Avalue Technology EAX-C236P User Manual

Intel core processors with intel c236 atx motherboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EAX-C236P
Intel® Core™ Processors with Intel® C236 ATX Motherboard
User's Manual
nd
Ed –17 August 2017
2
Part No. E2047A23601R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EAX-C236P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avalue Technology EAX-C236P

Summary of Contents for Avalue Technology EAX-C236P

  • Page 1 EAX-C236P Intel® Core™ Processors with Intel® C236 ATX Motherboard User’s Manual Ed –17 August 2017 Part No. E2047A23601R...
  • Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
  • Page 3 Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.
  • Page 4 A product returned without proof of the purchase date is not eligible for warranty service. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. 4 EAX-C236P User’s Manual...

  • Page 5: Table Of Contents

    SPI connector (JSPI1) ....................... 29 2.3.20 Speaker connector (JSPK1) ...................... 29 2.3.21 Miscellaneous setting connector (JFP1) ..................30 2.3.22 CPU fan connector (CPUFAN1) ....................30 2.3.23 System fan connector 1 (SYSFAN1) ..................31 2.3.24 System fan connector 2 (SYSFAN3) ..................31 EAX-C236P User’s Manual...
  • Page 6 3.6.2.8.1 Legacy Console Redirection Settings ................... 52 3.6.2.9 CPU Configuration ......................... 52 3.6.2.10 Intel TXT Configuration ......................54 3.6.2.11 SATA Configuration ....................... 54 3.6.2.11.1 Software Feature Mask Configuration ................... 56 3.6.2.12 Network Stack Configuration ....................56 6 EAX-C236P User’s Manual...
  • Page 7 Install Chipset Driver ....................76 Install VGA Driver ....................77 Install ME Driver ...................... 78 Install Audio Driver (For Realtek ALC892 HD Audio) ..........79 Install LAN Driver ....................80 Install RST Driver ....................81 5. Mechanical Drawing ....................83 EAX-C236P User’s Manual...

  • Page 8: Getting Started

    1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x EAX-C236P motherboard  2 x SATA cable  1 x I/O Shield ...

  • Page 9: Document Amendment History

    User’s Manual 1.3 Document Amendment History Revision Date Comment June 2016 Avalue Initial Release August 2017 Avalue Update System Specifications EAX-C236P User’s Manual...

  • Page 10: Manual Objectives

    We strongly recommend that you study this manual carefully before attempting to set up EAX-C236P or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance.

  • Page 11: System Specifications

    1 x Intel® I219LM Gigabit Ethernet PHY LAN Chip 1 x Intel® I211AT PCI-e Gigabit Ethernet Internal I/O Connectors Internal I/O Storage: Connector - 1 x SATA III or 1 x full size Mini PCI-e support mSATA by auto switch IC EAX-C236P User’s Manual 11...
  • Page 12 1 x 6 pin, pitch 2.00mm connector for SGPIO 1 x 5 pin, pitch 2.54mm connector for SMBus 1 x 2 x 4 pin, pitch 2.00mm connector for BIOS SPI 1 x 2 x 5 pin, pitch 2.0mm connector for LPC Onboard buzzer 12 EAX-C236P User’s Manual...
  • Page 13 0 ~ 60°C (32~140°F) Storage Temp. -40 ~ 75°C Operating 0% ~ 90% relative humidity, non-condensing Humidity Size (L x W) 12" x 9.6" (304.8mm x 243.84mm) Weight 0.60 kg Note: Specifications are subject to change without notice. EAX-C236P User’s Manual 13...
  • Page 14 EAX-C236P User’s Manual 14 EAX-C236P User’s Manual...

  • Page 15: Architecture Overview-Block Diagram

    User’s Manual 1.6 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of EAX-C236P. EAX-C236P User’s Manual 15...

  • Page 16: Hardware Configuration

    EAX-C236P User’s Manual 2. Hardware Configuration 16 EAX-C236P User’s Manual...

  • Page 17: Product Overview

    User’s Manual 2.1 Product Overview EAX-C236P User’s Manual 17...

  • Page 18: Jumper And Connector List

    4 x 1 wafer, pitch 2.54mm function supported) SYSFAN3 System fan connector 2 3 x 1 wafer, pitch 2.54mm JFP1 Miscellaneous setting connector 5 x 2 header, pitch 2.54 mm DIMM1/2/3/4 288-pin DDR4 DIMM socket AUDIO1 Audio connector 18 EAX-C236P User’s Manual...
  • Page 19 VGA1 VGA connector NGFF1 M.2 2230 KeyA Slot support WiFi module 13 x 2 header, pitch 2.54mm LPT1 LPT connector JSIM1 SIM card slot JSPDIF1 S/PDIF connector 5 x 1 header, pitch 2.54mm JSMB1 SMBus connector EAX-C236P User’s Manual 19...

  • Page 20: Setting Jumpers & Connectors

    EAX-C236P User’s Manual 2.3 Setting Jumpers & Connectors 2.3.1 Serial port 1 pin9 signal select (JRI1) Ring* +12V * Default 2.3.2 Serial port 2 pin9 signal select (JRI2) Ring* +12V * Default 20 EAX-C236P User’s Manual...

  • Page 21: At/Atx Power Mode Select (Jatatx1)

    User’s Manual 2.3.3 AT/ATX Power Mode Select (JATATX1) * Default 2.3.4 Clear CMOS (JCMOS1) Protect* Clear CMOS * Default EAX-C236P User’s Manual 21...

  • Page 22: Serial Port 2 Connector (Jcom2A)

    EAX-C236P User’s Manual 2.3.5 Serial port 2 connector (JCOM2A) Signal PIN PIN Signal NRXD NDCD# NDTR# NTXD NDSR# NCTS# NRTS# JNRI# 2.3.6 COM2 RS485/422 connector (JCOM2B) Signal PIN PIN Signal 485TX- 422RX- 485TX+ 422RX+ 22 EAX-C236P User’s Manual...

  • Page 23: Serial Port 3/4/5/6 Connector (Jcom3/4/5/6)

    User’s Manual 2.3.7 Serial port 3/4/5/6 connector (JCOM3/4/5/6) Signal PIN PIN Signal NRXD NDCD# NDTR# NTXD NDSR# NCTS# NRTS# NRI# 2.3.8 General purpose I/O connector (JDIO1) Signal PIN PIN Signal SMB_CLK_9555 10 SMB_DATA_9555 EAX-C236P User’s Manual 23...

  • Page 24: Sgpio Connector (Jsgpio1)

    Signal PIN PIN Signal SGIO_LOAD SGIO_DATOUT0 SGIO_CLK SGIO_DATOUT1 Note: Need to install Intel(R) Rapid Storage Technology Enterprise (RSTe) Driver. 2.3.10 ATX Power connector (ATXPWR1) Signal Signal +3.3V +12V +12V +V5SB ATX_PWRGD ATX_PSON# +3.3V -12V +3.3V +3.3V 24 EAX-C236P User’s Manual...

  • Page 25: Power Connector (Atx12V1)

    User’s Manual 2.3.11 Power connector (ATX12V1) Signal PIN PIN Signal +12V +12V +12V +12V 2.3.12 SMBus connector (JSMB1) Signal SMB_CLK_MAIN SMB_DATA_MAIN SMB_ALERT#_MAIN +3.3V EAX-C236P User’s Manual 25...

  • Page 26: Usb Connector 1 (Jusb1)

    EAX-C236P User’s Manual 2.3.13 USB connector 1 (JUSB1) Signal PIN PIN Signal USB_R_DP14 USB_R_DP13 USB_R_DN14 USB_R_DN13 SS_USB_TXP_C_6 SS_USB_TXP_C_5 15 SS_USB_TXN_C_6 SS_USB_TXN_C_5 17 SS_USB_RXP_C_6 SS_USB_RXP_C_5 18 SS_USB_RXN_C_6 SS_USB_RXN_C_5 USBVCC_DE USBVCC_DE 2.3.14 USB connector 2 (JUSB2) Signal USBVCC56 USB_R_DN5 USB_R_DP5 26 EAX-C236P User’s Manual...

  • Page 27: Usb Connector 4 (Jusb4)

    User’s Manual 2.3.15 USB connector 4 (JUSB4) Signal Signal USBVCC_BC USBVCC_BC USB_R_DN12 USB_R_DN11 USB_R_DP12 USB_R_DP11 2.3.16 Battery connector (JBAT1) Signal RTC_VBAT_1 EAX-C236P User’s Manual 27...

  • Page 28: Audio Connector (Jaudio1)

    2.3.17.1 Signal Description –Audio connector (JAUDIO1) Signal Signal Description LINE2_JD AUDIO IN (LINE_RIN/LIN)sense pin MIC2_JD MIC IN (MIC_RIN/LIN) sense pin 2.3.18 LPC connector (JLPC1) Signal PIN PIN Signal LPC_AD0_R +3.3V LPC_AD1_R BUF_PLT_RST# LPC_AD2_R LPC_FRAME#_R LPC_AD3_R LPC_CLK LPC_SERIRQ_R 28 EAX-C236P User’s Manual...

  • Page 29: Spi Connector (Jspi1)

    User’s Manual 2.3.19 SPI connector (JSPI1) Signal PIN PIN Signal +3.3V SSPI_CS0#_R SSPI_SCLK_R SSPI_SO_R SSPI_SI_R SSPI_HOLD#0 2.3.20 Speaker connector (JSPK1) Signal SPK_L+ SPK_L- SPK_R+ SPK_R- EAX-C236P User’s Manual 29...

  • Page 30: Miscellaneous Setting Connector (Jfp1)

    EAX-C236P User’s Manual 2.3.21 Miscellaneous setting connector (JFP1) Signal PIN PIN Signal HDD_LED+ PWR_LED+ HDD_LED- PWE_LED- RSET_BTN# PWRBTN# 2.3.22 CPU fan connector (CPUFAN1) Signal +12V CPUFANIN CPUFANOUT 30 EAX-C236P User’s Manual...

  • Page 31: System Fan Connector 1 (Sysfan1)

    User’s Manual 2.3.23 System fan connector 1 (SYSFAN1) Signal +12V SYSFANIN1 SYSFANOUT1 2.3.24 System fan connector 2 (SYSFAN3) Signal +12V SYS_FAN_IN_2 EAX-C236P User’s Manual 31...

  • Page 32: Ps/2 Keyboard & Mouse Connector (Jkbms1)

    EAX-C236P User’s Manual 2.3.25 PS/2 keyboard & mouse connector (JKBMS1) Signal MSCK MSDT KBDT KBCK 2.3.26 S/PDIF connector (JSPDIF1) Signal SPDIF_O 32 EAX-C236P User’s Manual...

  • Page 33: External Speaker Connector (Jbz1)

    User’s Manual 2.3.27 External Speaker connector (JBZ1) Signal BEEP# 2.3.28 LPT connector (LPT1) Signal PIN PIN Signal PT-STB- PT_AFD# PTD0 ERR# PTD1 PT_PAR_INIT# PTD2 PT_SLIN# PTD3 PTD4 PTD5 PTD6 PTD7 ACK# BUSY SLCT EAX-C236P User’s Manual 33...

  • Page 34: Auxiliary Panel Connector (Jauxp1)

    Linked Green connection Note: 1Gbps Blinking Data activity Orange connection This port allows Gigabit connection to a Local Area Network (LAN) through a network hub. Refer to the table below for the LAN port LED indications. 34 EAX-C236P User’s Manual...

  • Page 35: Bios Setup

    User’s Manual 3.BIOS Setup EAX-C236P User’s Manual 35...

  • Page 36: Introduction

    If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP 36 EAX-C236P User’s Manual...

  • Page 37: Using Setup

    Note: Some of the navigation keys differ from one screen to another.  To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. EAX-C236P User’s Manual 37...

  • Page 38: Getting Help

    BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 38 EAX-C236P User’s Manual...

  • Page 39: Bios Setup

    <Enter> to accept and enter the sub-menu. 3.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. 3.6.1.1 System Language This option allows choosing the system default language. EAX-C236P User’s Manual 39...

  • Page 40: System Date

    Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. 3.6.2 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 40 EAX-C236P User’s Manual...

  • Page 41: Trusted Computing

    O.S. will not show Security Device. TCG EFI Enable[Default] protocol and INT1Ainterface will not be available. 3.6.2.2 APCI Settings Item Options Description Enable ACPI Auto Disabled[Default], Enables or Disables BIOS ACPI Auto Configuration Enabled Configuration. EAX-C236P User’s Manual 41...

  • Page 42: Amt Configuration

    USB Power state in S3-S5 (Sleep), S4 (Hibernate) and S5 (Soft Off) Enabled[Default], States. 3.6.2.3 AMT Configuration Item Options Description Disabled Enable/Disable Intel® Active Management Technology BIOS Intel AMT Enabled[Default], Extension. Note: iAMT H/W is always enabled. This option just 42 EAX-C236P User’s Manual...

  • Page 43: Pch-Fw Configuration

    Selects TPM device: dTPM – The discrete TPM chip. dTPM Chip[Default], PTT – Intel Platform Trust Technology. Warning! If TPM Device Selection PTT/dTPM was disabled, All data saved on it will be lost. 3.6.2.4.1 Firmware Update Configuration EAX-C236P User’s Manual 43...

  • Page 44: Super Io Configuration

    Set Parameters of Serial Port 4 (COMD). Serial Port 5 Configuration Set Parameters of Serial Port 5 (COME). Serial Port 6 Configuration Set Parameters of Serial Port 6 (COMF). Parallel Port Configuration Set Parameters of Parallel Port (LPT/LPTE). 44 EAX-C236P User’s Manual...

  • Page 45: Serial Port 1 Configuration

    Enable or Disable Serial Port (COM). Disabled Change Settings Auto[Default] Select an optimal setting for Super IO Device. 3.6.2.5.2 Serial Port 2 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled EAX-C236P User’s Manual 45...

  • Page 46: Serial Port 3 Configuration

    Set COM Port as RS232, RS422 or RS485 mode. RS485 3.6.2.5.3 Serial Port 3 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled Change Settings Auto[Default] Select an optimal setting for Super IO Device. 3.6.2.5.4 Serial Port 4 Configuration 46 EAX-C236P User’s Manual...

  • Page 47: Serial Port 5 Configuration

    Select an optimal setting for super IO Device. 3.6.2.5.5 Serial Port 5 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled Change Settings Auto[Default] Select an optimal setting for super IO Device. EAX-C236P User’s Manual 47...

  • Page 48: Serial Port 6 Configuration

    EAX-C236P User’s Manual 3.6.2.5.6 Serial Port 6 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled Change Settings Auto[Default] Select an optimal setting for super IO Device. 3.6.2.5.7 Parallel Port Configuration 48 EAX-C236P User’s Manual...

  • Page 49: Nct6106D H/W Monitor

    STD Printer Mode[Default] SPP Mode EPP-1.9 and SPP Mode Device Mode EPP-1.7 and SPP Mode Change the Printer Port mode. ECP Mode ECP and EPP 1.9 Mode ECP and EPP 1.7 Mode 3.6.2.6 NCT6106D H/W Monitor EAX-C236P User’s Manual 49...

  • Page 50: Smart Fan Configuration

    Smart Fan), SmartFan IV™ Mode. CPU Fan Manual Duty 0-255 CPU Fan manual output duty: 0 to 255. Manual Smart Fan Mode Selection: Manual Mode (No SYSFAN1 Mode SmartFan IV[Default], Smart Fan), SmartFan IV™ Mode. 3.6.2.7 S5 RTC Wake Settings 50 EAX-C236P User’s Manual...

  • Page 51: Serial Port Console Redirection

    Wake system from S5 Fixed Time specified. Select Dynamic Time, System will wake on Dynamic Time the current time + Increase minute(s). 3.6.2.8 Serial Port Console Redirection Item Options Description Disabled[Default], Console Redirection Console Redirection Enable or Disable. Enabled EAX-C236P User’s Manual 51...

  • Page 52: Legacy Console Redirection Settings

    EAX-C236P User’s Manual 3.6.2.8.1 Legacy Console Redirection Settings Item Option Description Select a COM port to display redirection of Legacy Serial Redirection Port COM1[Default] Legacy OS and Legacy OPROM Messages. 3.6.2.9 CPU Configuration 52 EAX-C236P User’s Manual...
  • Page 53 Allows more than two frequency ranges to be Intel® SpeedStep™ Enabled[Default], supported. Disabled Turbo Mode Turbo Mode. Enabled[Default], Disabled CPU C states Enable or disable CPU states. Enabled[Default], C0/C1 Package C State limit Package C State limit. AUTO[Default] EAX-C236P User’s Manual 53...

  • Page 54: Intel Txt Configuration

    EAX-C236P User’s Manual 3.6.2.10 Intel TXT Configuration 3.6.2.11 SATA Configuration 54 EAX-C236P User’s Manual...
  • Page 55 Determines how SATA controller(s) operate. RAID Disabled, SATA Port Enable or Disable SATA Port. Enabled[Default] Hard Disk Drive[Default] Identify the SATA port is connected to Solid SATA Device Type Solid State Drive State Drive or Hard Disk Drive. EAX-C236P User’s Manual 55...

  • Page 56: Software Feature Mask Configuration

    If enabled, indicates that the LED/SGPIO hardware Disabled LED Locate is attached and ping to locate feature is enabled on Enabled[Default], the OS. 3.6.2.12 Network Stack Configuration Item Options Description Enabled Network Stack Enable/Disable UEFI Network Stack. Disabled[Default] 56 EAX-C236P User’s Manual...

  • Page 57: Csm Configuration

    User’s Manual 3.6.2.13 CSM Configuration Item Options Description Enabled CSM Support Enable/Disable CSM Support. Disabled[Default] 3.6.2.14 USB Configuration The USB Configuration menu helps read USB information and configures USB settings. EAX-C236P User’s Manual 57...

  • Page 58: Chipset

    Floppy enumerates devices according to their media format. Optical drives are emulated as ‘CDROM’, Mass Storage Devices Forced FDD Hard Disk drives with no media will be emulated according CD-ROM to a drive type. 3.6.3 Chipset 58 EAX-C236P User’s Manual...

  • Page 59: System Agent (Sa) Configuration

    If Enable, it will not scan for External Gfx Skip Scanning of External Gfx Card Disabled[Default] Card on PEG and PCH PCIE Ports. Auto [Default] Keep IGFX enabled based on the setup Internal Graphics Disabled options. Enabled EAX-C236P User’s Manual 59...

  • Page 60: Dmi/Opi Configuration

    EAX-C236P User’s Manual 3.6.3.1.2 DMI/OPI Configuration 3.6.3.1.3 PEG Port Configuration Item Option Description Disabled Enable Root Port Enabled Enable or Disable the Root Port. Auto[Default] Auto[Default] Gen1 Max Link Speed Configure PCI-E x16 Slot Max Speed. Gen2 Gen3 60 EAX-C236P User’s Manual...

  • Page 61: Memory Configuration

    Program PCIe ASPM after OpROM after OpROM. Disabled: PCIe ASPM will be Enabled programmed before OpROM. 3.6.3.1.4 Memory Configuration Item Option Description Auto[Default] 1067/1200/1333/1400/1600 Maximum Memory Maximum Memory Frequency Selections in /1800/1867/2000/2133/2200 Frequency Mhz. /2400/2600/2667/2800/2933 /3000/3200 EAX-C236P User’s Manual 61...

  • Page 62: Pch-Io Configuration

    EAX-C236P User’s Manual 3.6.3.2 PCH-IO Configuration Item Option Description Disabled Enable or disable OnBoard PCH LAN PHY LAN PHY Controller Enabled[Default] Controller. Quiet Serial IRQ Mode Configure Serial IRQ Mode. Continuous[Default] 3.6.3.2.1 PCI Express Configuration 62 EAX-C236P User’s Manual...
  • Page 63 DISABLE – Disables ASPM. L0sL1 Auto[Default] Auto[Default] Gen1 PCIe Speed Select PCI Express port speed. Gen2 Gen3 Detect Non-Compliance PCI Express Disabled[Default], Detect Non-Compliance Device Device. If enable, it will take more time at Enabled POST time. EAX-C236P User’s Manual 63...
  • Page 64 DISABLE – Disables ASPM. L0sL1 Auto Auto[Default] Gen1 PCIe Speed Select PCI Express port speed. Gen2 Gen3 Detect Non-Compliance PCI Express Disabled[Default], Detect Non-Compliance Device Device. If enable, it will take more time at Enabled POST time. 64 EAX-C236P User’s Manual...
  • Page 65 User’s Manual 3.6.3.2.1.3 PCI-E Root Port 6: PCI-E to PCI Bridge Item Option Description Enabled[Default], PCI-E to PCI Bridge Control the PCI Express Root Port. Disabled 3.6.3.2.1.4 PCI-E Root Port 7: PCIe x1 Slot EAX-C236P User’s Manual 65...
  • Page 66 Device. If enable, it will take more time at Enabled POST time. 3.6.3.2.1.5 PCI-E Root Port 8: Intel I211AT LAN Chip Item Option Description Enabled[Default], Intel I211AT LAN Chip Control the PCI Express Root Port. Disabled 66 EAX-C236P User’s Manual...
  • Page 67 DISABLE – Disables ASPM. L0sL1 Auto Auto[Default] Gen1 PCIe Speed Select PCI Express port speed. Gen2 Gen3 Detect Non-Compliance PCI Express Disabled[Default], Detect Non-Compliance Device Device. If enable, it will take more time at Enabled POST time. EAX-C236P User’s Manual 67...
  • Page 68 DISABLE – Disables ASPM. L0sL1 Auto Auto[Default] Gen1 PCIe Speed Select PCI Express port speed. Gen2 Gen3 Detect Non-Compliance PCI Express Disabled[Default], Detect Non-Compliance Device Device. If enable, it will take more time at Enabled POST time. 68 EAX-C236P User’s Manual...

  • Page 69: Hd Audio Configuration

    HAD will be unconditionally disabled Enabled = HAD will HD Audio Enabled be unconditionally enabled Auto = HAD will be enabled Auto[Default], if present, disabled otherwise. 20 dB 26 dB[Default] Amplifier Gain Select Amplifier Gain(dB). 32 dB 36 dB EAX-C236P User’s Manual 69...

  • Page 70: Boot

    Enable/ Disable boot with initialization of a Disabled[Default] minimal set of devices required to launch Fast Boot Enabled active boot option. Has no effect for BBS boot options. Boot Option #1 Sets the system boot order 70 EAX-C236P User’s Manual...

  • Page 71: Save And Exit

    Use this item to specify the number of minutes which must pass between duplicate log entries which utilize a multiple-event counter. The value ranges from 0 to 99 minutes. View SMBIOS Event Log This allows you to configure the SMBIOS Event Log Settings. EAX-C236P User’s Manual 71...

  • Page 72: Save Changes And Reset

    BIOS setting. 3.6.5.4 Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shellx64.efi) from one of the available filesystem devices. 3.6.6 Event Logs 72 EAX-C236P User’s Manual...

  • Page 73: Change Settings

    Log OEM Codes Codes as OEM Codes (if not already Enabled[Default] converted to legacy). Enable or disable the converting of EFI Status Disabled[Default] Convert OEM Codes Codes to Standard Smbios Types (Not all may Enabled be translated). EAX-C236P User’s Manual 73...

  • Page 74: View Smbios Eventlog

    EAX-C236P User’s Manual 3.6.6.2 View Smbios EventLog 74 EAX-C236P User’s Manual...

  • Page 75: Drivers Installation

    User’s Manual 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. EAX-C236P User’s Manual 75...

  • Page 76: Install Chipset Driver

    Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step 3. Click Install. Step1. Click Next. Step 4. Complete setup. Step 2. Click Accept. 76 EAX-C236P User’s Manual...

  • Page 77: Install Vga Driver

    Step 2. Click Yes. SUPPORTED PRODUCTS: The Intel® Graphics Driver contains support for the following Intel Chipsets/Processors with the following graphic support: Intel® , Iris® Pro and Intel® HD graphics: ．6 Gen Intel® Core™ processor family (codename Skylake) (Workstation-Xeon) EAX-C236P User’s Manual 77...

  • Page 78: Install Me Driver

    Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Next Step 4. Click Finish to complete the setup Step 1. Click Next to continue setup. Step 2. Click Next. 78 EAX-C236P User’s Manual...

  • Page 79: Install Audio Driver (For Realtek Alc892 Hd Audio)

    Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step1. Click Next to Install. Step 2. Select Finish to complete Installation. EAX-C236P User’s Manual 79...

  • Page 80: Install Lan Driver

    Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Install. Step 2. Click Next. Step 5. Click Finish to complete setup. 80 EAX-C236P User’s Manual...

  • Page 81: Install Rst Driver

    Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 2. Click Next. Step 5. Click Finish to complete setup. EAX-C236P User’s Manual 81...
  • Page 82 EAX-C236P User’s Manual Step 6. Click Finish to complete setup. 82 EAX-C236P User’s Manual...

  • Page 83: Mechanical Drawing

    User’s Manual 5. Mechanical Drawing EAX-C236P User’s Manual 83...
  • Page 84 EAX-C236P User’s Manual Unit: mm 84 EAX-C236P User’s Manual...
  • Page 85 User’s Manual Unit: mm EAX-C236P User’s Manual 85...
