Read this Owner's Manual carefully and
be sure your gas grill is properly assem-
bled, installed and maintained. Failure
to follow these instructions could result
in serious bodily injury and/or property
damage. This gas grill is intended for
outdoor use only and is not intended to
be installed in or on recreational vehi-
cles or boats.
Customer Service Helpline: If you have questions about assembly or grill operation, or if there are damaged or
missing parts when you unpack this unit from the shipping box, call us Monday through Friday at 1-800-752-3085
RV 021705
Owner's Manual
GE3BSSLP
GE3BSSNG
All barbecues and carts are designed for outdoor use only!
All barbecues are not intended for commercial use.
WARNING:
Note to Installer: Leave this Owner's
Manual with the consumer after delivery
and/or installation.
Note to Consumer: Leave this Owner's
Manual in a convenient place for future
reference.
WARNING:
GE4BSSLP
GE4BSSNG
Design Certified
Unit approved by
CSA Laboratories under standard
ANSI Z21-58b-2002/CGA 1.6b-2002
P/N P80151005A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Grand Endevator GE3BSSLP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Barbeques Galore Grand Endevator GE3BSSLP

  • Page 1 America's Barbecue Grill Superstores Owner’s Manual GE3BSSLP GE4BSSLP GE3BSSNG GE4BSSNG WARNING: All barbecues and carts are designed for outdoor use only! All barbecues are not intended for commercial use. WARNING: Read this Owner’s Manual carefully and Note to Installer: Leave this Owner’s...
