RF-Link WAVECOM Sr Owner's Manual page 25

Warning: See instructions shown below for rotating audio/video antenna.
Rotating antenna beyond the specified range will result in permanent
damage to both antenna and mechanical stopper.
In most situations, the flat pitted face of the A/V antennas on both the transmitter
and receiver should be facing one another. Since each home is different, for optimal
reception, additional slight pivots or rotations may be necessary. If the transmitter
and receiver are less that 10 feet apart, keep the A/V antennas flat in their casings.
Remote Control
Antenna
Sideview of WAVECOM Sr.
Warning: Do not rotate
audio/video antenna beyond the
indicated region. Antenna does
not rotate freely 360º.
Maximum clockwise rotation of
audio/video antenna shown
TM
WAVECOM
Audio/Video
Antenna
Front side of the
antenna-pitted
side
Sr. owner's manual 23
