powersoft M30D HDSP+ETH User Manual page 8

1 2 3
6 7
9
8
PAT. PEND.
FIGURE 6: M Series – MxxQ (non HDSP+ETH) rear panel view.
PAT. PEND.
18
1. Channel 1 input attenuator
2. Channel 1 meter LEDs
3. Channel 2 meter LEDs
4. Channel 2 input attenuator
5. On/off power switch
6. Channels 1&2 ready LED
7. Channels 1&2 temperature warning LED
8. AC mains power plug
9. Air vents
4
CLIP
6dB
-18dB
SIGNAL
- +32 - +32
dB dB
READY TEMP
FIGURE 5: M Series – MxxQ front panel view.
Made in Italy
12
Made in Italy
FIGURE 7: M Series
19 20 21 22 23
rear panel view.
10. Channels 3&4 line input XLR connector
11. Channels 1&2 line input XLR connector
12. Channel 4 output Speakon connector
13. Link switch channels 3-4
14. Channel 3 output Speakon connector
15. Channel 2 output Speakon connector
16. Link switch channels 1-2
17. Channel 1 output Speakon connector
10
13 14 15
HDSP+ETH
18. Amplifier's remote ID selector
19. Preset LEDs
20. Preset selector button channels 3&4
21. Preset selector button channels 1&2
22. AUX supply plug
23. Ethernet port
5
11
16 17
