SMC Networks SMCFS2601 Specifications

SMCFS2601
EZ Switch 10/100 Mbps
TM
26-Port Unmanaged Fast Ethernet Switch

Product Overview

The EZ Switch 10/100 SMCFS2601 is an unmanaged, rack-mountable
24-port Fast Ethernet switch with two Gigabit uplink ports. All 10BASE-T/
100BASE-TX ports deliver dedicated 10/100 Mbps links to each attached
LAN segment. Auto-negotiation is used to select the optimal
communication mode for each connection, auto-sensing selects the
optimal transmission speed. With store-and-forward switching and flow
control, maximum data integrity is always maintained, even under heavy
loading. Environmentally friendly, the switch consumes less power than
non-green switches without reducing network performance. Easy
installation and reliability make this plug-and-play switch an ideal choice
for smooth Fast Ethernet integration in workgroup and small office
network environments.
Key Features and Benefits
Performance and Scalability
This switch provides 8.8 Gbps wire-speed switching
performance across all 26 ports. This enables the switch to
fully support existing high-performance PCs and laptops,
which significantly improves application response times and
the speed of large file transfers.
Support IEEE 802.1p Quality of Service
When the switch receives a frame tagged with an 802.1p
priority tag, it is placed in the appropriate priority queue.
Priority queuing is useful in environments where
time-sensitive data, such as voice and video, are streamed
across the network.

Application Diagram

LEGEND
10G FIBER
1G FIBER
10G COPPER
1G COPPER
10/100
PoE
WIRELESS
Green Ethernet Support
The switch power consumption is much less than non-
green switches and can be as low as 15.1 W.
Auto MDI/MDI-X on Each Port
Support for Auto MDI/MDIX means that no crossover
cables are required. Straight-through cables can be used
for all connections.
Metal Chassis Fan-less Design
The compact, rack mountable metal chassis is ideal for
desktop or rack mounting. In addition, the lack of fans
provides silent operation.
