Connecting Contact Closure Switch Inputs - Philips iPlayer 3 User Manual

To connect Controller Keypad to the iPlayer 3:
1. Unplug the power cord from the iPlayer 3.
2. Select serial port 1 or 2.
3. Set the iPlayer 3 DIP switch to apply power to the selected
4. Choose the Controller Keypad power option:
5. Connect one end of the serial cable to the Controller Keypad.
Note: The maximum serial cable length is 50' (15.24m).
6. Connect the other end of the serial cable to the selected

Connecting Contact Closure Switch Inputs

The iPlayer 3 accepts input from any standard contact closure
switch via serial port 1 or serial port 2. Note that an optional
Color Kinetics' AuxBox is required for closure switch
connection.
Connecting the AuxBox to the iPlayer 3
1. Unplug the power cord from the iPlayer 3.
2. Select serial port 1 or 2.
3. Set the iPlayer 3 DIP switch to apply power to the selected
serial port. See iPlayer 3 DIP Switch Functions on page 22.
– Power the Controller Keypad via the iPlayer 3 serial
connection
– Power the Controller Keypad via an external source
The Controller Keypad power source selection is configured
via wiring. Refer to the Controller Keypad instructions for
details.
A serial cable is supplied with the Controller Keypad.
serial port on the iPlayer 3.
serial port. See iPlayer 3 DIP Switch Functions on page 22.
INSTALLATION
18
