ASSEMBLY AND OPERATION INSTRUCTIONS
USE ONLY THE GAS HOSE AND HOSE CONNECTOR PROVIDED!
If a replacement is necessary, please contact your store of purchase
Tools Required:
1x Phillips Head Screwdriver
1x Adjustable Spanner
FOR OUTDOOR USE ONLY- OPERATES ON LPG
Important！ Please read these instructions carefully before use.
Retain these instructions for future reference
Gas Consumption
Number
Model
of BBQ
Pressure
Burners
KYQ-
4
2.75kPa
G41S-G
Connoisseur Code: G4CNSM
Model: KYQ-G41S-G
The use of unauthorised parts can create unsafe conditions
Gas
Gas Type
Injector
kPa
￠0.85mm
Propane
Main Burner
Gas
Consumption
Size
(each)
9.36MJ/h
Side Burner
Injector
Gas
Size
Consumption
￠0.85mm
9.36MJ/h
Total Gas
Consumption
MJ/h
46.8MJ/h
Advertisement
Table of Contents
Related Manuals for Barbeques Galore KYQ-G41S-G
Summary of Contents for Barbeques Galore KYQ-G41S-G
- Page 1 Connoisseur Code: G4CNSM ASSEMBLY AND OPERATION INSTRUCTIONS Model: KYQ-G41S-G USE ONLY THE GAS HOSE AND HOSE CONNECTOR PROVIDED! If a replacement is necessary, please contact your store of purchase The use of unauthorised parts can create unsafe conditions Tools Required:...
-
Page 2: Safety First
SAFETY FIRST Hazardous fire or explosion may result if instructions are ignored It is the consumer’s responsibility to see that the barbeque is properly assembled, installed, and maintained. Failure to follow instructions in this manual could result in bodily injury and/or property damage. - Page 3 IMPORTANT: READ ALL OPERATING INSTRUCTION BEFORE LIGHTING. 1. Do not perform any servicing on the barbeque yourself. This includes internal adjustment of the regulator and gas valves. Servicing can only be carried out by authorised technicians. 2. When cylinder is replaced or reconnected, always check carefully for leaks as outlined later in this manual.
- Page 4 ONLY USE THIS BARBEQUE OUTDOORS. This barbeque must be only used in an above ground open air situation with natural ventilation, without stagnant areas, where any gas leakage and products of combustion are rapidly dispersed by wind and natural convection. Do not obstruct the flow of combustion air to the burner when the barbeque is in use.
- Page 5 Gas Cylinder Safety Before assembling your barbeque, you should ensure your barbeque is suited to the type of gas which you are going to use. This is a low pressure barbeque and must only be used with the hose and regulator supplied. Your barbeque is designed for use with 4kg or 9Kg refillable propane cylinders.
-
Page 6: Warning Information
OTHER IMPORTANT POINTS: Strong winds and low temperatures can affect the heating and performance of your gas bbq, so factor in these elements when positioning your barbeque outdoors for cooking. Never use your gas barbeque in a garage, porch, shed, breezeway or any other enclosed area. Your gas barbeque is to be used outdoors only, at least 60cm from the back and side, 100cm from above for any combustible surface. - Page 7 Part List: G4CNSM...
- Page 8 Part qty per Qty per part Parts # GLG CODE GLG DESCRIPTION Code Complete hood without temperature gauge, KYQ-G4SM-1 handle or buffers Hood Glass KYQ-G4SM-6 Temperature Gauge KYQ-G4SM-11 KYQ-G4S00-3 Hood Handle Protective pad-front KYQ-G4S00-4 Protective pad-rear Warming rack KYQ-G4S00-6 Hotplate KYQ-G4S00-7 Cooking Grill KYQ-G4S00-8...
-
Page 9: Assembly Instructions
Hard Ware List: G4CNSM Description Quantity M4×10mm Screw M6×12mm Screw M6×20mm HEX Screw ￠6 Lock Washer ￠6 Flat Washer ASSEMBLY INSTRUCTIONS WARNING: Whilst every effort has made in manufacture of your barbeque to remove any sharp edges, nevertheless, you should handle all components with care to avoid accidental injury. Tools required: Standard Philips crosshead screwdriver and an adjustable spanner. - Page 10 STEP 4 STEP 3 # 53 # 48 # B M6×12mm×4 PCS # B M6×12mm×6 PCS STEP 5 STEP 6 # 46 # 47 # 46 # 47 # 45 # 45 # C HEX M6×20mm×4 PCS # D ￠6 Lock Washer×4 PCS # E ￠6 Flat Washer×4 PCS...
- Page 11 STEP 7 STEP 8 # 50 # 51 # 43 # 42 STEP 9 # B M6×12mmx2 PCS # 40 # 38 # A M4×10mm×2 PCS...
- Page 12 STEP 10 # B M6×12mm×4 PCS STEP 11 Loosen the prefitted screws (both side), keep 6mm gap, as shown.
- Page 13 STEP 12 # 35 # 34 Hang the side tables on the pre-fixed screws, then tighten the screws with a screwdriver Remove the nut from the nozzle assembly, attach the nozzle assembly through the hole in the bracket, and fix with the nut, as shown. Tighten firmly.
- Page 14 STEP 13 # 36 Ignitor wire # 41 # A M4×10mm×2 PCS Make sure the burner is engaged onto the nozzle! STEP 14 Ref # 18...
- Page 15 STEP 15 # 15 # 31 # 16 # 17 Connecting to a portable LPG cylinder Hang the LPG cylinder to the cylinder hook on the left side of the barbeque. Before connecting the cylinder, inspect the hose fittings and rubber seals. If there is any sign of splitting or wear.
-
Page 16: To Check For Leaks
BEFORE USE CHECK FOR LEAKS Never check for leaks with a naked flame, always use a soapy water solution TO CHECK FOR LEAKS: Make 100 ml of leak detecting solution by mixing one part washing up liquid with 3 parts water. Ensure all the barbeque control valves are “OFF”. - Page 17 If you wish to turn the complete barbeque ”OFF” turn the cylinder valve to the “OFF” position and then turn the control knob on the appliance clockwise to the “OFF” position. Before cooking for the first time, operate the barbeque for about 15 minutes with the lid closed and the gas turned on “LOW”.
-
Page 18: Troubleshooting
Remove cooking grill and hotplate. Clean the burner with a soft brush or blow clean with compressed air and wipe with a cloth. Clean any clogged ports with a pipe cleaner or stiff wire (such as an opened paper clip). Inspect burner for any damage (cracks or holes). - Page 19 Motor kit Ref # Description Motor Motor mounting bracket Rotisserie bracket M6 nut M6X12 screw Rotisserie shaft kit Ref # Description Meat prong (including locking screw) Locating ring (including locking screw) Rolling ring Rotisserie shaft tail Handle Rotisserie shaft...
- Page 20 How to maintain your BBQ: 1 Wipe over the stainless steel surface with rust resistant oil or 3N Stainless Steel Cleaner & Polish when you store the barbeque or after use. 2.Fit a rainproof cover over the BBQ when it is not in use. Use a vented cover, and/or add a couple of sponges under the cover to promote ventilation between the cover and the bbq.
-
Page 21: Data Plate
Data plate: Manufactured by: GUANGDONG KANGYE ELECTRIC APPLIANCE CO., LTD Need More Information? Call your local Barbeques Galore, our barbeque experts will be happy to help: Phone: 1 300 301 392 Or visit us online at: www.barbequesgalore.com.au Barbeques Galore GLG Australia Pty Ltd (ABN 70 001 185 002) Building A2, Campus Business Business Park, 350-374 Parramatta Road.
