Position the switch away from water and moisture sources, be sure to
◆
provide an acceptable temperature and humidity operating environment.
I
NSTALLATION
This switch can be either installed in a standard 19-inch mountable rack or
located on a desktop.
C
AUTION
the switch.
D I
ESKTOP NSTALLATION
To install the switch on the desktop, follow these steps:
Set the switch on a flat surface strong enough to support the entire weight
1.
of the switch with all fittings.
Remove the adhesive backing papers from the rubber feet.
2.
Turn the switch over and attach the supplied rubber feet to the recessed
3.
areas on the bottom at each corner of the switch.
Figure 4: Attaching Rubber Feet
Please unplug the power cord before installing or removing
:
C
HAPTER
– 21 –
| Installing the Switch
3

Installation
