Installing the Access Point 420
Installation Procedures
N o t e
If mounting the access point in an air conditioning or heating duct, leave the
cover on to aid in mounting the unit on the bracket as described in the
preceding steps. The unit's plastic cover should then be removed for safety
reasons.
5/8-inch
wood screws
2-8
Mounting the Bracket on a Wall
Sliding the Access Point onto the Bracket
Mounting
slots
Alignment tabs
Retaining
latches
Mounting
points
Alignment slots
