SMCFS1601/SMCFS2401
EZ Switch
10/100
TM
16-/24-Port Unmanaged Fast Ethernet Switches
Product Overview
The EZ Switch 10/100 SMCFS1601 and SMCFS2401 are unmanaged,
rack-mountable 16- and 24-port Fast Ethernet switches for workgroup and small
office environments. All 10BASE-T/ 100BASE-TX ports deliver dedicated 10/100
Mbps links to each attached LAN segment – all with conventional cabling and
adapters. Auto-negotiation is used to select the optimal communication mode for
each connection, auto-sensing selects the optimal transmission speed. With
store-and-forward switching and flow control, maximum data integrity is always
maintained, even under heavy loading. Environmentally friendly, the switches
consume less power than non-Green Ethernet switches without reducing network
performance. Easy installation and reliability make these plug-and-play switches an
ideal choice for smooth Fast Ethernet integration in workgroup and small office
network environments.
Key Features and Benefits
IEEE 802.3az Energy-Efficient Ethernet Support
When two 802.3az-compliant switches are connected, up to
49%* of power consumption can be saved.
Support for Quality of Service
When the switches receive a frame tagged with an 802.1p
priority tag, it is placed in the appropriate priority queue.
Priority queuing is useful in environments where time-
sensitive data, such as voice and video, are streamed across
the network.
Application Diagram
LEGEND
10G FIBER
1G FIBER
10G COPPER
1G COPPER
10/100
PoE
WIRELESS
Auto MDI/MDI-X on Each Port
Support for Auto-MDIX means that no crossover cables
are required. Straight-through cables can be used for all
connections.
Metal Chassis Fan-less Design
The compact, rack mountable metal chassis is ideal for
desktop or rack mounting. In addition, the lack of fans
provides silent operation.
* According to an IEEE 802.3az Energy Efficient Ethernet
measurement test conducted by an independent testing
company, the SMCFS1601 and SMCFS2401 save up to
49% when each is compared to a non-Green Ethernet
switch.
POWER TO CONNECT
www.edge-core.com
www.smc.com
