MN/22137, rev 1
This command will force the selected Demod to its Home State configuration,
replacing its current configuration.

STDMA State

This command (enter T) toggles the setting of STDMA in the target
CDD-56X's Home State between Enabled and Disabled. This is the same
feature that is set from the Feature Configuration menu screen shown in
figure 3-4. Setting the STDMA State to Enabled is only applicable for a
CDD-56X that is configured as a Hub burst controller.
Note: Only one demod can be set with STDMA enabled. Vipersat recommends
NOTE

Receive Frequency

Enter M to use the dialog shown in figure 3-64 to set the Receive Frequency
for the selected Demod's Home State.
Note that this screen dialog example displays the frequency range for a CDD-
562L/564L L-Band Demodulator/Router. For a CDD-564, the range displayed
will be either 50 to 90 MHz or 100 to 180 MHz.

Receive Data Rate

Enter N to use the dialog shown in figure 3-65 to set the Receive Data Rate for
the selected Demod's Home State.
C h ap t e r U s i n g t h e C o m m a n d L in e I n t e r f a c e ( C L I )
3 -
Figure 3-63
that Demod 1 be utilized for applications calling for STDMA.
Figure 3-64
Force Modem to Home State warning
Receive Frequency prompt
V i p er s at C o n f i g u r a t io n
3-49
