• 2F UNIT
STANDARD SIGNAL GENERATOR (SSG)
100–500 MHz
–127 to – 17 dBm (0.1 V to 32 mV)
CAUTION:
DO NOT transmit while the
signal generator is connected.
L102
UHF sensitivity
adjustment
CP1
UHF sensitivity
check point
Terminator for the S-meter adjustment
5 - 4
68 k
8
speaker
L53
VHF sensitivity
L54
adjustment
L55
S
VHF sensitivity
check point
R504
Squelch level adjustment
