Page 1: User Guide
USER GUIDE EZ Switch 10/100 16/24-Port Unmanaged Fast Ethernet Switches SMCFS1601/SMCFS2401... - Page 2 EZ Switch 10/100 User Guide From SMC’s EZ line of low-cost workgroup LAN solutions 20 Mason April 2011 Irvine, CA 92618 SMC-UG-0411-01 Phone: (949) 679-8000...
- Page 3 Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.
-
Page 4: Warranty And Product Registration
ARRANTY AND RODUCT EGISTRATION To register SMC products and to review the detailed warranty statement, please refer to the Support Section of the SMC Website at http://www.smc.com. – –... -
Page 5: Compliances And Safety Statements
OMPLIANCES AND AFETY TATEMENTS FCC - C LASS This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 6: C Ompliances And S Afety S Tatements
OMPLIANCES AND AFETY TATEMENTS – 6 –... -
Page 7: About This Guide
BOUT UIDE URPOSE This guide details the hardware features of the switch, including the physical and performance-related characteristics, and how to install the switch. UDIENCE The guide is intended for use by network administrators who are responsible for installing and setting up network equipment; consequently, it assumes a basic working knowledge of LANs (Local Area Networks). - Page 8 BOUT UIDE – 8 –...
-
Page 9: Table Of Contents
ONTENTS ARRANTY AND RODUCT EGISTRATION OMPLIANCES AND AFETY TATEMENTS BOUT UIDE ONTENTS NTRODUCTION Overview Features IEEE 802.1p QoS ARDWARE ESCRIPTION Front Panel Port and System Status LEDs RJ-45 Ports Rear Panel Grounding Terminal AC Power Socket NSTALLING THE WITCH Package Contents Precautions Safety Requirements Location Requirements... - Page 10 ONTENTS Powering On Connecting Network Devices Cabling Guidelines Connecting to PCs, Servers, Hubs and Switches ROUBLESHOOTING Diagnosing Switch Indicators The Power LED is Off The Link/Act LED is Off when a Device is Connected to the Corre- sponding Port Power and Cooling Problems Installation PECIFICATIONS Physical Characteristics...
-
Page 11: Introduction
NTRODUCTION VERVIEW The EZ Switch 10/100 SMCFS1601 and SMCFS2401 switches provide 16 or 24 10/100 Mbps auto-negotiating RJ-45 ports. Each port on the switches support auto MDI/MDI-X, which eliminates the need for crossover cables or uplink ports. The switches are plug-and-play; any port can be connected to a server, a hub, or a switch, using straight-through or crossover cable. -
Page 12: Ieee 802.1P Qos
HAPTER Overview IEEE 802.1 The SMCFS1601 and SMCFS2401switches support 802.1p priority queuing Quality of Service, which is an implementation of the IEEE 802.1p standard. With the 802.1p QoS function, network traffic that requires high priority, such as VoIP (Voice-over Internet Protocol), web browsing applications or video conferencing, can be forwarded before other traffic. - Page 13 | Introduction HAPTER Overview The SMCFS1601 and SMCFS2401 switches use Weighted Robin Round (WRR) for scheduling. The WRR queue-scheduling algorithm schedules all the queues in turn with every queue assured a certain service time. For both WFQ and WRR mode, the default weight values of TC0, TC1, TC2 and TC3 are 1:2:4:8.
- Page 14 | Introduction HAPTER Overview – 14 –...
-
Page 15: Description
ARDWARE ESCRIPTION This chapter describes the front panel, rear panel, and LED indicators of the switch. The SMCFS1601 and SMCFS2401 only differ in the number of ports. All figures in this guide are of the SMCFS2401. RONT ANEL The front panel of SMCFS2401 consists of switch LED indicators, and 24 10/100 Mbps RJ-45 ports. -
Page 16: Rear Panel
| Hardware Description HAPTER Rear Panel Table 1: System and Port Status LEDs (Continued) Condition Status 100Mbps On Green The port is operating at 100 Mbps. (SMCFS2401 only) The port is operating at 10 Mbps. RJ-45 P ORTS The switch contains 16/24 100BASE-TX RJ-45 ports. All ports support automatic MDI/MDI-X operation, so you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs. -
Page 17: Ac Power Socket
| Hardware Description HAPTER Rear Panel AC P OWER OCKET Connect the female connector of the power cord here, and the male connector to the AC power outlet. Make sure the voltage of the power supply meets the requirement of the input voltage. –... - Page 18 | Hardware Description HAPTER Rear Panel – 18 –...
-
Page 19: Installing The Switch
SMC distributor. Also be sure you have all the necessary tools and cabling before installing the switch. ACKAGE ONTENTS The following contents should be found in your package: One SMCFS1601 or SMCFS2401 Switch ◆ One power cord ◆ This User Guide ◆... -
Page 20: Precautions
| Installing the Switch HAPTER Precautions RECAUTIONS To ensure a long-term and stable performance of the switch, pay attention to the following before installation. AFETY EQUIREMENTS Before cleaning the switch, disconnect the power supply. Do not clean the ◆ switch using a wet cloth, and never use any other liquid for cleaning. Take waterproof measures during storage, transportation and operation of ◆... -
Page 21: Installation
| Installing the Switch HAPTER Installation Position the switch away from water and moisture sources, be sure to ◆ provide an acceptable temperature and humidity operating environment. NSTALLATION This switch can be either installed in a standard 19-inch mountable rack or located on a desktop. -
Page 22: Rack Installation
| Installing the Switch HAPTER Installation Upturn the switch and set in the desired location, making sure there is enough ventilation space on all sides for proper air flow Connect the switch to a power source with the provided power cord. See “Powering On”... -
Page 23: Connecting To Ground
| Installing the Switch HAPTER Installation Use suitable screws (not provided) to secure the brackets to the rack, as illustrated in the following figure. Figure 6: Mounting the Switch Connect the switch to a power source with the provided power cord. See “Powering On”... - Page 24 | Installing the Switch HAPTER Installation ONNECTING TO A ROUNDING When the switch is installed in an equipment room, where a grounding bar is available, you are recommended to connect the switch to the grounding bar as shown in the following figure. Figure 7: Connecting to a Grounding Bar 100-240V~ 50/60Hz 0.3A Switch (Rear Panel)
-
Page 25: Powering On
| Installing the Switch HAPTER Installation Figure 8: Connecting to Ground Through the Power Supply Switch (Rear Panel) AC Power Cord (with PE cable) The figure illustrates the application and principle. The power plug in the package and the socket in your situation will comply with regulations in your country, so they may differ from the figure above. -
Page 26: Connecting Network Devices
| Installing the Switch HAPTER Connecting Network Devices ONNECTING ETWORK EVICES The switches are designed to be connected to 10, or 100 Mbps network cards in PCs and servers, as well as to other switches and hubs. ABLING UIDELINES The RJ-45 ports on the switch support automatic MDI/MDI-X pinout configuration, so you can use standard straight-through twisted-pair cables to connect to any other network device (PCs, servers, switches, routers, or hubs). -
Page 27: A Troubleshooting
ROUBLESHOOTING IAGNOSING WITCH NDICATORS OWER Make sure the AC power cord is connected to the switch and power source ◆ properly. Make sure the power source is ON. ◆ FF WHEN A EVICE IS ONNECTED TO THE ORRESPONDING Make sure that the cable connectors are firmly plugged into the switch and ◆... -
Page 28: Installation
| Troubleshooting PPENDIX Installation NSTALLATION Verify that all system components have been properly installed. If one or more components appear to be malfunctioning (such as the power cord or network cabling), test them in an alternate environment where you are sure that all the other components are functioning properly. -
Page 29: Specifications
PECIFICATIONS HYSICAL HARACTERISTICS TANDARDS IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX OPOLOGY Star ROTOCOL CSMA/CD RANSFER Ethernet: 10 Mbps (half duplex) Ethernet: 20 Mbps (full duplex) Fast Ethernet: 100 Mbps (half duplex) Fast Ethernet: 200 Mbps (full duplex) ETWORK EDIA ABLE 10BASE-T: UTP Category 3, 4, 5 cable (maximum 100 m) EIA/TIA-568 100 STP (maximum 100 m) 100BASE-TX: UTP Category 5, 5e cable (maximum 100 m) - Page 30 10BASE-T: 14881 pps/port 100BASE-TX: 148810 pps/port RAME ORWARD 10BASE-T: 14881 pps/port 100BASE-TX: 148810 pps/port WITCHING ATABASE 8K MAC address entries UFFER EMORY 256 Kbyes/device WITCHING APACITY SMCFS1601: 3.2 Gbps SMCFS2401: 4.8 Gbps HROUGHOUT SMCFS1601: 2.4 Mpps SMCFS2401: 3.6 Mpps – 30 –...
- Page 31 | Specifications PPENDIX Physical Characteristics OWER EQUIREMENT SMCFS1601/2401: 100 to 240 V, 50-60 Hz, 0.3A IMENSIONS 29.4 x 18.0 x 4.4 cm (11.6 x 7.1 x 1.73 in.) EIGHT SMCFS1601: 1.287 Kg (2.83 lbs) SMCFS2401: 1.321 Kg (2.9 lbs) EATURE...
- Page 32 SMC NETWORKS TECHNICAL SUPPORT From Singapore in English and (Mon.-Fri. 9AM to 5 PM) Tel: +65-63387667, Ext. 4 From the United Arab Emirates in English (Sun.-Thu. 9AM to 6 PM) Tel: +971 800 222866/+971 4 3564810 From U.S.A. and Canada (24 hours a day, 7 days a week) Tel: +1 (800) SMC-4-YOU/+1 (949) 679-8000 Fax: +1 (949) 679-1481 su www.smc.com...
