Icom IC-T7H Service Manual page 18

[1F UNIT]
REF ORDER
NO. NO.
W1 7120000470 JUMPER
W2 7030003860 S.JUMPER
W5 7030000010 S.JUMPER
EP1 0910051202 PCB
[PA BOARD]
REF ORDER
NO. NO.
Q401 1560001100 S.FET
Q402 1560001060 S.FET
L401 6200005670 S.COIL
L402 6200008830 S.COIL
L403 6200005600 S.COIL
L404 6200008480 S.COIL
L405 6200008220 S.COIL
L406 6200008870 S.COIL
R401 7030004980 S.RESISTOR
R402 7030004970 S.RESISTOR
R403 7030003380 S.RESISTOR
C401 4030009760 S.CERAMIC
C402 4030009810 S.CERAMIC
C403 4030009810 S.CERAMIC
C404 4030009810 S.CERAMIC
C405 4030009780 S.CERAMIC
C406 4030009810 S.CERAMIC
C407 4030009810 S.CERAMIC
C409 4030014520 S.CERAMIC
C410 4030016720 S.CERAMIC
C411 4030004720 S.CERAMIC
C412 4030007010 S.CERAMIC
EP401 0910051222 PCB
[DUAL-VCO BOARD]
REF ORDER
NO. NO.
Q301 1530003260 S.TRANSISTOR
Q302 1530003260 S.TRANSISTOR
Q304 1530003320 S.TRANSISTOR
Q305 1530003320 S.TRANSISTOR
Q306 1530003320 S.TRANSISTOR
D301 1720000370 S.VARICAP
D302 1790001260 S.DIODE
D303 1790001290 S.VARICAP
D304 1790001260 S.DIODE
L301 6110003180 COIL
L302 6200004480 S.COIL
L303 6110003190 COIL
L304 6200004480 S.COIL
R302 7030007290 S.RESISTOR
R303 7030005040 S.RESISTOR
R304 7030005590 S.RESISTOR
R305 7030005040 S.RESISTOR
R306 7030009200 S.RESISTOR
R307 7030009200 S.RESISTOR
R311 7030005120 S.RESISTOR
R312 7030005290 S.RESISTOR
DESCRIPTION
ERDS2T0
ERJ3GE JPW V
MCR10EZHJ JPW (000)
B 5215C
DESCRIPTION
2SK3074 (TE12L)
2SK3075 (TE12L)
ELJRE 12NG-F
0.20-1.0-12TL 60N
ELJRE 3N3Z-F
0.30-1.4-5TR 25N
0.40-1.4-5TR 21N
0.40-1.1-3TL
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 470 X (47 Ω)
ERJ3GEYJ 331 V (330 Ω)
C1005 CH 1E 150J-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 CH 1E 270J-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
GRH708 CH 200J 200PT
GRH708 CH 560J 100PT
C2012 JB 1H 102K-T-A
C1608 CH 1H 102K-T-A
B 5218B
DESCRIPTION
2SC5006-T1
2SC5006-T1
2SC5108-Y (TE85R)
2SC5108-Y (TE85R)
2SC5108-Y (TE85R)
HVU350TRF
MA2S077-(TX)
MA304 (TX)
MA2S077-(TX)
LA-508
MLF1608D R82K-T
LA-509
MLF1608D R82K-T
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 680 X (68 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 390 X (39 Ω)
ERJ2GEJ 390 X (39 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 682 X (6.8 kΩ)
[DUAL-VCO BOARD]
REF ORDER
NO. NO.
R313 7030004980 S.RESISTOR
R314 7030005290 S.RESISTOR
R315 7030004990 S.RESISTOR
R316 7030004970 S.RESISTOR
R317 7030005240 S.RESISTOR
R318 7030004980 S.RESISTOR
R319 7030005110 S.RESISTOR
R320 7030004990 S.RESISTOR
R321 7030004980 S.RESISTOR
C301 4030009780 S.CERAMIC
C302 4030010080 S.CERAMIC
C303 4030011670 S.CERAMIC
C304 4030011670 S.CERAMIC
C305 4030009810 S.CERAMIC
C306 4030009810 S.CERAMIC
C307 4030009810 S.CERAMIC
C308 4030011720 S.CERAMIC
C311 4030009810 S.CERAMIC
C312 4030009780 S.CERAMIC
C313 4030009810 S.CERAMIC
C314 4030011670 S.CERAMIC
C315 4030011670 S.CERAMIC
C316 4030009810 S.CERAMIC
C317 4030009810 S.CERAMIC
C318 4030009810 S.CERAMIC
C319 4030011720 S.CERAMIC
C320 4030009770 S.CERAMIC
C321 4030009810 S.CERAMIC
C322 4030009810 S.CERAMIC
C323 4030009810 S.CERAMIC
C324 4030009810 S.CERAMIC
C325 4030009810 S.CERAMIC
J301 6510018640 CONNECTOR
J302 6510018640 CONNECTOR
EP301 0910051194 PCB
[2F UNIT]
REF ORDER
NO. NO.
IC101 1110003490 S.IC
IC102 1130004200 S.IC
IC151 1110001810 S.IC
IC301 1130006220 S.IC
IC601 1110003370 S.IC
Q4 1590001170 S.TRANSISTOR
Q5 1510000670 S.TRANSISTOR
Q51 1530003430 S.TRANSISTOR
Q52 1530002560 S.TRANSISTOR
Q53 1590001690 S.TRANSISTOR
Q101 1530002600 S.TRANSISTOR
Q102 1590001170 S.TRANSISTOR
Q103 1540000350 S.TRANSISTOR
Q104 1540000350 S.TRANSISTOR
Q105 1590001690 S.TRANSISTOR
Q151 1520000650 S.TRANSISTOR
Q152 1590001170 S.TRANSISTOR
Q201 1530002920 S.TRANSISTOR
Q202 1530002560 S.TRANSISTOR
Q305 1590001140 S.TRANSISTOR
Q306 1590001470 S.TRANSISTOR
Q307 1590002010 S.TRANSISTOR
Q308 1590001770 S.TRANSISTOR
Q309 1590001430 S.TRANSISTOR
Q310 1590001140 S.TRANSISTOR
Q400 1530003310 S.TRANSISTOR
Q401 1530002560 S.TRANSISTOR
Q403 1590001690 S.TRANSISTOR
Q404 1590001690 S.TRANSISTOR
Q601 1530002900 S.TRANSISTOR
6 - 3
DESCRIPTION
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 682 X (6.8 kΩ)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 101 X (100 Ω)
C1005 CH 1E 270J-T-A
C1005 CH 1E 240J-T-A
C1005 CH 1E 2R5B-T-A
C1005 CH 1E 2R5B-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 CH 1E R75B T000P
C1005 JB 1E 102K-T-A
C1005 CH 1E 270J-T-A
C1005 JB 1E 102K-T-A
C1005 CH 1E 2R5B-T-A
C1005 CH 1E 2R5B-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 CH 1E R75B T000P
C1005 CH 1E 220J-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
C1005 JB 1E 102K-T-A
IMSA-9230B-1-05Z064-T
IMSA-9230B-1-05Z064-T
B 4731D
DESCRIPTION
TA31136FN (D,EL)
TC4S66F (TE85R)
TA7368F (TP1)
TC4W53FU (TE12L)
µPC2748T-E3
XP1501-(TX).AB
2SA1588-GR (TE85R)
2SC5226-4-TL
2SC4403-3-TL
UN9115 (TX)
2SC4215-O (TE85R)
XP1501-(TX).AB
2SD2216-S (TX)
2SD2216-S (TX)
UN9115 (TX)
2SB1201-S-TL
XP1501-(TX).AB
2SC4226-T2 R25
2SC4403-3-TL
UN9210 (TX)
UN9213 (TX)
XP1114 (TX)
XP1213 (TX)
UN9114 (TX)
UN9210 (TX)
2SC5107-O (TE85R)
2SC4403-3-TL
UN9115 (TX)
UN9115 (TX)
2SC4228-T2 R45
S.=Surface mount
