Atlona AT-MDP21 Specifications

Atlona 2x1 Mini DisplayPort KVM Switch
FEATURES:
• 2 x Mini DisplayPort inputs and 1mini DisplayPort output KVM Switch.
• 4 USB inputs and 2 USB outputs.
• 2 input select buttons on front panel to select the input sources.
• Passive mechanical Switch, doesn't require power
• Supports digital video resolutions up to 1920x1200
• Supports high-speed uncompressed digital video.
SPECIFICATIONS:
• Type of Switcher: 2 inputs to 1 output, (Mechanical) Mini DisplayPort KVM Switch
• Video Resolutions: up to 1920x1200
• Controls: Select buttons on the front panel
• Signal Support: High-speed Uncompressed digital video and audio
• Safety Approvals: RoHS (2002/95/EC)
• Dimensions (LxWxH): 6.25"x 5" x 1.23"(160mm x 134.8mm x 32mm)
• Shipping Weight: 0.3 Kgs / 0.65 lbs
www.atlona.com | toll free: 1-877-536-3976
For International: 1-408-962-0515
Weight 0.65 lbs
SKU# AT-MDP21
REAR VIEW
INPUTS/OUTPUTS:
• Inputs: 2 x Mini DisplayPorts, 4xUSB
• Outputs: 1 x Mini DisplayPorts, 2xUSB
PACKAGE CONTENTS:
• 1 x AT-MDP21 2x1 Mini DisplayPort KVM Switch
• 1 x Instruction Manual
• 2 x 5ft Mini DisplayPort cables
• 4 x 5ft USB cables
WARRANTY
3 year manufacturer warranty (parts and labor)
