Preface
10/100Base-TX Hardened PoL/PoE Ethernet Extender Preface This manual describes how to install and use the Hardened Ethernet Extender. The Hardened Ethernet Extender introduced here provides one channel for Ethernet over existing voice grade copper wire. The Hardened Ethernet Extender fully complies with IEEE802.3 10Base-T and IEEE802.3u 100Base-TX standards. -
Page 8: Table Of Contents
10/100Base-TX Hardened PoL/PoE Ethernet Extender Table of Contents Quick Start Guide................1 Installation..................1 Physical Description................ 2 The Port Status LEDs and Power Inputs ........2 10/100Base-TX and Ethernet Extender Connectors ....4 Functional Description..............5 Preface ....................6 Table of Contents ................7 Introduction .................. -
Page 9: Introduction
10/100Base-TX Hardened PoL/PoE Ethernet Extender Introduction The Hardened Ethernet Extender provides one channel for Ethernet over existing voice grade copper wire. This Hardened Ethernet Extender solution works in industrial applications or rugged environments. Product Overview Transmitter Receiver Product Features ∞ Meets EN61000-6-2 &... -
Page 10: Packing List
185 ). ∞ Supports Din-Rail or Panel Mounting installation. Packing List Your package should contain the following items. IIf anything is missing or damaged, contact Black Box Technical Support at 724-746-5500 or info@blackbox.com. ∞ The Hardened Ethernet Extender ∞... -
Page 11: One-Channel Hardened Ethernet Extender
10/100Base-TX Hardened PoL/PoE Ethernet Extender One-Channel Hardened Ethernet Extender Ports The Hardened Ethernet Extender provides TX ports and one Ethernet Extender port. For the TX ports, it uses RJ-45 connectors and auto senses the speed of 10/100 Mbps. For the Ethernet Extender port, it uses RJ-11 and Terminal Block connectors auto senses... -
Page 12: Front Panel & Leds
10/100Base-TX Hardened PoL/PoE Ethernet Extender Front Panel & LEDs LED Indicators The LED indicators give you instant feedback on the status of the Hardened Ethernet Extender: LEDs State Indication Power Steady Power received 1/2/3 Power off Power Ethernet extension interface function is Steady enabled power... -
Page 13: 10/100Base-Tx And Ethernet Extender Connectors
10/100Base-TX Hardened PoL/PoE Ethernet Extender Power over Link (PoL) Disabled Power Supply Applied on Receiver Distance Data Rate Receiver PoE Output 1400M 15Mbps 30.0W 1600M 10Mbps 30.0W 1800M 3Mbps 30.0W Up to 2200M 1Mbps 30.0W <Note> The Reference Performance is tested on 24 AWG Telephone wire (0.5 mm diameter, 1-pair wire, Cable impedance: 100 ohm). -
Page 14: Installation
10/100Base-TX Hardened PoL/PoE Ethernet Extender Installation This chapter gives step-by-step installation instructions for the Hardened Ethernet Extender. Selecting a Site for the Equipment As with any electric device, you should place the equipment where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference. - Page 15 10/100Base-TX Hardened PoL/PoE Ethernet Extender User’s Manual...
-
Page 16: Connecting To Power
10/100Base-TX Hardened PoL/PoE Ethernet Extender Connecting to Power Redundant DC Terminal Block Power Inputs or 48-VDC DC Jack: Redundant DC Terminal Block Power Inputs Two pairs of power inputs can be used to power up this device. You only need to have one power input connected to run the Hardened Ethernet Extender. - Page 17 10/100Base-TX Hardened PoL/PoE Ethernet Extender Power Input Assignment Power1 48VDC DC Jack T:46-57V / R:46-57V DC Power2 Power Ground Terminal T:46-57V / R:46-57V DC Power3 Block Power Ground Earth Ground User’s Manual...
-
Page 18: Specifications
10/100Base-TX Hardened PoL/PoE Ethernet Extender Specifications IEEE802.3 10Base-T, IEEE802.3u 100Base-TX Applicable Standards Fixed Ports 10/100Mbps Ethernet ports with RJ-45 connectors 1 x Ethernet Extender port with RJ-11 and Terminal Block connectors Speed 10Base-T 10/20Mbps for half/full-duplex 100Base-TX 100/200Mbps for half/full-duplex Ethernet Extender Link (Below 20), 20, 40, 60, 80, 100Mbps Switching Method... - Page 19 10/100Base-TX Hardened PoL/PoE Ethernet Extender Operating Temperature ~ 75 (-40 ~ 167 ) Tested for functional operation @ ~ 85 (-40 ~ 185 ) Storage Temperature ~ 85 (-40 ~ 185 ) Humidity 5 ~ 95%, non-condensing FCC Part 15, Class A EN61000-6-4: EN55022, EN61000-3-2, EN61000-3-3 EN61000-6-2: EN61000-4-2 (ESD Standard)
- Page 20 About Black Box Black Box provides an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 30 seconds or less.
