Viewing Controller Settings - Promise Technology FastTrak TX2000 User Manual

Viewing Controller Settings

The Controller Configuration <6> menu selection allows you to enable or disable the FastTrak
TX2000 BIOS from halting (the default) if it detects an error on boot up. You may also view the
system resources (Interrupt and I/O port address) of FastTrak's data channels.
FastBuild (tm) Utility 1.xx (c) 1995-2001 Promise Technology, Inc.
Channel 1 (IDE1)
Channel 2 (IDE2)
Halting FastTrak BIOS On Bootup Errors
The [Adapter Configuration – Options] section allows you to enable or disable FastTrak TX2000
to Halt operation at the BIOS startup screen should an error be detected. This is the only option
that can be changed on this screen.
Viewing FastTrak System Resources
The [System Resources Configuration] section of this submenu displays the PCI slot interrupt
and port address used by the FastTrak TX2000. The resources used are determined by the
Mainboard PCI PnP BIOS for the PCI slot in which the FastTrak TX2000 resides.
In the rare case that there is a resource conflict, refer to the Mainboard BIOS documentation on
changes on resources allocated to the FastTrak TX2000 PCI slot.
FastTrak TX2000™ Series User Manual
[ Adapter Configuration - Options ]
Halt On Error:
[ System Resources Configuration ]
Interrupt : A
Interrupt : A
[ Keys Available ]
[ , , Space] Change Option [ESC] Exit
Enable
I/O Port : FFF0
I/O Port : FFA8
29
