Setting up the telephone

Connecting the phone

Before you can start using your telephone you must plug in the telephone connector
cable and the mains cable.
Socket for mains cable
Safety note
Use only the mains units supplied for the base station or charging unit.
Telephone connector cable
The telephone connector cable has two different plugs. Insert the smaller plug in the
socket marked with the telephone symbol on the base station, and fit the cable into the
corresponding cable duct. Insert the larger plug in your telephone connection socket.
Mains cable
First, insert the mains cable in the socket marked with the mains connector symbol on
the base of the base station or charging unit, and fit the cable in the moulded cable
duct. Then insert the mains plug in the 230 V socket.
Note Your telephone will not function if the mains connector is not plugged in or
during a power failure.
Socket for telephone connector cable
12
