1.4 FRONT VIEW

1.4.1 LED Indicators

Power — This LED will emit a
when the Mercury Elite Pro Dual is on. During
drive activity the LED will
during a rebuild the LED will
HDD1/HDD2 — These LEDs represent the two
hard disk drives (HDDs) inside the Mercury Elite
Pro Dual. During normal activity, these LEDs will
remain off. If one of the hard drives inside the
Mercury Elite Pro Dual fails, or if one of the drives
is removed without the RAID mode being reset,
the corresponding LED will

1.5 REAR VIEW

1
OWC MERCURY ELITE PRO DUAL
solid blue
blink blue
steadily, and
pulse blue
blink red.
2
3
light
Power
slowly.
4
2
HDD1 HDD2
6
5
INTRODUCTION
