Access the Input Settings Window
7.
To access, momentarily move the Input Selector Switch in the direction of
the Input. This action also sends the input signal to the headphone monitor
(solo).
1 3 5
2 4 6
Input Setting Options:
Source (mic/line/digital)
Phantom (on (mic)/on (line)/off)
High-Pass Filter (on/off)
Limiter (on/off)
Input-to-Track Routing
Mute (none / mute)
Polarity (normal / reverse)
8. The Input Settings Window is where changes are made to input parameters.
Press the TONE key to toggle Phantom Power (Choose 48V for microphones).
Turn the Rotary Switch to adjust the High-Pass Filter Frequency.
MENU
HDD
788T/788T-SSD User Guide and Technical Information
1
MENU
7
8
HDD
Press adjacent key to change the parameter.
Left for odd inputs
2
Right for even inputs
MENU
HDD
Turn the Rotary Switch
3
