INSTRUCTION MANUAL
MODEL NUMBER: GBBK/GBBKR
Outdoor Portable Charcoal Grill
For Outdoor Use Only!
WARNING! BE CAREFUL OF SHARP EDGES DURING ASSEMBLY
MADE IN CHINA
Save these instructions for future reference. If you are assembling this unit for
someone else, give this manual to him or her to save for future reference.
Advertisement
Table of Contents
Related Manuals for Barbeques Galore GBBK/GBBKR
Summary of Contents for Barbeques Galore GBBK/GBBKR
- Page 1 INSTRUCTION MANUAL MODEL NUMBER: GBBK/GBBKR Outdoor Portable Charcoal Grill For Outdoor Use Only! WARNING! BE CAREFUL OF SHARP EDGES DURING ASSEMBLY MADE IN CHINA Save these instructions for future reference. If you are assembling this unit for someone else, give this manual to him or her to save for future reference.
- Page 2 Parts List and Hardware List Exploded View 1, Wire handle 2, Lid handle 3, Top hinge 4, Lid 5, Cooking grid 6, Charcoal grid 7, Ash receiver 8, Bottom bowl 9, Bottom hinge 10, Warming rack 11, Leg (4) 12, Bottom mesh Hardware List A.
-
Page 3: Assembly Instructions
Assembly Instructions DO NOT tighten screws until grill is completely assembled Step 1 Attach bottom mesh to leg (I Washer 4Pcs / D Wing nut 4Pcs). Step 2 Attach leg assembly to bottom bowl (B Screw 4Pcs / I Washer 4Pcs). - Page 4 Step 3 Attach wire handle to bottom bowl (I Washer 2Pcs). Step 4 Attach bottom hinge to bottom bowl (A Screw 2Pcs / E Heat resistant washer 2Pcs /H Washer 2Pcs / F Lock washer 2Pcs / C Wing nut 2Pcs).
- Page 5 Step 5 Attach lid handle to lid (E Heat resistant washer 2Pcs / I Washer 2Pcs / G Lock washer 2Pcs / D Wing nut 2Pcs). Step 6 Attach top hinge to lid (A Screw 2Pcs / E Heat resistant washer 2Pcs /H Washer 2Pcs / F Lock washer 2Pcs / C Wing nut 2Pcs).
- Page 6 Step 7 Attach top hinge to bottom hinge (J Pin 1Pc / K Cotter pin 1Pc). Step 8 Insert ash receiver into bottom bowl. Insert charcoal grid into bottom bowl. Insert cooking grid into bottom bowl.
- Page 7 Step 9 Cut zip tie on warming rack. Slide warming rack into holes in lid and bottom bowl. Note: Look for corresponding holes on side of lid. Insert short wire ends into lid holes, one side at a time. Position warming rack legs into slots on bottom bowl sides.
- Page 8 BARBECUE SAFETY HINTS 1. Stand your grill on a safe, level surface, away from flammable items such as wooden fences or over hanging tree branches. NEVER USE your grill indoors. 2. DO NOT use petrol, paraffin, methyl lated spirit or lighter fuel to light your charcoal. Special lighting fluid, pastes and fire lighters are available.
