SMC Networks FS1601 Datasheet

SMCFS1601/SMCFS2401
EZ Switch 10/100
TM
16-/24-Port Unmanaged Fast Ethernet Switches
Product Overview
The EZ Switches 10/100 (SMCFS1601/ SMCFS2401) are unmanaged,
rack-mountable 16-/24-port Fast Ethernet switches for workgroup and
small office environments. All 10BASE-T/ 100BASE-TX ports deliver
dedicated 10/100 Mbps links to each attached LAN segment – all with
conventional cabling and adapters. Auto-negotiation is used to select the
optimal communication mode for each connection, auto-sensing selects
the optimal transmission speed. With store-and-forward switching and flow
control, maximum data integrity is always maintained, even under heavy
loading. Environmentally friendly the switches consume less power than
non-Green Ethernet switches without reducing network performance. Easy
installation and reliability make these plug-and-play switches an ideal
choice for smooth Fast Ethernet integration in workgroup and small office
network environments.
Key Features and Benefits
Green Ethernet
Environmentally friendly these switches allow
significant power saving compared to non-
Green switches.
Support for Quality of Service
When the switches receive a frame tagged
with an 802.1p priority tag, they will place it
into a priority queue. Priority queuing is useful
in implementations where time-sensitive data
such as voice and video are streamed across
the network.
Auto MDI/MDI-X on each port
Support from Auto-MDIX means that no
cross-over cables are required. Simply plug
and play.
Metal chassis, fan-less design
The compact, rack mountable metal chassis
is ideal for desktop or rack mounting
applications. In addition, the lack of fans
ensures silent operation.
