Back of the Access Point

hp procurve
wireless AP
420 na
J8130B
Console port
Lock

Antennas

The access point includes diversity antennas for wireless communications.
These antennas are detachable and can be replaced by various external
antenna options. For further information, see chapter 4, "Using an External
Antenna with the Access Point 420".
Lock
The access point includes a Kensington security slot on the rear panel, marked
with the lock symbol (
access point by wrapping the Kensington security cable (not provided) around
an unmovable object, inserting the lock into the slot, and turning the key.
Introducing the ProCurve Wireless Access Point 420
ProCurve Wireless Access Point 420
Antennas
Console 10/100Base-TX
Reset button
Network port
10/100Base-TX RJ-45
port and PoE input
). You can prevent unauthorized removal of the
Back of the Access Point
Reset
3.3V 4A
DC power connector
1-5
