D I R E C T V E N T F I R E P L A C E - I P I
OWNER'S MANUAL
WARNING:
fire or explosion may result causing property damage, personal injury
or loss of life. Installation and service must be performed by a qualified
C#4001609
Version Française: www.enviro.com/fr.html
G39LI
If the information in this manual is not followed exactly, a
installer, service agency or the gas supplier.
CERTIFIED TO/CERTIFIÉ AUX : ANSI Z21.88-2017
: CSA 2.33-2017
: CSA 2.17-2017
50-3581
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Enviro G39LI
Summary of Contents for Enviro G39LI
- Page 1 Installation and service must be performed by a qualified installer, service agency or the gas supplier. C#4001609 CERTIFIED TO/CERTIFIÉ AUX : ANSI Z21.88-2017 50-3581 : CSA 2.33-2017 Version Française: www.enviro.com/fr.html : CSA 2.17-2017...
-
Page 2: Safety Precautions
Safety Precautions WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapours and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •... - Page 3 Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • All ENVIRO gas-fired appliances must be installed in • A barrier designed to reduce the risk of burns from the accordance with their instructions. Carefully read all the hot viewing glass is provided with this appliance and shall instructions in this manual first.
-
Page 4: Table Of Contents
Table of Contents Safety Precautions ..........................2 Codes And Approvals ........................... 5 Specifications ............................6 Dimensions: ..............................6 Rating Label & Lighting Instructions Location: ....................6 Operating Instructions ........................7 Lighting and Instructions:..........................7 Remote Control Operations:...........................8 System Description:............................8 Technical Data:.............................8 Remote Transmitter:.............................8 Integrated Fireplace Controller (IFC):......................9 Operating Procedure:...........................10 Normal Sounds During Operation:........................13... -
Page 5: Codes And Approvals
TESTED TO: ANSI Z21.88-2017/CSA 2.33-2017 VENTED GAS FIREPLACE HEATERS CAN/CGA 2.17-2017 GAS FIRED APPLIANCES FOR HIGH ALTITUDES This ENVIRO G39 Fireplace: • Has been certified for use with either natural gas or propane (see rating label). • Is not for use with solid fuels. -
Page 6: Specifications
Specifications G39 D imensions 27 3 18 3 18 1 1041 18 1 29 3 39 3 34 1 34 1 30 1 1066 1008 35 1 ELECTRICAL 38 3 39 1 Figure 1. G39 Dimensions & L atinG abeL iGhtinG nstRuctions ocation... -
Page 7: Operating Instructions
Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OF LOSS OF LIFE. iGhtinG anD nstRuctions FOR YOUR SAFETY READ BEFORE OPERATING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION... -
Page 8: Remote Control Operations
Operating Instructions emote ontRoL peRations Proflame 2 is a modular remote control system that directs the functions of the fireplace. The Proflame 2 remote transmitter is configured to control the on and off function of the main burner. The systems also allows your to modulate the flame level, fan speed, and accent light features. -
Page 9: Integrated Fireplace Controller (Ifc)
Operating Instructions WARNING: Fire Hazard. Can cause severe injury or death. The Transmitter causes ignition of the appliance. The appliance can turn on suddenly. Keep away from the appliance burner when operating the remote system. Key Lock Transmission Low battery alarm Thermostat OFF/ Room ON/SMART... -
Page 10: Operating Procedure
Operating Instructions peRatinG RoceDuRe Initializing The System Install the four (4) supplied AA batteries into the IFC battery holder. The remote transmitter should come from the manufacturer with the batteries already installed. Press the reset button on the IFC (see Figure 5) and listen for three (3) beeps. - Page 11 Operating Instructions Room Thermostat (Transmitter Operation) Room Temperature The remote transmitter acts as a room thermostat. The thermostat can be set to a desired temperature to control the comfort level in a room. Press the THERMOSTAT key to activate this function. The transmitter display will indicate the thermostat is ON and the set temperature can be adjusted with the UP/DOWN key.
- Page 12 Operating Instructions Fan Control The Proflame 2 remote control system has six (6) fan speed levels. Adjust the fan speed using the UP/DOWN key; each time the button is pressed the IFC will beep to confirm your command. The remote display will show which level the fan speed is currently at.
-
Page 13: Normal Sounds During Operation
Operating Instructions Top Light Control The top light is used to illuminate the log set in the fireplace, even when the flame is off. The on/off operation can be controlled using the remote transmitter. Use the MODE key to select the auxiliary icon and use the UP/DOWN key to activate the top light;... -
Page 14: Pilot Light
Operating Instructions iLot iGht The pilot flow adjustment is set to maximum at the factory and Flame Sensor should not need to be adjusted. The pilot flame should cover ⅜” to ½” (10 to 13mm) of the flame sensor (see Figure 16). .375-.500 (10-13mm) However, should the need arise, turn the adjustment screw to... -
Page 15: Maintenance And Service
Do not operate with the glass front removed, cracked or broken. Removal and replacement of the glass from the door must be done by a licensed or qualified service person. The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. To remove the door (see m ). -
Page 16: Cleaning Decorative Surfaces
Maintenance And Service LeaninG ecoRatiVe uRFaces Painted and porcelain faces should be wiped with a damp cloth periodically. If a plated face has been purchased, it should be unpacked carefully to avoid getting anything on the surface of the finish, including cleaners, polish and finger prints. -
Page 17: Door Cover Removal
Maintenance And Service oVeR emoVaL To remove the door cover, remove the two (2) wing nuts using your fingers then lift up and outward. Wing nuts are only for shipping and do not need to be reinstalled. WARNING: Do not touch or attempt to remove the glass door if the fireplace is not completely cold. Figure 19. -
Page 18: Front Burner Removal
Maintenance And Service The burner will need to be removed for maintenance and fuel conversion, also liner removal or installation. Follow the procedure carefully. Proceed only when the unit has completely cooled down. uRneR emoVaL 1. Remove the surround panel (see m aIntenance anD erVIce urrounD... -
Page 19: Ember Lights Removal
Maintenance And Service mbeR iGhts emoVaL 1. Disconnect electrical power to the unit. 2. Remove burner (see m aIntenance anD erVIce ront urner emoVal 3. Remove glass media (if installed). 4. Remove light tray by removing the four (8) T-20 screws (see Figure 22). Figure 22. -
Page 20: Top Light Replacement
6. Remove the light cover by removing the four (4) T-20 Light Assembly screws. If light gasket is damaged, contact your ENVIRO dealer for replacement. 7. Replace the light assembly as necessary and assemble back into unit. -
Page 21: Fuel Conversion
Kit Parts List for G39LI Model: 1 - Burner Orifice LP [DMS #52] NG [#36 DMS] as marked 1 - Stepper Motor w/ Hardware... - Page 22 9. Reconnect electrical power to the unit. 10. Light the pilot and recheck for leaks in the aluminum pilot line. If a leak is evident, contact your ENVIRO dealer for a pilot line replacement. WARNING: DO NOT ATTEMPT TO FIX THIS LINE, IT MUST BE REPLACED IF DAMAGED.
-
Page 23: Initial Installation
Initial Installation QUALIFIED INSTALLERS ONLY ntRoDuction This section of the owner’s manual is for the use of qualified technicians only. There are several installation safety guidelines that must be adhered to; carefully read the safety precautions at the front of this manual. - Page 24 CAUTION: DO NOT DRILL INTO THE BOARD ANY FURTHER OR IT MAY CRACK. This board is mandatory unless the c is activated, if it is damaged urFace ystem contact you ENVIRO dealer. Figure 35: Non-combustible board DETAIL DETAIL SCALE 1 : 2...
-
Page 25: Placement And Framing
Initial Installation QUALIFIED INSTALLERS ONLY Lacement anD RaminG 42” 72” (1,067mm) (1,830mm) Natural Gas* 41½” (1,054mm) 18¼” (464mm) Figure 36: G39 Minimum Framing Table 3: G39 Minimum Framing Minimum Framing Dimensions Depth ” 464mm Width ” 1054mm Header Height 42” 1067mm Enclosure Ceiling (Natural Gas) 72”... -
Page 26: Finishing A Fireplace
Initial Installation QUALIFIED INSTALLERS ONLY inishinG a iRepLace There are multiple ways to finish a G39 fireplace. Here is what you need to know to properly install the desired finishing material. There are three finishing edge options. 1. Outer Finishing Edge (Short) - This finishing edge comes mounted to the unit with screws. -
Page 27: Cool Surface Activation
Initial Installation QUALIFIED INSTALLERS ONLY ONLY Combustible material may be brought up to any finishing edge if the Cool Surface System (CSS) has been correctly activated allowing heat in the chase to be vented. This system keeps the front wall cool enough for any combustible materials. The supplied non-combustible board can still be used but is not mandatory when the CSS is activated, combustible material may overlap in this situation. - Page 28 Initial Installation QUALIFIED INSTALLERS ONLY Standard Install: the Non-combustible is Cool Surface System (CSS) Install: Image mandatory. Image shows single layer finishing shows the short finishing edge, combustible material using the short finishing edge. can be brought right down to the finishing edge. 1 "...
-
Page 29: Cool Surface Install Options
Initial Installation QUALIFIED INSTALLERS ONLY uRFace nstaLL ptions This fireplace is manufactured with a built-in heat distribution kit, referred to as the Cool Surface System (CSS). The purpose of the CSS is to dramatically reduce the front wall temperatures above your fireplace. This is very useful when delicate objects such as a TV or artwork are mounted above the unit. - Page 30 Initial Installation QUALIFIED INSTALLERS ONLY Option 2: Open Chase (built-out installations) - This could be considered the most discreet option when considering the CSS. The chase must be constructed in a way that stops short of the ceiling, leaving it totally vented above. Minimum framing dimensions must be followed when constructing this option and not to deviated from them when using combustible materials.
- Page 31 Initial Installation QUALIFIED INSTALLERS ONLY Option 4: Bezel - The included bezel may be desired to accentuate the CSS outlet. This installation will also cover the edge of the finishing material at the cutout. Construct the framing in a way that provides a 41 ”...
-
Page 32: Flat Wall Installation
Initial Installation QUALIFIED INSTALLERS ONLY nstaLLation These are the minimum allowable dimensions required to safely operate the fireplace. Plan your entire installation before proceeding. These are minimum dimensions associated with natural gas only; adjust the ceiling dimensions by adding 10.5” (266 mm) if using propane. 4"... -
Page 33: Recess Installation
Initial Installation QUALIFIED INSTALLERS ONLY ecess nstaLLation These are the minimum allowable dimensions required to safely operate the fireplace. Plan your entire installation before proceeding. The maximum allowable depth for a recess in 3 ” (90mm) + Finishing material thickness. 4"... -
Page 34: Corner Installation
Initial Installation QUALIFIED INSTALLERS ONLY oRneR nstaLLation These are the minimum allowable framing dimensions required to safely operate the fireplace in a corner install. Plan your entire installation before proceeding. " 853mm " 1" 554mm 25mm 15" " 382mm 1206mm 1"... -
Page 35: Floor Protection
Initial Installation QUALIFIED INSTALLERS ONLY LooR Rotection The fireplace must be placed on a solid and level floor; plywood is recommended for basic installations. A protective hearth in front of the unit is not required but highly recommended for the longevity of sensitive flooring materials in front of the fireplace. -
Page 36: Minimum Venting Requirements
Initial Installation QUALIFIED INSTALLERS ONLY inimum entinG equiRements This appliance uses a 4” (102mm) exhaust / 6 ” (168mm) air intake vent pipe system. For safe and proper operation of the appliance follow the venting instructions exactly. Deviation from the minimum vertical length can create difficulty in burner start-up and sooting. -
Page 37: Flex Venting
Initial Installation QUALIFIED INSTALLERS ONLY entinG This fireplace is only certified to work with certain BDM Pro-Form and Duravent flexible direct venting systems. Not all rigid venting configurations are allowable when using flex venting. Only horizontally terminated applications will work with a vertical rise between 12” (305mm) and 78” (1981mm) measured from the top of the unit. -
Page 38: Clearances & Noncombustible
Initial Installation QUALIFIED INSTALLERS ONLY & n LeaRances ombustibLe When installing the fireplace as a zero clearance fireplace the correct clearances and materials must be used. : The supplied noncombustible board is required above the unit up to the header 9” MIN. boVe However this not required if the Cool Surface System has been properly installed. -
Page 39: Tv Installation Considerations
Initial Installation QUALIFIED INSTALLERS ONLY tV i nstaLLation onsiDeRations Use of the Cool Surface System is highly recommended when mounting a TV or delicate artwork above the fireplace. If the system is not desired, some considerations must be made to ensure above objects are protected from the heat. -
Page 40: Direct Vent
Initial Installation QUALIFIED INSTALLERS ONLY iRect WARNING: - Follow the venting instructions exactly for safe and proper appliance operation. - Use Mill Pac or high temp RTV silicone for all venting connections. - Risk of fire, explosion, or asphyxiation if improper venting setup. -Risk of fire, do not allow loose materials or insulation to contact vent pipe. -
Page 41: General Venting Clearances
Initial Installation QUALIFIED INSTALLERS ONLY 12 in (30 cm) Clearance to non-mechanical air supply inlet to building, or the combustion air inlet to any other appliance. 6 ft (1.83 m) 3 ft (91 cm) above if within 10 Clearance to mechanical air supply inlet. ft (3 m) horizontally 7 ft (2.13 m )t 7 ft (2.13 m) *t... -
Page 42: Approved Venting Parts
Initial Installation QUALIFIED INSTALLERS ONLY ppRoVeD entinG aRts Table6: Approved Vent Manufacturers Manufacturer Trade Name Nominal Sizes EXCELDirect 4” - 6 ” M&G Dura-Vent Direct Vent Pro 4” - 6 ” Selkirk DIRECT-TEMP 4” - 6 ” Selkirk AMP DV 4”... -
Page 43: Allowable Co-Axial Vent Configurations
Initial Installation QUALIFIED INSTALLERS ONLY LLoWabLe xiaL onFiGuRations This shows the range of venting options 40’ (12.2m) using either vertical or horizontal terminations; any layout that remains NG Vent within the shaded area is acceptable. Having the fewest number of elbows RESTRICTOR 5 RESTRICTOR 5 is ideal as they restrict air movement. - Page 44 Initial Installation QUALIFIED INSTALLERS ONLY 40’ (12.2m) ONLY use this venting diagram if your fireplace has been converted to LP. LP Vent Restrictor Setting: Find the point on the graph where your vent configuration will RESTRICTOR 5 RESTRICTOR 5 35’ Position terminate.
-
Page 45: Exhaust Restrictor Setting
Initial Installation QUALIFIED INSTALLERS ONLY xhaust estRictoR ettinG WARNING: Improperly set restrictor setting can cause overheating issues which can lead to building fire. It may be necessary to adjust the exhaust restrictor in order to control combustion quality and flame appearance. -
Page 46: Horizontal Termination
Initial Installation QUALIFIED INSTALLERS ONLY oRizontaL eRmination . A minimum of 12”(NG) or 24”(LP) vertical rise before an elbow is required when horizontally terminating with an approved venting cap. 2. Horizontal pipes must not be level. For every 12” (305 mm) of horizontal travel there should be at least ¼”... -
Page 47: Vertical Termination
Initial Installation QUALIFIED INSTALLERS ONLY Step 4. The vent pipe must extend into the vent cap at least 1¼” (320 mm). Secure the connection between the vent cap and the pipe by attaching the two (2) sheet metal straps, which extend from the vent cap assembly to the outer wall of the vent pipe. - Page 48 Initial Installation QUALIFIED INSTALLERS ONLY Table 8: Minimum ‘H’ for Figure 63. Roof Pitch Minimum Height (H) Dimension ‘H’ obtained Feet Meters from table below Flat to 7/12 Over 7/12 to 8/12 0.46 Over 8/12 to 9/12 0.61 Over 9/12 to 10/12 0.76 Over 10/12 to 11/12 3.25...
-
Page 49: Gas Line Connection And Testing
Initial Installation QUALIFIED INSTALLERS ONLY onnection anD estinG WARNING: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. GAS LINE CONNECTION • This fireplace is equipped with a certified flexible pipe located on the right side of the unit terminating in a 3/8”... -
Page 50: Electrical Requirements
Initial Installation QUALIFIED INSTALLERS ONLY LectRicaL equiRements WARNING: The fireplace must be electrically connected and grounded in accordance with local codes or, in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code Part 1, Safety Standards For Electrical Installations, or The National Electrical Code ANSI / NFPA 70 in the US. -
Page 51: Secondary Installation
If the liners arrive damaged, please contact your ENVIRO dealer for replacement. Step 5. Replace liners back into position starting with the rear. Please note that any liner options containing brick will have to be aligned with each other. -
Page 52: Log Set Installation
Wear vinyl gloves when handling the logs, the ceramic material can irritate your skin. Take care not to damage the logs as they are very fragile and can chip easily. If any logs arrive damaged, please contact your ENVIRO dealer for replacement. Log 4... - Page 53 Secondary Installation Step 3 Place Log 3 on the right side in front of the grate arms. Line up the Log 3 bottom sockets with the points on the ember bed. Step 4 Place Log 4 to the right, on the top of Log 1 and Log 2.
- Page 54 Secondary Installation Step 7 Rest Log 7 at an angle on top of the log grate and Log 6. Step 8 Place Log 8 between the grate arms, with the bottom of the log resting on the edge of the ember bed. Step 9 Place Log 9 between the grate arms, with the bottom of the log resting on the edge of...
-
Page 55: Troubleshooting
Troubleshooting Table 10: Troubleshooting Problem Possible Cause Solution · Turn the system off by pressing the ON/OFF button on the transmitter · After approximately 2 seconds press the ON/OFF button on the transmitter again. Locking Reset the Proflame IFC board ·... -
Page 56: Parts List
Parts List Table 11: Parts List Reference # Part Description Part # Convection Fan Only 50-3577 Top Light Assembly 50-3516 Log Burner 50-3585 S.I.T IPI Valve 50-2682 PSE IPI Pilot Assembly 50-3026 Halogen Socket W/ Wires 50-2028 35W Halogen Bulb 50-3291 G39 Safety Screen 50-3578... -
Page 57: Parts Diagram
Parts Diagram... - Page 58 Notes...
-
Page 59: Warranty
Exclusions conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail. This warranty does not cover: In the event of a defect of material or workmanship during the specified warranty period, ƒ... - Page 60 � � NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in wc PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com August, 2018 C-15559...
