Icom IC-T7H Service Manual page 2

INTRODUCTION
This service manual describes the latest service information
for the IC-T7H DUAL BAND FM TRANSCEIVER at the time
of publication.
4 version of the IC-T7H have been designed. This serves
manual cover each versions.
MODEL VERSION
Europe
Italy
IC-T7H
SE Asia
U.S.A.
To upgrade quality, all electrical or mechanical parts and
internal circuits are subject to change without notice or
obligation.
DANGER
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than 16 V. This will ruin the
transcever.
DO NOT expose the transceiver to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100mW)
to the antenna connector. This could damage the transceiv-
er's front end.
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
1110002700 S.IC NJM2904M-T1
8810008750 Screw PH BO 2 x 15 ZK
Addresses are provided on the inside back cover for your
convenience.
1. Make sure a problem is internal before disassembling the transceiver.
2. DO NOT open the transceiver until the transceiver is disconnected from its power source.
3. DO NOT force any of the variable components. Turn them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insulated turning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the transceiver is defective.
6. DO NOT transmit power into a signal generator or a sweep generator.
7. ALWAYS connect a 40 dB to 50 dB attenuator between the transceiver and a deveiation meter or spectrum analyzer when
using such test equipment.
8. READ the instructions of test equipment thoroughly before connecting equipment to the transceiver.
SYMBOL
EUR
ITA
SEA
USA-3
IC-T7H 1F UNIT 5pieces
IC-T7H Chassis 10pieces
REPAIR NOTES
