CHAPTER 2 Hardware Configuration
2.2 Base cabinet

FIGURE 2.4 PRIMEQUEST 2400E/2800E right view

FIGURE 2.5 PRIMEQUEST 2400E/2800E perspective view

FIGURE 2.6 PRIMEQUEST 2800B front view

31 C122-B025-02EN
