Selecting Array Type
1.
Under the Definition section of this menu, highlight the Array # for which you want to
assign a RAID level.
2.
Use the [Space] key to cycle through three array types: Performance (RAID 0 Striping),
Security (RAID 1 Mirroring, RAID 0+1 Striping/Mirroring (for 4 drives), or Capacity
(Spanning)). See page 43 about RAID levels.
FastBuild (tm) Utility 1.xx (c) 1995-2001 Promise Technology, Inc.
Array No
RAID Mode
Array 1
Stripe Block: 64 KB
Channel:ID
1 : Master
1 : Slave
2 : Master
[ ] Up [ ] Down [ESC] Exit [Space] Select [Ctrl-Y] Save
Selecting Stripe Block
For RAID 0 and RAID 0+1 arrays you may manually select the "stripe block size." Use the
Spacebar to scroll through choices progressing as follows (1, 2, 4, 8, 16 . . . 1024).
The size selected affects how FastTrak TX2000 sends and retrieves data blocks from the
drives. You will need to perform your own testing to determine how the data block size is
affecting your particular use of the array. In general, a larger block size is better when handling
large data transfers (such as in A/V editing or graphics) while a smaller block size is better
when handling e-mail and other common server data. The default is 64K.
Gigabyte Boundary
The Gigabyte Boundary feature is designed for mirrored arrays (RAID 1 or
RAID 0+1) in which a drive has failed and the user cannot replace the drive with the same
capacity or larger. Instead, the Gigabyte Boundary feature permits the installation of a
replacement drive that is slightly smaller (within 1 gigabyte) than the remaining working drive
(for example, a 20.5 GB drive would be rounded down to 20 GB). This can be helpful in the
event that a drive fails and an exact replacement model is no longer available. Without this
feature enabled, FastTrak TX2000 will NOT permit the use of a replacement drive that is slightly
smaller than the remaining working drive.
For the Gigabyte Boundary feature to work, the Gigabyte Boundary feature must be set to "ON"
when the original mirrored array is created. When enabled, the Gigabyte Boundary feature
rounds the drive capacity of both drives to the common whole GB drive size. For example, with
the Gigabyte Boundary feature enabled, the remaining working drive can be 20.5 GB and the
replacement drive can be 20.3, since both are rounded down to 20GB. This permits the smaller
FastTrak TX2000™ Series User Manual
[ Define Array Definition Menu ]
Total Drv
Stripe
2
[ Drive Assignments ]
Drive Model
QUANTUMCR8.4A
QUANTUMCR8.4A
QUANTUMCR8.4A
[ Keys Available ]
Capacity(MB)
16126
Gigabyte Boundary: ON
Capacity (MB)
8063
8063
8063
20
Status
Functional
Assignment
Y
N
Y
