788T/788T-SSD User Guide and Technical Information
Wave Agent Beta
XL-1B
XL-2
XL-2F
XL-4
XL-88
XL-B2
XL-BNC
XL-DVDRAM
XL-H
XL-LB2
XL-LCD
XL-LL
XL-LX
XL-NPH
XL-RJ
XL-WPH3
166
v. 3.01 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
Sound Devices Wave Agent fi le librarian for Mac OS and Windows
computers. Wave Agent provides a comprehensive and indispens-
able range of tools for preparing audio fi les for problem-free passage
through complex production workfl ows. Wave Agent allows a 788T
to be connected via USB for extended metering and control. For more
details and download visit www.waveagent.com.
TA3F to TA3F cable, connects the direct outputs of a Sound Devices
442 mixer to the 788T's analog inputs 5-8, also used to connect analog
outputs 1-4 to third-party devices with TA3M inputs, 12-inch.
TA3F to XLR-M cable, used to connect analog and digital outputs 1-4
to third-party devices with XLR-F inputs, 25-inch; package of two.
XLR-F to TA3F cable, used to connect microphones, mixers, and other
devices with XLR-M outputs to the 788T analog inputs 5-8, 25-inch;
package of two.
Bag of four (4) TA3-F-type connectors.
788T-specifi c breakout cable for the DE-15 multi-pin connector. XLR
connectivity to AES inputs 1 through 8, plus XLR output for AES 5/6.
A 4-pin Hirose female connector accepts 10-18 VDC input. Lead for
Logic In and Out.
Removable, rechargeable, Li-ion battery; 7.2 V, 4600 mAh battery;
good to have several spares.
BNC to BNC cable, to connect word clock from external sources to the
788T for synchronizing the 788T; also used to sync external devices
from the word clock of the 788T.
External slot-loading DVD-RAM drive in FireWire and USB enclosure.
5X writing. For use with 7-Series recorders for recording, copying, and
playback. Powered by FireWire bus or included external supply.
Bare Hirose 4-pin locking DC connector (HR10-7P-4P).
5-pin LEMO to two (2) BNC cable, used to jam to and from video
cameras, 60-inch.
Protective, clear Lexan LCD cover for 7-Series Digital Recorders. Pro-
tects the LCD glass from scratches and water. Kit of four covers.
LEMO-5 to LEMO-5 time code cable, time code equipped 7-Series re-
corders to Ambient Lockit, Slate, or Masterclock, coiled cable, 20-inch
coiled, 55-inch full extension.
5-pin LEMO to XLR-M and XLR-F cable, used to connect the time code
output to SMTPE time code inputs and outputs, 25-inch to XLR-M,
14-inch to XLR-F.
NP-type battery cup with 24-inch cable terminated in Hirose 4-pin
locking DC connector (HR10-7P-4P) at equipment end.
RJ-12 to RJ-12 for C.Link to C.Link 702, 702T, 722, 744T, and 788T
recorder linking, 12-inch.
AC to DC Power Supply (in-line) 100 - 240V 50/60 Hz input, 12 VDC
3.75 A (45 W) output, Hirose 4-pin DC plug. Supplied with 3-pin IEC
cord for use in North America and Japan.
