788T/788T-SSD User Guide and Technical Information
# Setup Name
52. Output 1: Analog Gain
53. Output 2: Analog Gain
54. Output 3: Analog Gain
55. Output 4: Analog Gain
56. Output 5: Analog Gain
57. Output 6: Analog Gain
58. Digital Input: AES42 Power
59. Digital Output: Mode
60. Play: AutoPlay Mode
61. Time/Date: 12/24 Hr
62. Time/Date: Date Format
63. Time/Date: Set
64. LCD: Contrast
65. LCD: Backlight Mode
66. LCD: Scrolling Direction
67. Meter: Scale
68. Meter: Ballistics
154
v. 3.01 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
Description
Sets the attenuation level of each
analog output bus.
Provides +10 V of Digital Phantom
Power to each digital input. Never
apply digital phantom to unbalanced
digital inputs, as this can result in
damage to the hardware.
Selects whether or not the consumer
SPDIF bit is applied or not in the
AES3id output.
Allows the user to play file(s) con-
secutively from a select directory, one
time through or continuously.
Great for playing an MP3 collection
during down time!
Selects between 12- and 24-hour
formats.
Selects the date syntax of the
recorder.
Sets the internal date and time of
the 788T.
Resetting the time re-jams the inter-
nal time code generator to the set
time. Setting the internal clock during
a production day will require time
code devices to be re-jammed.
Adjusts the contrast level of the LCD
display.
Enables or disables the LCD
backlight color from indicating that
the 788T is in Record, Playback, or
Standby.
Defines the direction in which the Ro-
tary Switch will navigate throughout
the 788T.
Selects meter scale in dBFS. Stan-
dard and Zoom options are factory
settings. Custom meter scales can be
set by adding a new entry and edit-
ing the meter scale. The * indicates
Favorite mode. Press and hold the
Backlight key to toggle between the
selected meter scale and the favorite.
Lists are saved to a METERSCALED
folder within the INHDD SOUNDDEV
folder.
Selects among three different meter
ballistics settings
Options
Selectable from -40 to 0 dB in 1 dB incre-
ments
• Disabled
• Enabled
• Consumer
• Professional
• Disabled
• Play all
• Repeat one
• Repeat all
• 12 hr
• 24 hr
• mm/dd/yy
• dd/mm/yy
<time, date>
Clock is not set until <done> is selected
0–100%
• White/Green/Red
• Red on Record Only
• Green on Play Only
• White Only
• Normal
• Reverse
• Standard
• Zoom
• <Add New Entry>
• <Load List From INHDD>
• <Save List From INHDD>
• <Load Default List>
• <Set Favorite>
• VU only
• Peak only
• Peak + VU
Factory
Default
-4 dB
Disabled
Professional
Play all
12 hr
mm/dd/yy
White/Green/Red
Normal
Standard
Zoom is Favorite
Peak + VU
