SECTION 2:
INSTALLATION
INSTALLATION PLANNING
Before beginning installation, make sure you have the necessary tools
and materials on hand and that pre-installation site preparation has been
accomplished.
TOOLS & MATERIALS
In addition to the contents of the
TOPCAT system, you will need the
following tools & materials:
• Flat Blade screwdriver (small)
• Pliers
• Wire cutters
• Drill
• Utility Knife
SITE PREPARATIONS
A schematic/wiring diagram of a
typical TOPCAT installation is shown
in the following figure:
NOTE: TOPCAT is designed for
installation in a 2' x 2' or 2' x 4'
suspended ceiling grid (or 600mm x
600mm international ceiling grids). If
you do not have this type of ceiling,
please contact your local Lightspeed
Classroom Audio Consultant.
Integrated
Sensor/
Receiver
Ampli er/
TX/RX
TOPCAT Module
Media Connector Module
Audio Mixer/TX/RX
