CHAPTER 2 Hardware Configuration
2.11 PCI_Box

2.11.5 PCI_Box component list

PCI_Box component list is shown below.
Component
PCI_Box
IO_PSU
IO_FAN
PEXU
PCIB
LNKC
PCI Express slot 12/PCIB

2.11.6 PCI_Box connection pattern

The PCI_Box is connected to the PCNC on the IOU.
One port on the PCI_Box is connected to one PCNC on the IOU by three PCI_Box connection cables (Two
PCI Express cables and one PCI_Box control cable).
Number of connectable PCI_Boxes is shown in below list.
Number of connectable devices
The diagram of the maximum PCI_Box connections is shown below.
For details on the connection conditions of the PCI_Box, see

FIGURE 2.23 PCI_Box connection diagram (maximum configuration) for mounted four IOU_1GbEs

TABLE 2.14 PCI_Box components

Unit
2/PCI _Box
2/PCI _Box
1/PCI _Box
1/PEXU
2/PCIB

TABLE 2.15 Number of connectable PCI_Boxes

Display format
PCI_Box#0, #1, #2, #3
IO_PSU#0, IO_PSU#1
IO_FAN#0, IO_FAN#1
PEXU
PCIB
LNKC#0, LNKC#1
PCIC#0, PCIC#11, etc.
PRIMEQUEST
2400E 2800E
4
'2.11.7 PCI _Box connection
51
Redundancy
Possible by option
Possible by option
Possible as standard
No
No
No
Possible by option
2800B
-
conditions'.
C122-B025-02EN
