Using an External Antenna with the Access Point 420

External Antenna Options

External Antenna Options
The Access Point 420 external antenna options are outlined in the following
table:
Table 4-1.
Antenna Type
5 dBi indoor/outdoor
omnidirectional
8 dBi outdoor omnidirectional
3 dBi indoor omnidirectional
diversity
7 dBi indoor/outdoor directional
4-2
Summary of External Antennas to Use for the Access Point 420
Part Number Mounting
J8441A Ceiling or mast
J8444A Mast
J8997A Ceiling grid
J8999A Flush wall mount with
integrated
articulating feature
Horizontal Vertical
Beamwidth (3dB) Beamwidth (3dB)
360 Degrees 31 Degrees
360 Degrees 12 Degrees
360 Degrees 70 Degrees
68 Degrees 66 Degrees
