Physical; Electrical; Environmental - ProCurve 420 Installation And Getting Started Manual

Specifications

Physical

Width:
Depth:
Height:
Weight:

Electrical

Adapter
AC voltage:
DC voltage:
Power consumption:
PoE (DC)
Input voltage:
Note: Power can also be provided to the access point through the Ethernet
port based on IEEE 802.3af Power over Ethernet (PoE) specifications. The
accees point is a Class 0 device, that is, the maximum power required is in the
range of 0.44 to 12.95 watts. When both PoE is provided and the adapter is
plugged in, PoE is turned off.

Environmental

Temperature:
Relative humidity:
(non-condensing)
Maximum altitude:
21.83 cm (8.60 in)
13.73 cm (5.40 in)
3.27 cm (1.29 in)
0.80 kg (1.76 lbs)
100-240 volts, 0.4A, 50/60 Hz
3.3 volts, 4A
13.2 watts
-48 VDC, 0.15A, 7.2 watts
Operating
0° C to 40° C (32° F to 104° F)
15% to 95% at 40°C (104°F)
3.05 Km (10,000 ft)
Non-Operating
-40° C to 70° C (-40° F to 158° F)
90% maximum at 65° C (149° F)
4.6 Km (15,000 ft)
A
A-1
