- Page 1 Marshall M-CT5 Camera-Top Monitor Owner’s Manual M-CT5 C a m e r a - To p M o n i t o r Owner’s Manual...
- Page 2 M-CT5 Camera-Top Monitor Owner’s Manual Dear users: Thank you for purchasing Marshall’s M-CT5-CE6 HD DSLR LCD Moni- tor. This 5” Pro HD LCD Monitor is designed to be used as an external video display, allowing you to step back from the camera while still being able to frame and capture the action without having to look through the camera’s built-in viewfi...
-
Page 3: Table Of Contents
Marshall M-CT5 Camera-Top Monitor Owner’s Manual To ensure the best use of this product, please read this manual carefully beforehand. CAUTION 1. Please use the adapter attached in the accessory or another quali- fi ed adapter. 2. Please do NOT expose this product to direct sunlight, heat, or humid conditions. -
Page 4: Product Description
Marshall M-CT5 Camera-Top Monitor Owner’s Manual Product Description Panel Instruction 1. Volume down to adjust the value setting function 2. Volume up or to adjust the value setting function and activate the volume adjust menu 3. MENU: To activate OSD menu 4. -
Page 5: Back View
Marshall M-CT5 Camera-Top Monitor Owner’s Manual Back view 10. HDMI input jack 11. HDMI output jack 12. 3.5mm headphone jack 13. Power on/off 14. Battery mount 15. DC12V input jack 16. Video In 17. Audio In 1/4inch Fixed hole There is a 1/4 standard screw bracket fi xed hole on the top and bottom of the monitor for mounting the monitor and mounting accessories onto the monitor. -
Page 6: Battery Plate
Marshall M-CT5 Camera-Top Monitor Owner’s Manual battery plate Battery plate: To power the monitor with the Canon LP-E6 (equivalent) battery. Battery installation Side Suggestion: Remove the battery for long periods of inactivity. Sunhood installation and Removal Attach the self adhesive side of the Velcro® to the side of the monitor. -
Page 7: Power Input
Marshall M-CT5 Camera-Top Monitor Owner’s Manual 2. Power input The monitor can be powered by the enclosed CE6 or equivalent battery or by a 12V power adapter (optional). Please note the input polarity is Positive with respect to --○-+, otherwise will damage the monitor! 3. - Page 8 Marshall M-CT5 Camera-Top Monitor Owner’s Manual ¤ Color temperature: Enter into (color) menu, press “◄” or “►” on the unit to confi rm, press ”▲” or “▲” to select the form of color tempera- ture, then press “◄” or “►” on the unit to confi rm, then use “▲” or ”▼”...
- Page 9 Marshall M-CT5 Camera-Top Monitor Owner’s Manual ¤ H Position: To adjust the OSD position in horizontal, ¤ V Position: To adjust the OSD position in vertical. ¤ OSD Timeout: To adjust the clock. ¤ Transparent: To adjust the level of transparent.
- Page 10 Marshall M-CT5 Camera-Top Monitor Owner’s Manual Sound After select “sound”, press “◄” or “►” button to confi rm, then enter into parameters adjust. Using “▲” or ”▼” button to select adjustable items, then using “◄” or “►” button to adjust the parameters.
-
Page 11: Parameters
Marshall M-CT5 Camera-Top Monitor Owner’s Manual 4. Parameters Display panel size TFT LCD 5.0inch 1152000 Pixels Panel type TFT LCD Resolution 800*480 Max resolution 1920×1440 Horizontal frequency range 30-60kHz Field frequency range 60Hz ~ 75Hz Distance 0.045(W) x 0.135 (H) -
Page 12: Accessories
Check “color” function menu “color temperature” adjustment, whether adjustment misconduct under the “user” state. If you are still experiencing problems, contact Marshall Electronics technical support at: (800) 800-6608 or +1 (310) 333-0606... -
Page 13: Menu List
Marshall M-CT5 Camera-Top Monitor Owner’s Manual Menu Option Chart Input Mode HDMI Video Color Brightness Contrast Saturation Color Temperature Language H Position V Position OSD Timeout Zoom Transparent Function Reset Display Ratio Screen Marker Center Marker DSLR Sound Volume... - Page 14 Marshall M-CT5 Camera-Top Monitor Owner’s Manual Marshall Electronics 1910 E. Maple Avenue El Segundo, CA 90245 USA Phone: 310-333-0606 • 800-800-6608 • Fax: 310-333-0688 marshall-usa.com Manual contents subject to change without notice.
