C o n n e c t i n g t h e T r a n s m i t t e r

How to transmit audio/video from your VCR

Step 1. Make sure the WAVECOM
Connect one set of audio/video (A/V) cables to the A/V jacks of the
transmitter and to the A/V jacks on the back of your VCR labeled LINE
OUT. Be sure the yellow, red and white plugs match the yellow, red and
white jacks on both the VCR and the transmitter. If the VCR has only one
output for audio (mono sound only), connect the white plug to that single
audio output and to the transmitter's AUDIO LEFT jack.
Step 2. Plug one end of the provided power adapter into the back of the
WAVECOM
outlet . Turn the ON/OFF switch to on position and indicator light should
go on.
Step 3. If your VCR has only one set of A/V output jacks and you want to use it
with a nearby TV, connect coaxial cable from the single OUT port on your
VCR to the VHF/UHF IN port on your TV. (Note: In order to also view
cable transmission on that TV, connect your incoming cable TV source to
the single IN port of the VCR.)
Step 4. Locate and orient the transmitter according to the chapter of this manual
titled "Orienting Units for Optimal Performance."
TM
6 WAVECOM
TM
Sr. transmitter and the other end into any 120-volt wall
Sr. owner's manual
TM
Sr. ON/OFF switch is in the OFF position.
