Barbeques Galore STS2611ALP Operator's Manual

Barbeques Galore STS2611ALP Operator's Manual

Liquidpropanegas(lpg)grill & naturalgas (ng)grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

By Barbeques Galore
Liquid Propane Gas (LPG) Grill
Models STS2611ALP, STS2611BLP, STS3211ALP & STS3211BLP
Natural Gas (NG ) Grill
Models STS2611ANG, STS2611BNG, STS3211ANG & STS3211BNG
STS2611ALP/NG
FREE HELP
Grill Information Center:
FROM THE GRILL EXPERTS
Grand Hall is the expert on this product
and trained to help you with:
Ÿ
Assembly Questions
Ÿ
Grill Operation
Ÿ
Replacement of Damaged or Missing parts
visit www.grandhall.com or call:
1-877-934-7455
Monday - Friday 8:00am-4:30pm CST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL #
__________________
(see silver CSA label on main body of grill)
STS3211ALP/NG
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property damage.
Ÿ
Whether this grill was assembled by you or
someone else, you must read this entire manual
before using your grill to ensure the grill is
properly assembled, installed and maintained.
Ÿ
Use your grill at least 3 feet away from any
wall or surface. Use your grill at least 3 feet
away from combustible objects that can melt or
catch fire such as vinyl or wood siding, fences
and overhangs or sources of ignition including
pilot lights on water heaters and live electrical
appliances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR OUT-
DOOR USE ONLY.
Ÿ
Never use your gas grill in a garage, porch,
shed, breezeway or any other enclosed area.
Ÿ
Never obstruct the flow of ventilation air
around your gas grill housing.
Ÿ
Never disconnect the gas regulator or any gas
fitting while your grill is lit. A lit grill can ignite
leaking gas and cause a fire or explosion which
could result in property damage, personal injury
or death.
Operator's Manual
STS2611BLP/NG
WARNING
Manual # P80151035A - Date:2011/01/21
STS3211BLP/NG
!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STS2611ALP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Barbeques Galore STS2611ALP

Summary of Contents for Barbeques Galore STS2611ALP

  • Page 1: Primary Safety Warnings

    Operator's Manual By Barbeques Galore Liquid Propane Gas (LPG) Grill Models STS2611ALP, STS2611BLP, STS3211ALP & STS3211BLP Natural Gas (NG ) Grill Models STS2611ANG, STS2611BNG, STS3211ANG & STS3211BNG STS2611BLP/NG STS3211BLP/NG STS3211ALP/NG STS2611ALP/NG FREE HELP WARNING Grill Information Center: FROM THE GRILL EXPERTS Ÿ...

  • Page 2: Table Of Contents

    Table of Contents WARNING Primary Safety Warnings......1-3 Pre-Assembly Instructions........3 Do not store or use gasoline or other Part Diagrams and Lists......4-20 flammable liquids or vapors in the Assembly Instructions.........21-29 vicinity of this or any other appli- Use & Care Instructions: ances.

  • Page 3: Pre-Assembly Instructions

    Pre-Assembly Instructions For Your Safety CAUTION PRE-ASSEMBLY Read and perform the following pre-assembly instruc- tions: Failure to comply with these instructions may result Tools Required for Assembly in a hazardous situation which, if not avoided, may • protective work gloves result in injury.

  • Page 4: Part Diagrams And Lists

    S112G0306E Phillips Head Screw 3/16"x3/8" Install the Tank Holder Brackets (for STS2611ALP & STS3211ALP) S313G03051 Flange Nut 3/16" S112G0306E Phillips Head Screw 3/16"x3/8" Install the Bowl Brackets to the Cart (for STS2611ALP/NG & S313G03051 Flange Nut 3/16" STS3211ALP/NG) S112G0406E Phillips Head Screw 1/4"x3/8"...
  • Page 5 PART # PART DESCRIPTION PURPOSE OF PART P06006023A Hardware Pack For us e in as s em bly STS2611ALP & STS2611BLP S112G0406E Phillips Head Screw 1/4"x3/8" S182G0406E Pan Head Screw 1/4"x3/8" Ins tall Bowl Side Trim Brackets (for STS2611BLP) S313G04081 Flange Nut 1/4"...
  • Page 6 Hardware Parts List for Models STS3211ALP STS3211BLP & PART # PART DESCRIPTION PURPOSE OF PART P06006025A Hardware Pack For use in assem bly for STS3211ALP & STS3211BLP S112G0406E Phillips Head Screw 1/4"x3/8" S182G0406E Pan Head Screw 1/4"x3/8" Install Bowl Side Trim Brackets (for STS3211BLP) S313G04081 Flange Nut 1/4"...
  • Page 7 Hardware Pack for Models STS2611ANG & STS2611BNG PART # PART DESCRIPTION PURPOSE OF PART P06006024A Hardware Pack For use in assembly for Models STS2611ANG & STS2611BNG S112G0406E Phillips Head Screw 1/4"x3/8" Install Bowl Side Trim Brackets (for STS2611BNG) S182G0406E Pan Head Screw 1/4"x3/8" S313G04081 Flange Nut 1/4"...
  • Page 8 Parts Diagram for Models STS2611ALP/NG...
  • Page 9 Parts List for Model STS2611ALP/NG DESCRIPTION PART# Lid Assembly P001462764 Temperature Gauge P00601071A Lid Handle Bracket, Left P03303124A Lid Handle Bracket, Right P03303125A Lid Handle P00218001R Protective Pad P05518002I Cooking Rack/Secondary P01505009K Cooking Grid, 13" P01604013B Burner/Main P02003003B P01804012A Flame Tam er/Ceramic, Front...
  • Page 10 Parts List for Models STS2611ALP/NG DESCRIPTION PART# Cart Side Panel, Right P076180494 Door Hinge Bracket, Upper Left P033020144 Door Hinge Bracket, Upper Right P033020154 Door Hinge, Left/Lower P033020374 Door Hinge, Right/Lower P033020384 Cart Bracket, Front P033050744 Tank Holder Assembly (LPG)
  • Page 11 Parts Diagram for Models STS3211ALP/NG...
  • Page 12 Parts List for Models STS3211ALP/NG DESCRIPTION PART# Lid Assembly P001473364 Temperature Gauge P00601071A Lid Handle Bracket, Left P03303124A Lid Handle Bracket, Right P03303125A Lid Handle P00218002R Protective Pad P05518002I Cooking Rack/Secondary P01516004B Cooking Grid, 13" P01604013B Burner/Main P02003003B Infrared Burner P02005026B Flame Tam er/Ceramic, Front P01804012A...
  • Page 13 Parts List for Models STS3211ALP/NG DESCRIPTION PART# Cart Bottom Shelf P010020714 Door Hinge Bracket, Upper Left P033020144 Door Hinge, Left/Lower P033020374 Cart Side Panel, Left P076170484 Side Shelf Bracket, Rear P033110454 Cart Bracket, Front P033050804 Side Shelf Bracket, Front P033110424 Tank Holder Assembly (LPG) P053580034 Tank Tray...
  • Page 14 Parts Diagram for Models STS2611BLP/NG...

  • Page 15: Cooking Grid

    Parts List for Models STS2611BLP/NG DESCRIPTION PART# Lid Assembly P001462764 Temperature Gauge P00601071A Lid Handle Bracket, Left P03303124A Lid Handle Bracket, Right P03303125A Lid Handle P00218001R Protective Pad P05518002I Cooking Rack/Secondary P01505009K Cooking Grid, 13" P01604013B Burner/Main P02003003B P01804012A Flame Tam er/Ceramic, Front P01804013A Flame Tam er/Ceramic, Rear P01720038B...
  • Page 16 Parts List for Models STS2611BLP/NG DESCRIPTION PART# Rotisserie Burner Wind Shield P069060824 Therm ocouple for Rotisserie Burner P05305062A Rotisserie Burner Electrode P02614025A Rotisserie Burner Fram e P020110654 Electric Ignitor Protector P03328048Q Regulator with Hose Assembly (NG) P03614007A Bracket for NG Regulator (NG) P033040544 Tank Holder Bracket, Left (LPG) P03304055F...
  • Page 17 Parts Diagram for Models STS3211BLP/NG...

  • Page 18: P01604013B

    Parts List for Models STS3211BLP/NG DESCRIPTION PART# Lid Assembly P001473364 Temperature Gauge P00601071A Lid Handle Bracket, Left P03303124A Lid Handle Bracket, Right P03303125A Lid Handle P00218002R Protective Pad P05518002I Cooking Rack/Secondary P01516004B Cooking Grid, 13" P01604013B Burner/Main P02003003B Infrared Burner P02005026B P01804012A Flame Tam er/Ceramic, Front...

  • Page 19: P033280494

    Parts List for Models STS3211BLP/NG DESCRIPTION PART# Regulator with Hose (LPG) P03601043A Lighting Stick P05313022B Electric Wire Set P02627010A Rotisserie Burner Wind Shield P069060824 Thermocouple for Rotisserie Burner P05305051A Rotisserie Burner Electrode P02614025A Thermocouple Bracket/Rotisserie Burner P033280494 Rotisserie Burner Fram e P020110664 Thermocouple for Infrared Burner P05305050A...
  • Page 20 Rotisserie Assembly Parts Diagram Rotisserie Assembly Parts List PART# DESCRIPTION P05508177F Rot. Collar S196G04084 Rot. Thumbscrew 1/4"x1/2" P05508202F Rot. Spit (for STS2611ALP/NG Models) P05508203F Rot. Spit (for STS3211ALP/NG Models) P05508023F Rot. Holding Fork P05508174F Rot. Motor Bracket P07101039B Rot. Motor/AC S112G10124 Rot.

  • Page 21: Assembly Instructions

    Assembly Instructions for STS2611ALP/NG & STS3211ALP/NG CAUTION : While it is possible for one person to assemble this grill, obtain assistance from 2 people when handling some of the larger, heavier pieces. Install Tank Holder Brackets and Tank Holder Assembly (for STS2611ALP &...

  • Page 22: P055010174

    Install Bowl to the Cart With the help of your assistants, lift the Bowl on to the top of the Cart so that the bottom of the bowl sits on top of the Bowl Brackets. Insert the 4 Pan Head Screws 1/4"x1-3/16"(reserved from Step 2) into the Cart as shown below. Tighten and secure the screws.

  • Page 23: P055360014

    Install Hose Holders (for STS2611ALP & STS3211ALP Models) Install 2 Hose Holders on the Left Cart Side and Rear Panels, Secure using 4 Phillips Head Screws 3/16"x3/8" and 4 Flange Nuts 3/16". The Regulator Hose should sit inside the Hose Holders.
  • Page 24 Install the Transformer. Connect Transformer to Power Source and turn on Grill Lights. (for STS3211ALP/NG Models) Remove Transformer from box (the transformer is in Grill Head). Install Transformer-Plug into Transformer-Socket and tighten securely. (See Fig. 1) Install Transformer to the Right Cart Panel by using 4 Phillips Head Screws 3/16"x1/2" and tighten using 4 Hex Nuts 3/16".
  • Page 25 Assembly Instructions for STS2611BLP/NG & STS3211BLP/NG CAUTION : While it is possible for one person to assemble this grill, obtain assistance from 2 people when handling some of the larger, heavier pieces. Install Bowl Side Trim Brackets Install Left Bowl Side Trim Bracket to Left Bowl Panel using 6 Phillips Head Screws 1/4"x3/8" Then tighten using 4 Flange Nuts 1/4"...
  • Page 26 Install the Transformer. Connect the Transformer to Power Source and turn on the Grill Lights. (for STS3211BLP/NG Models) Remove Transformer from box (the transformer is in Grill Head). Install Transformer-Plug into Transformer-Socket and tighten securely. (See Fig. 1) Install Transformer to the Rear Island Panel* by using 4 Phillips Head Screws 3/16"x1/2". Secure and tighten using 4 Hex Nuts 3/16".
  • Page 27 Remove the LP Regulator and Install the Regulator Hose Connector Remove the LP Regulator from the Manifold as shown in Figure 1. Install the Regulator Hose Connector to the LP Regulator Hose as shown in Figure 2. Regulator Hose Connector Figure 1 Figure 2 CAUTION: Build your grill island before installing the LP Gas Tank and Partition Panel (Not included in this...
  • Page 28 Install Partition Panel (for STS2611BLP & STS3211BLP Models) Install the Partition Panel (not included in this unit) to the left island. Make sure there is 22-24" of clearance between the partition panel and the Tank Holder Assembly. Vent Openings must Partition Panel be at least 1/8"...
  • Page 29 "clicking" sound as the burner is being ignited. Your assistant should see a blue spark within each Gas Collector Box. If (for STS2611ALP/NG & STS2611BLP/NG Models) a spark is present the Electrode Tips are properly positioned.

  • Page 30: Use & Care Instructions

    Never allow children to operate your grill. Do not allow children or pets to play near your grill. Always supervise WIND DIRECTION children and pets if they are in the vicinity of the unit. (for STS2611ALP/NG & STS3211ALP/NG Models)
  • Page 31 USE AND CARE INSTRUCTIONS WARNING NOTE about LP Gas Tank Exchange Programs Ÿ Many retailers that sell grills offer you the option of replacing your empty LP Gas tank through an exchange service. Use only those reputable exchange compa- Refer to the this table when designing the island unit nies that inspect, precision fill, test and certify their for the STS2611BLP/NG &...
  • Page 32 USE AND CARE INSTRUCTIONS LP Gas Model only: Secure a 20lb LP Gas Tank to Gas Grill Secure a 20lb LP Gas Tank to Gas Grill (for STS2611BLP & STS3211BLP) Note: You can only use a 20lb LP Gas Tank in this Turn your LP Gas Tank Valve clockwise to the Gas Grill.
  • Page 33 USE AND CARE INSTRUCTIONS LP Gas Model only: Check all connections for LP Gas Leaks Connect Regulator with Hose to your LP Gas Tank Never test for leaks with an open flame. Prior to first use, at the beginning of each season, or every time Turn all Burner Valves to the OFF position.

  • Page 34: Natural Gas Connection

    Natural Gas Connection Fig.1 Natural Gas Model only: Connecting Natural Gas To Your Grill Connect the Swivel nut of the 12' Natural Gas Hose to the horizontal fitting of NG Regulator as shown in Fig.1. Connect the other hose end (male plug) to the gas supply line from your Horizontal Fitting home.

  • Page 35: Lighting Instructions

    Burner instructions in this manual. Do not smoke while lighting your grill or when checking the gas supply (for STS2611ALP/NG & STS2611BLP/NG Models) connections. Be sure that the LP Gas tank is filled, and lock Casters to prevent movement during grill operation.

  • Page 36: Troubleshooting

    USE AND CARE INSTRUCTIONS Manually Lighting Your Grill By Paper Match Troubleshooting If the grill fails to light : To light your gas grill by match, insert a match into the Lighting Stick and follow steps 1 through 5 of the Grill Lighting Turn gas off at source and turn Control Knobs to OFF.
  • Page 37 USE AND CARE INSTRUCTIONS WARNING CORRECT ROTISSERIE USE Read all instructions before initial use. IMPORTANT: When using electrical appliances, basic safety precautions should always be used. To protect against electrical shock, do not immerse The Rotisserie Motor is set for 120V, 60Hz AC current. electrical cord, plugs or motor in water or expose to The Rotisserie is for outdoor use only.

  • Page 38: Rotisserie Instruction

    Rotisserie Instructions 1. Remove all components from the carton. Attach the Motor Bracket on the outside of the right grill bowl panel. Align the two holes of the Bracket with the holes on the grill bowl. Tighten securely using two Screws #10-24x3/4" UNC, Plain Washers and Nuts provided.
  • Page 39 Install the AC (alternating current) Rotisserie Motor onto the Motor Bracket as shown below. Be sure the Motor attaches to the Bracket with the electrical cord down. This installation insures that once the Spit is inserted into the Motor it will also rest securely into the slot of your grill bowl. Rotisserie Motor Rotisserie Spit must rest securely into the slot of your grill bowl.

  • Page 40: Cleaning And Maintenance

    Cleaning Exterior Stainless Steel Surfaces: CLEANING AND MAINTENANCE Routine care and maintenance is required to preserve Proper care and maintenance will keep your grill in top operating the appearance and corrosion resistance of stainless condition and prolong its life. Follow these cleaning procedures on steel.
  • Page 41 2. 2. CLEANING THE BURNER TUBES AND BURNER PORTS Regardless of which Burner cleaning procedure you To reduce the chance of FLASHBACK FIRE you must clean the Burner Tubes as follows at least once a month in summer use, we recommend that you also complete the follow- ing cleaning regimens to help prolong Burner life.
  • Page 42 Cooking Instructions Indirect Cooking using Main Burners Burn-Off The indirect cooking method can also be used with the Before cooking on your gas grill for the first time, you supplied Cooking Grids. To cook indirectly, the food should "burn off" the grill to eliminate any odor or foreign should be placed on the left or right side of your grill with matter.
  • Page 43 Guide to Grilling using the Main Burners and Direct Cooking Method Approximate Cooking Times Grilling Steak and Ribs Cut of Meat Rare: 4-8 minutes Turn the grill Burners on Hi, close the Lid and preheat your T-bone steak Medium: 10-14 minutes grill 3 to 5 minutes.
  • Page 44 Guide to Searing using the Infrared Cooking Zone Important notes about using the Infrared Burner • Once lit, leave the Infrared Burner on High and sear both sides of meat using the guidelines below. Whether you are a seasoned chef or a newcomer to gas •...
  • Page 45 Guide to Roasting and Baking Using the Main Burners Food preparation An Important Note About Heat Settings Trim meat of excess fat. Truss meat and poultry with cooking The suggested heat settings shown are approximate. There string to retain shape if desired. Bacon strips can be used to are many factors such as outside temperature, wind condi- cover the outside surface of lean meat and poultry to help tions and grill location that affect your grill performance.
  • Page 46 Guide to Rotisserie Cooking Guide to Smoking Slow Cooking with a Rotisserie Preparing to Smoke Rotisserie cooking produces foods that are moist, flavor- Smoking gives food a distinctive, delicious flavor. You will find ful and attractive. The rotisserie system is most com- a variety of wood chips available for use in smoking grilled monly used for cooking meat or poultry and is designed foods.
  • Page 47 Question: Question: Can I convert my grill from one fuel type to another in Sometimes I hear a humming sound coming from my other words from LPG to NG or vice versa? regulator. What causes this? And - My grill has a low flame and sometimes will not light.
  • Page 48 Question: The Regulator and Hose supplied with my gas grill After every use (after your grill has cooled down), wipe stain- does not fit the older LP Gas tank I’ve used for years. less surfaces with a soft, soapy cloth or sponge then Why not? rinse with water.
  • Page 49 Grand Home Holdings dba Barbeques Galore Limited Warranty Barbeques Galore will warrant to the ORIGINAL PURCHASER of this gas grill that it will be free of defects in material and workmanship for set periods below from the date of purchase when used under normal outdoor use and correct assembly.
