Icom IC-T7H Service Manual page 21

[LOGIC UNIT]
REF ORDER
NO. NO.
Q44 1590001860 S.TRANSISTOR
Q45 1590001690 S.TRANSISTOR
D1 1790001250 S.DIODE
D3 1790001250 S.DIODE
D4 1790000990 S.ZENER
D6 1790001250 S.DIODE
D7 1790001250 S.DIODE
D8 1790001200 S.DIODE
D11 1160000050 S.DIODE
1750000240 S.DIODE
D12 1750000220 S.DIODE
1750000240 S.DIODE
D14 1790001250 S.DIODE
D15 1160000050 S.DIODE
1750000240 S.DIODE
D16 1790001250 S.DIODE
D19 1790001250 S.DIODE
X1 6050009620 S.XTAL
R2 7030003580 S.RESISTOR
R10 7030003560 S.RESISTOR
R11 7030003560 S.RESISTOR
R12 7030003560 S.RESISTOR
R38 7030003800 S.RESISTOR
R41 7030003520 S.RESISTOR
R42 7030003630 S.RESISTOR
R43 7030003630 S.RESISTOR
R44 7030003550 S.RESISTOR
R45 7030003480 S.RESISTOR
R46 7030003580 S.RESISTOR
R47 7030003700 S.RESISTOR
R48 7030003750 S.RESISTOR
R140 7030003620 S.RESISTOR
R141 7030003440 S.RESISTOR
R142 7030003440 S.RESISTOR
R143 7030003440 S.RESISTOR
R144 7030003560 S.RESISTOR
R145 7030003720 S.RESISTOR
R146 7030003400 S.RESISTOR
R147 7310002600 S.TRIMMER
R148 7030003540 S.RESISTOR
R149 7030003320 S.RESISTOR
R151 7030003590 S.RESISTOR
R152 7030003650 S.RESISTOR
R153 7030003650 S.RESISTOR
R154 7030003710 S.RESISTOR
R155 7030003640 S.RESISTOR
R156 7030003520 S.RESISTOR
R157 7030003680 S.RESISTOR
R158 7030003520 S.RESISTOR
R159 7030003610 S.RESISTOR
R160 7030003700 S.RESISTOR
R161 7030003200 S.RESISTOR
R162 7030003320 S.RESISTOR
R181 7030003760 S.RESISTOR
R183 7030003320 S.RESISTOR
R184 7030003320 S.RESISTOR
R185 7030003320 S.RESISTOR
R186 7030003760 S.RESISTOR
R187 7030003800 S.RESISTOR
R190 7030003520 S.RESISTOR
R196 7030003680 S.RESISTOR
R197 7030005840 S.RESISTOR
R198 7030005840 S.RESISTOR
R200 7030003760 S.RESISTOR
R205 7030003680 S.RESISTOR
R207 7030003720 S.RESISTOR
R208 7030003320 S.RESISTOR
R209 7030005840 S.RESISTOR
R210 7030003560 S.RESISTOR
R211 7030003760 S.RESISTOR
R213 7030003670 S.RESISTOR
R214 7030003670 S.RESISTOR
R215 7030003670 S.RESISTOR
DESCRIPTION
UN9215 (TX)
UN9115 (TX)
MA2S111-(TX)
MA2S111-(TX)
MA8051-H (TX)
MA2S111-(TX)
MA2S111-(TX)
MA6S121 (TX)
DAP202U T107 [ITA], [SEA]
DA112 T107 [EUR], [USA-3]
DA113W T107 [ITA]
DA112 T107 [SEA], [USA-3]
MA2S111-(TX)
[EUR], [SEA], [USA-3] only
DAP202U T107
[EUR], [SEA], [USA-3]
DA112 T107 [ITA]
MA2S111-(TX) [USA-3] only
MA2S111-(TX)
CR-534 (5.039 MHz)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
[EUR], [ITA], [SEA]
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 394 V (390 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 471 V (470 Ω)
RV-110 (RH03A3AS4X0AA) 473
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 184 V (180 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
RR0510R-473-D (47 kΩ)
RR0510R-473-D (47 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 101 V (100 Ω)
RR0510R-473-D (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
[LOGIC UNIT]
REF ORDER
NO. NO.
R216 7030003800 S.RESISTOR
R218 7030003680 S.RESISTOR
R219 7030003840 S.RESISTOR
R220 7030003560 S.RESISTOR
R221 7030005520 S.RESISTOR
R222 7030005970 S.RESISTOR
R223 7030003520 S.RESISTOR
R224 7030003800 S.RESISTOR
R230 7030003680 S.RESISTOR
R231 7410000710 S.ARRAY
R233 7030003800 S.RESISTOR
R234 7030003800 S.RESISTOR
R235 7030005110 S.RESISTOR
R236 7030005110 S.RESISTOR
R237 7030005110 S.RESISTOR
R238 7030005110 S.RESISTOR
R240 7030003690 S.RESISTOR
R241 7030003680 S.RESISTOR
R242 7030003760 S.RESISTOR
R302 7030003560 S.RESISTOR
R304 7030003560 S.RESISTOR
R309 7030003560 S.RESISTOR
R336 7030003560 S.RESISTOR
C5 4030009810 S.CERAMIC
C6 4030011600 S.CERAMIC
C15 4030006860 S.CERAMIC
C17 4510005900 S.ELECTROLYTIC
C18 4030006860 S.CERAMIC
C19 4030006900 S.CERAMIC
C20 4550006120 S.TANTALUM
C21 4030011600 S.CERAMIC
C22 4030006860 S.CERAMIC
C23 4550006780 S.TANTALUM
C36 4030008920 S.CERAMIC
C40 4030006860 S.CERAMIC
C41 4030006870 S.CERAMIC
C42 4030006860 S.CERAMIC
C43 4030011600 S.CERAMIC
C44 4030006900 S.CERAMIC
C45 4030006900 S.CERAMIC
C80 4030009810 S.CERAMIC
C81 4030009810 S.CERAMIC
C82 4030009810 S.CERAMIC
C83 4030009810 S.CERAMIC
C84 4030009810 S.CERAMIC
C87 4030009810 S.CERAMIC
C91 4030009810 S.CERAMIC
C92 4030009810 S.CERAMIC
C93 4030009810 S.CERAMIC
C130 4030009800 S.CERAMIC
C131 4030006900 S.CERAMIC
C132 4030008920 S.CERAMIC
C133 4550003290 S.TANTALUM
C136 4030009000 S.CERAMIC
C137 4030006850 S.CERAMIC
C138 4030006860 S.CERAMIC
C139 4030006880 S.CERAMIC
C140 4030006850 S.CERAMIC
C141 4550003290 S.TANTALUM
C142 4030006860 S.CERAMIC
C143 4030007140 S.CERAMIC
C145 4030006880 S.CERAMIC
C146 4030006870 S.CERAMIC
C147 4030010040 S.CERAMIC
C148 4030006860 S.CERAMIC
C149 4550006780 S.TANTALUM
C154 4030008920 S.CERAMIC
C155 4030009650 S.CERAMIC
C156 4030007060 S.CERAMIC
C157 4030011600 S.CERAMIC
C166 4030006860 S.CERAMIC
C167 4030006860 S.CERAMIC
C168 4030006860 S.CERAMIC
C169 4030009980 S.CERAMIC
C170 4030011600 S.CERAMIC
C171 4030008910 S.CERAMIC
6 - 6
DESCRIPTION
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 225 V (2.2 MΩ)
ERJ3GEYJ 103 V (10 kΩ)
RR0816R-334-D (330 kΩ)
RR0816R-683-D (68 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
EXB-V8V 224JV (220 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ3GEYJ 124 V (120 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
[EUR] only
ERJ3GEYJ 103 V (10 kΩ)
[ITA] only
ERJ3GEYJ 103 V (10 kΩ)
[SEA] only
ERJ3GEYJ 103 V (10 kΩ)
[USA-3] only
C1005 JB 1E 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
ECEV0GA101SR
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
TEMSVA 0G 226M-8L
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
TEMSVB2 0J 476M-8R
C1608 JB 1C 473K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 222K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 471K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1C 473K-T-A
TESVA 0G 475M1-8L
C2012 JB 1C 224K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 471K-T-A
TESVA 0G 475M1-8L
C1608 JB 1H 102K-T-A
C1608 CH 1H 121J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 222K-T-A
C1608 JB 1H 561K-T-A
C1608 JB 1H 102K-T-A
TEMSVB2 0J 476M-8R
C1608 JB 1C 473K-T-A
C1608 CH 1H 240J-T-A
C1608 CH 1H 270J-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 152K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 393K-T-A
S.=Surface mount
