Icom IC-T7H Service Manual page 19

[2F UNIT]
REF ORDER
NO. NO.
Q602 1590002380 S.TRANSISTOR
Q901 1520000460 S.TRANSISTOR
Q902 1590002580 S.FET
D52 1790001290 S.VARICAP
D53 1790001290 S.VARICAP
D54 1790001290 S.VARICAP
D55 1750000530 S.DIODE
D101 1790001260 S.DIODE
D102 1790001260 S.DIODE
D103 1790001260 S.DIODE
D201 1750000530 S.DIODE
D202 1790001260 S.DIODE
D203 1790001260 S.DIODE
D301 1790001250 S.DIODE
D302 1790001250 S.DIODE
D400 1790001260 S.DIODE
D401 1790000840 S.DIODE
D402 1790000840 S.DIODE
D403 1790001260 S.DIODE
D404 1790001260 S.DIODE
D601 1790001260 S.DIODE
D602 1790001260 S.DIODE
D603 1790001260 S.DIODE
D604 1790001260 S.DIODE
D605 1790000850 S.DIODE
D606 1790001260 S.DIODE
D607 1790001260 S.DIODE
D902 1790000860 S.DIODE
D903 1790001240 S.DIODE
D904 1790000670 S.DIODE
FI101 2020001270 CERAMIC
FI201 2040001000 S.SAW
2040001020 S.SAW
FI401 2010001960 MONOLITH
L53 6150004920 S.COIL
L54 6150004920 S.COIL
L55 6150004920 S.COIL
L101 6200002710 S.COIL
L102 6150004840 S.COIL
L201 6200004370 S.COIL
L202 6200004380 S.COIL
L203 6200004360 S.COIL
L204 6200004360 S.COIL
L400 6200006980 S.COIL
L401 6200004340 S.COIL
L403 6200002710 S.COIL
L603 6200004370 S.COIL
L604 6200004350 S.COIL
L605 6200004350 S.COIL
L606 6200004390 S.COIL
L607 6200004390 S.COIL
L609 6200004400 S.COIL
R5 7030005050 S.RESISTOR
R51 7030005070 S.RESISTOR
R52 7030005090 S.RESISTOR
R53 7030005590 S.RESISTOR
R54 7030004980 S.RESISTOR
R55 7030007280 S.RESISTOR
R56 7030005050 S.RESISTOR
R57 7030005060 S.RESISTOR
R58 7030004970 S.RESISTOR
R59 7030005090 S.RESISTOR
R60 7030005090 S.RESISTOR
R61 7030005050 S.RESISTOR
R62 7030005050 S.RESISTOR
R63 7030005050 S.RESISTOR
R64 7030005050 S.RESISTOR
R101 7030005240 S.RESISTOR
R102 7030005000 S.RESISTOR
R103 7030005120 S.RESISTOR
R104 7030005080 S.RESISTOR
R105 7030005030 S.RESISTOR
R106 7030005110 S.RESISTOR
DESCRIPTION
XP1115 (TX)
2SB1132 T100 R
HAT1024R-EL
MA304 (TX)
MA304 (TX)
MA304 (TX)
1SV271 (TPH3)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
1SV271 (TPH3)
MA2S077-(TX)
MA2S077-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S077-(TX)
MA132WA (TX)
MA132WA (TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
MA132WK (TX)
MA2S077-(TX)
MA2S077-(TX)
MA133 (TX)
MA2S728-(TX)
SB07-03C-TB
CFWM450E
EFCH435MWNP1
[EUR], [ITA], [SEA]
EFCH445MWNP1 [USA-3]
45M15AM FL-244
LS-518
LS-518
LS-518
ELJFC 1R8K-F
LS-510
LL1608-F15NK
LL1608-F18NK
LL1608-F12NK
LL1608-F12NK
ELJRE R10G-F
LL1608-F6N8K
ELJFC 1R8K-F
LL1608-F15NK
LL1608-F10NK
LL1608-F10NK
LL1608-F22NK
LL1608-F22NK
LL1608-F47NK
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 680 X (68 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 823 X (82 kΩ)
ERJ2GEJ 152 X (1.5 kΩ)
ERJ2GEJ 224 X (220 kΩ)
[2F UNIT]
REF ORDER
NO. NO.
R107 7030005220 S.RESISTOR
R108 7030007340 S.RESISTOR
R110 7030005220 S.RESISTOR
R111 7030005220 S.RESISTOR
R112 7030005000 S.RESISTOR
R113 7030005050 S.RESISTOR
R114 7030005050 S.RESISTOR
R115 7030005230 S.RESISTOR
R116 7030005000 S.RESISTOR
R117 7030005240 S.RESISTOR
R118 7030005120 S.RESISTOR
R119 7030004980 S.RESISTOR
R120 7030005220 S.RESISTOR
R121 7030005240 S.RESISTOR
R122 7030005110 S.RESISTOR
R123 7030005160 S.RESISTOR
R151 7030005530 S.RESISTOR
R152 7030007270 S.RESISTOR
R153 7030005040 S.RESISTOR
R155 7030000140 S.RESISTOR
R156 7030000140 S.RESISTOR
R157 7030000140 S.RESISTOR
R158 7030005050 S.RESISTOR
R159 7030005120 S.RESISTOR
R160 7030005330 S.RESISTOR
R161 7030005330 S.RESISTOR
R162 7030005090 S.RESISTOR
R201 7030005060 S.RESISTOR
R202 7030007270 S.RESISTOR
R203 7030004990 S.RESISTOR
R204 7030005070 S.RESISTOR
R205 7030007280 S.RESISTOR
R206 7030007300 S.RESISTOR
R207 7030005040 S.RESISTOR
R300 7510000960 S.THERMISTOR
R301 7030006020 S.RESISTOR
R302 7310003590 S.TRIMMER
R303 7030005070 S.RESISTOR
R304 7310003590 S.TRIMMER
R305 7030005240 S.RESISTOR
R306 7030005170 S.RESISTOR
R308 7310003630 S.TRIMMER
R309 7030005530 S.RESISTOR
R310 7030005050 S.RESISTOR
R311 7030009290 S.RESISTOR
R312 7030005240 S.RESISTOR
R313 7310003610 S.TRIMMER
R314 7310003630 S.TRIMMER
R315 7030005050 S.RESISTOR
R316 7310003610 S.TRIMMER
R401 7030005040 S.RESISTOR
R402 7030005090 S.RESISTOR
R403 7030005580 S.RESISTOR
R404 7030005600 S.RESISTOR
R405 7030005570 S.RESISTOR
R406 7030005710 S.RESISTOR
R407 7030005040 S.RESISTOR
R408 7030005040 S.RESISTOR
R409 7030003520 S.RESISTOR
R410 7030005120 S.RESISTOR
R411 7030005010 S.RESISTOR
R414 7030005000 S.RESISTOR
R415 7030005310 S.RESISTOR
R502 7030005530 S.RESISTOR
R504 7310003590 S.TRIMMER
R505 7030007340 S.RESISTOR
R506 7510001040 S.THERMISTOR
R601 7030005040 S.RESISTOR
R602 7030007300 S.RESISTOR
R603 7030005220 S.RESISTOR
R604 7030007280 S.RESISTOR
R605 7030004980 S.RESISTOR
R606 7030007290 S.RESISTOR
R607 7030005090 S.RESISTOR
R608 7030005040 S.RESISTOR
R609 7030005090 S.RESISTOR
R610 7030007290 S.RESISTOR
R612 7030005040 S.RESISTOR
R903 7030000180 S.RESISTOR
R904 7030000180 S.RESISTOR
R905 7030005090 S.RESISTOR
R906 7030005050 S.RESISTOR
6 - 4
DESCRIPTION
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 334 X (330 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 105 X (1 MΩ)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
MCR10EZHJ 10 Ω (100)
MCR10EZHJ 10 Ω (100)
MCR10EZHJ 10 Ω (100)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 102 X (1 kΩ)
RR0816P-562-D (5.6 kΩ)
RR0816P-562-D (5.6 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
TBPS1R104K475H5Q
RR0510P-682-D (6.8 kΩ)
EVM-1XSX50 B24 (203)
ERJ2GEJ 683 X (68 kΩ)
EVM-1XSX50 B24 (203)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 474 X (470 kΩ)
EVM-1XSX50 BQ4 (473)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 562 X (5.6 kΩ)
ERJ2GEJ 473 X (47 kΩ)
EVM-1XSX50 B14 (103)
EVM-1XSX50 BQ4 (473)
ERJ2GEJ 103 X (10 kΩ)
EVM-1XSX50 B14 (103)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 560 X (56 Ω)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 820 X (82 Ω)
ERJ2GEJ 121 X (120 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 681 X (680 Ω)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 124 X (120 kΩ)
ERJ2GEJ 100 X (10 Ω)
EVM-1XSX50 B24 (203)
ERJ2GEJ 153 X (15 kΩ)
TBPS1R153K460H5Q
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
MCR10EZHJ 22 Ω (220)
MCR10EZHJ 22 Ω (220)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 103 X (10 kΩ)
S.=Surface mount
