– Design or load a show file in ColorPlay 3. Click the LIVE
PLAY button to initiate USB Mode and simulate your show
on your light fixtures.
6. End USB Mode by clicking DISCONNECT in the ColorPlay 3
configuration layer.
Note: While in USB mode, you cannot access standard
iPlayer 3 operational modes. End USB Mode to resume
normal iPlayer 3 functionality.

Setting Up the iPlayer 3 in Run Mode

Run Mode is used to play light shows.
In Run Mode, the iPlayer 3 controller is not connected to your
computer. The iPlayer 3 must be in Run Mode to play light
shows.
See Chapter 4 for details about Run Mode.
To set up the iPlayer 3 in Run Mode:
1. Using the supplied RJ-45 data cable, connect the DMX 1 port
or DMX 2 port to the light fixture(s) you want to use for
playback.
2. Disconnect the USB cable from the iPlayer 3.
The LCD screen will indicate
3. (Optional) Press the iPlayer 3
The LCD screen will read
Press the
Note: When you power on the iPlayer 3 or exit from USB Mode,
the iPlayer 3 automatically enters Run Mode and begins playing
the show assigned to show Preset 1 (the show assigned to
trigger 1). To switch to another show, press another Preset
button (2 through 5) or use an external switch such as the
Controller Keypad available from Color Kinetics.
RUN MODE
LIGHTS OFF
button again to resume Run Mode.
.
button to pause playback.
.
INSTALLATION
16
