KAN200

12. SPECIFICATIONS

Speaker power handling
Frequency range
13
Acoustics
150 W
(AES)
Max power 300 W
(1)
Impedance
64 Ω
150 Hz – 18 KHz +/- 6dB
SPL 1W/1mt
86 dB
(3)
Maximum SPL
96 dB continuous – 102 dB peak
Coverage
Horizontal
160°
Vertical
10°
Crossover
Type
External cross over required
Frequency
150Hz, 24dB/oct suggested minimum
Transducers
Full-range
8 x 1" Neodymium cone driver with 0.75" voice coil
Power Audio Input
Connectors
2 x 4-pin speakon (1 female, 1 male)
Wiring
1+ 1- (signal IN & LINK) 2+ 2- (Through)
Recommended Amplifiers
KA40 for up to 16 units each channel and KMT12 for up to 8 units
Certification
IP
55
Physical
Dimensions
201.9 x 5.6 x 3.53 cm (79.5" x 2.2" x 1.4")
Weight
1.4 Kg (3.09 lbs)
Notes for data
1. Maximum RMS applicable power for a musical signal. The reference signal is the one proposed
by EIAJ standard;
2. With dedicated preset;
3. Mesured @8 m, then scaled @1 m;
4. Mesured with musical signal;
New materials and design are introduced into existing products without previous notice. Present
systems may differ in some respects from those presented in this catalogue.
(2)
(4)
REV. A
