SIDE PANEL CONTROLS AND

CONNECTIONS

1. CH A VOLUME: Controls the

volume level for microphone set

to channel A. It is preset at the

factory to its 12 O'clock position.

Turn clockwise to increase volume

or counter clockwise to decrease

volume.

2. CH B VOLUME: Controls the

volume level for microphone

set to channel B. Turn clockwise

to increase volume or counter

clockwise to decrease volume.

3. AUX POWER INPUT

CONNECTOR (OPTIONAL):

For use during installations where

AC power is not available in the

ceiling. Accepts 24VDC, 2.5A

connector from an external power

supply.

4. PAGEFIRST INPUT AND ADJUST:

Connect the input from optional

PageFirst sensor when interfacing

with the buildings paging system.

Use the ADJ control to adjust the

sensitivity if needed.

5. REGISTRATION BUTTON: This

button is used to synchronize

the TOPCAT with the Media

Connector Module.

SIDE VIEW
