CHAPTER 2 Hardware Configuration

2.10 OPL (Operator panel)

2.9.2 Internal SSD

The SSD capacity in maximum configuration and the maximum LUN capacity in a RAID configuration are
listed in the table below.
TABLE 2.11 The SSD capacity in maximum configuration and the maximum LUN capacity in a RAID
configuration
RAID configuration
SAS (non-RAID)
SAS-RAID (RAID0)
SAS-RAID (RAID1)
SAS-RAID (RAID5)
SAS-RAID (RAID6)
SAS-RAID (RAID10) 12.8 TB
SAS-RAID
(RAID1E)
2.10 OPL (Operator panel)
The OPL (Operator panel) provides following functions.
- System LED control
The System LED control device (I2C LED driver) that displays the status of the System is mounted
- System FRU
The System FRU (I2C EEPROM) that stores the device information is mounted
- Intake air temperature sensor
A sensor to monitor the temperature of the intake air of the device is mounted
An overview of the OPL is shown below.
Maximum PRIMEQUEST capacity
(each 1.6 TB SSD)
2400E 2800E
25.6 TB 38.4 TB 12.8 TB
25.6 TB 38.4 TB 12.8 TB
12.8 TB 19.2 TB 6.4 TB
19.2 TB 28.8 TB 9.6 TB
12.8 TB 19.2 TB 6.4 TB
19.2 TB 6.4 TB
12.8 TB 19.2 TB 6.4 TB
45
Maximum LUN
2800B 1.6 TB SSD
1.6 TB
6.4 TB (x4)
1.6 TB (1+1)
4.8 TB (3+1)
3.2 TB (2+2)
3.2 TB (2x2)
3.2 TB (4/2)
C122-B025-02EN
